Pilot oil unit |
2 |
InternBDB: 414 156 40 | InternKon: 457 800 40 / 23
|
090-0442 |
|
|
? |
|
Pilot oil unit H 65 H 85 |
1 |
InternBDB: 346 567 40 | InternKon: 457 800 40 / 22
|
090-0441 |
|
|
? |
|
Pilot oil unit |
2 |
InternBDB: 414 960 40 | InternKon: 466 170 40 / 24
|
090-0461 |
|
|
? |
|
Operator's seat |
1 |
InternBDB: 44578740 TL | InternKon: 457 800 40 / 21
|
090-6719a |
|
|
? |
|
Wiper and windscreen washing assy. |
1 |
|
111-1915 |
|
|
? |
|
Pilot oil unit |
1 |
InternBDB: 368 162 40 | InternKon: 457 800 40 / 24
|
090-0387 |
|
|
? |
320 214 99
|
Screw |
8 |
InternBDB: M6x20 /912 | InternKon: 457 800 40 / 60
|
|
|
|
? |
343 853 99
|
Lock washer |
8 |
InternBDB: 6 /7980 | InternKon: 457 800 40 / 69
|
|
|
|
? |
436 928 40
|
Cover |
1 |
InternKon: 466 170 40 / 16
|
|
|
|
? |
440 637 40
|
Flex. hose
Bulk ware, state length
required |
2 |
InternBDB: Techno-Chemie LW 110 Typ K1 /7130 | InternKon: 457 800 40 / 51
|
|
|
|
? |
374 933 99
|
Clamp |
4 |
InternBDB: AS 100-120/ 3017 | InternKon: 457 800 40 / 53
|
|
|
|
? |
421 531 40
|
Intermediate plate |
1 |
InternKon: 457 800 40 / 26
|
|
|
|
? |
308 553 40
|
Bolt |
3 |
InternBDB: M8x35 /931 | InternKon: 457 800 40 / 57
|
|
|
|
? |
340 507 99
|
Washer |
3 |
InternBDB: A8,4 /125 | InternKon: 457 800 40 / 72
|
|
|
|
? |
421 517 40
|
Foot rest |
1 |
InternKon: 457 800 40 / 11
|
|
|
|
? |
421 521 40
|
Safety rubber |
1 |
InternKon: 457 800 40 / 19
|
|
|
|
? |
308 907 99
|
Bolt |
1 |
InternBDB: M8x55 /931 | InternKon: 457 800 40 / 56
|
|
|
|
? |
332 111 99
|
Nut |
1 |
InternBDB: M8 /934 | InternKon: 457 800 40 / 66
|
|
|
|
? |
436 920 40
|
Foot supporting surface |
1 |
InternKon: 466 170 40 / 11
|
|
|
|
? |
436 926 40
|
Safety rubber 70x120 |
1 |
InternKon: 466 170 40 / 19
|
|
|
|
? |
436 912 40
|
Lever assy. |
1 |
InternKon: 466 170 40 / 15
|
|
|
|
? |
505 901 98
|
Compression spring |
1 |
InternBDB: 6x20x48/2098 | InternKon: 466 170 40 / 118
|
|
|
|
? |
344 643 99
|
Groove pin |
1 |
InternBDB: 6x20 /1473 | InternKon: 466 170 40 / 119
|
|
|
|
? |
307 596 99
|
Bolt |
1 |
InternBDB: M6x25 /933 | InternKon: 466 170 40 / 117
|
|
|
|
? |
307 597 99
|
Bolt |
8 |
InternBDB: M8x25 /933 | InternKon: 466 170 40 / 116
|
|
|
|
? |
307 425 99
|
Bolt |
14 |
InternBDB: M8x20 /933 | InternKon: 466 170 40 / 58
|
|
|
|
? |
|
Pilot oil unit (applies to bullclam equipment only) |
1 |
|
|
|
|
? |
319 136 99
|
Screw |
4 |
InternBDB: M6x50 /912
|
|
|
|
? |
346 499 99
|
Lock washer |
4 |
InternBDB: 6 /128
|
|
|
|
? |
332 110 99
|
Nut |
4 |
InternBDB: 6 /934
|
|
|
|
? |
445 736 40
|
Parts to control, 570 mm |
1 |
InternBDB: 445 739 40/4
|
|
|
|
? |
449 322 40
|
Parts to control, 1300 mm |
1 |
InternBDB: 449 325 40/4
|
|
|
|
? |
457 804 40
|
Parts to control, standard |
1 |
InternKon: 457 800 40 / 6
|
|
|
|
? |
445 760 40
|
Arm support |
2 |
InternKon: 457 800 40 / 9
|
|
|
|
? |
445 771 40
|
Bracket |
2 |
InternKon: 457 800 40 / 20
|
|
|
|
? |
440 564 40
|
Screw |
4 |
InternBDB: Ganter SK32/M6x20/ GN 6363.4 | InternKon: 457 800 40 / 28
|
|
