01 |
438 095 40
|
Driver's cab assy. |
1 |
InternBDB: 7-560-00 SK 438 080 40
|
|
|
|
02 |
|
Covering |
1 |
InternBDB: 25 P 00005
|
111-1905 |
|
|
03 |
|
Glazing with trap shield |
1 |
|
|
|
|
|$4 |
|
with compound glass |
-2 |
|
111-1910 |
|
|
04 |
|
Wipe and wash equipment |
1 |
|
111-1915 |
|
|
05 |
|
Lighting equipment |
1 |
|
111-2105 |
|
|
06 |
696 341 73
|
Cab door assy. |
1 |
InternBDB: H 557/560-16 SK 438 075 40 | InternKon: 438 095 40 / 2
|
|
|
|
07 |
457 806 40
|
Cover |
1 |
InternBDB: 30 P 70005 Best.-Nr. 2681-32A Pos. 53 | InternKon: 438 095 40 / 7
|
|
|
|
08 |
457 807 40
|
Retainer for sun visor |
1 |
InternKon: 438 095 40 / 8
|
|
|
|
09 |
457 808 40
|
Threaded rod |
1 |
InternKon: 438 095 40 / 9
|
|
|
|
10 |
461 568 40
|
Rod for mirror |
1 |
InternKon: 438 095 40 / 10
|
|
|
|
11 |
|
Rod for mirror |
1 |
InternKon: 438 095 40 / 11
|
|
|
|
12 |
269 203 40
|
Ashtray |
1 |
InternBDB: GHE 550 0056 | InternKon: 438 095 40 / 35
|
|
|
|
13 |
461 210 40
|
Sun visor |
1 |
InternBDB: 562 0064 | InternKon: 438 095 40 / 36
|
|
|
|
14 |
081 334 40
|
Dressing hook |
1 |
InternBDB: GHE 621 0021 | InternKon: 438 095 40 / 37
|
|
|
|
15 |
|
Profile |
-2 |
InternBDB: GHE 461 0046 | InternKon: 438 095 40 / 39
|
|
|
|
16 |
|
Profiled joint |
-2 |
InternBDB: GHE 461 0048 | InternKon: 438 095 40 / 40
|
|
|
|
17 |
461 209 40
|
Silent bloc |
1 |
InternBDB: Phцnix 781 073 | InternKon: 438 095 40 / 46
|
|
|
|
18 |
461 213 40
|
Lock |
1 |
InternBDB: DLP 2/4604/1 | InternKon: 438 095 40 / 47
|
|
|
|
19 |
461 214 40
|
Lock pin |
1 |
InternBDB: DLP 0/4663 | InternKon: 438 095 40 / 48
|
|
|
|
20 |
461 215 40
|
Plate |
1 |
InternBDB: DLP 19.4661. 01.24 | InternKon: 438 095 40 / 49
|
|
|
|
21 |
461 216 40
|
Washer |
1 |
InternBDB: DLP 0/4662 | InternKon: 438 095 40 / 50
|
|
|
|
22 |
461 217 40
|
Handle |
1 |
InternBDB: DLP 4429 K | InternKon: 438 095 40 / 51
|
|
|
|
23 |
461 218 40
|
Base |
1 |
InternBDB: DLP 4426/1 | InternKon: 438 095 40 / 52
|
|
|
|
24 |
461 219 40
|
Base |
1 |
InternBDB: DLP 4426/2 | InternKon: 438 095 40 / 53
|
|
|
|
25 |
696 482 73
|
Door fixing device |
1 |
InternBDB: 30 D 00476 115.880.0160 | InternKon: 438 095 40 / 54
|
|
|
|
26 |
696 483 73
|
Plate |
1 |
InternBDB: 30 D 00477 115.887.0006 | InternKon: 438 095 40 / 55
|
|
|
|
27 |
461 572 40
|
Cover |
1 |
InternBDB: Kapsto GPN 910/20365/ 3044 schwarz | InternKon: 438 095 40 / 58
|
|
|
|
28 |
350 748 99
|
Fork end |
1 |
InternBDB: G 6x12-9S20K DIN 71752 | InternKon: 438 095 40 / 59
|
|
|
|
29 |
002 823 98
|
Clip |
1 |
InternBDB: 6x12 ESN 01 9S 20K | InternKon: 438 095 40 / 60
|
|
|
|
30 |
461 573 40
|
Mirror |
2 |
InternBDB: 30 S 00 626 | InternKon: 438 095 40 / 61
|
|
|
|
31 |
461 574 40
|
Clamp for mirror |
2 |
InternKon: 438 095 40 / 62
|
|
|
|
32 |
461 575 40
|
Handle |
1 |
InternKon: 438 095 40 / 63
|
|
|
|
33 |
461 579 40
|
Plug |
1 |
InternKon: 438 095 40 / 64
|
|
|
|
34 |
308 575 99
|
Bolt |
2 |
InternBDB: M10x40 /931 | InternKon: 438 095 40 / 67
|
|
|
|
35 |
500 299 98
|
Screw |
3 |
InternBDB: M6x20 /7985 | InternKon: 438 095 40 / 69
|
|
|
|
36 |
318 579 99
|
Screw |
6 |
InternBDB: M6x16 /964 | InternKon: 438 095 40 / 70
|
|
|
|
37 |
318 377 99
|
Bolt |
2 |
InternBDB: M5x25 /963 | InternKon: 438 095 40 / 71
|
|
|
|
38 |
506 408 98
|
Bolt |
2 |
InternBDB: M5x25 /931 | InternKon: 438 095 40 / 72
|
|
|
|
39 |
504 010 98
|
Bolt |
6 |
InternBDB: M5x16 /933 | InternKon: 438 095 40 / 73
|
|
|
|
40 |
320 976 99
|
Screw |
5 |
InternBDB: AM 4x20 /84 | InternKon: 438 095 40 / 74
|
|
|
|
41 |
318 373 99
|
Bolt |
4 |
InternBDB: M4x16 /963 | InternKon: 438 095 40 / 75
|
|
|
|
42 |
334 678 99
|
Nut |
2 |
InternBDB: M 10 /985 | InternKon: 438 095 40 / 76
|
|
|
|
43 |
332 110 99
|
Nut |
10 |
InternBDB: M 6 /934 | InternKon: 438 095 40 / 78
|
|
|
|
44 |
343 610 99
|
Washer |
2 |
InternBDB: A 10,5 /6798 | InternKon: 438 095 40 / 79
|
|
|
|
45 |
346 499 99
|
Lock washer |
1 |
InternBDB: B 6 /128 | InternKon: 438 095 40 / 82
|
|
|
|
46 |
346 509 99
|
Lock washer |
2 |
InternBDB: B 5 /128 | InternKon: 438 095 40 / 83
|
|
|
|
47 |
340 463 99
|
Washer |
11 |
InternBDB: B 6,4 /125 | InternKon: 438 095 40 / 84
|
|
|
|
48 |
461 211 40
|
Safety cap |
2 |
InternBDB: M 10 | InternKon: 438 095 40 / 85
|
|
|
|
49 |
461 212 40
|
Safety cap |
6 |
InternBDB: M 5 | InternKon: 438 095 40 / 87
|
|
|
|
50 |
440 556 40
|
Hinge assy. with grease nipple |
2 |
|
|
