01 |
|
Compressor |
1 |
InternBDB: 255 470 40
|
|
|
|
02 |
255 472 40
|
Magnetic clutch |
1 |
InternBDB: York 77-022/24V
|
|
|
|
03 |
153 683 40
|
Refrigerant |
1 |
InternBDB: Teves R 12
|
|
|
|
04 |
445 129 40
|
Shaft |
1 |
InternKon: 445 128 40 / 1
|
|
|
|
05 |
445 136 40
|
V-belt pulley 2-rillig |
1 |
InternKon: 445 128 40 / 2
|
|
|
|
06 |
445 137 40
|
Angle |
1 |
InternKon: 445 128 40 / 3
|
|
|
|
07 |
445 138 40
|
Carrier |
2 |
InternKon: 445 128 40 / 4
|
|
|
|
08 |
445 139 40
|
Flat steel |
1 |
InternBDB: SchweiЯteil | InternKon: 445 128 40 / 5
|
|
|
|
09 |
445 140 40
|
Rib |
2 |
InternBDB: SchweiЯteil | InternKon: 445 128 40 / 6
|
|
|
|
10 |
445 141 40
|
Flat steel |
1 |
InternBDB: SchweiЯteil | InternKon: 445 128 40 / 7
|
|
|
|
11 |
445 142 40
|
Flat steel |
1 |
InternBDB: SchweiЯteil | InternKon: 445 128 40 / 8
|
|
|
|
12 |
506 143 98
|
V-belt set |
1 |
InternBDB: 2x12,5x1268LA /07753 | InternKon: 445 128 40 / 9
|
|
|
|
13 |
534 061 99
|
Bolt |
4 |
InternBDB: 3/8-16xUNC 1 1/2 10.9 | InternKon: 445 128 40 / 10
|
|
|
|
14 |
341 207 99
|
Washer |
4 |
InternBDB: 11 /434 | InternKon: 445 128 40 / 11
|
|
|
|
15 |
340 465 99
|
Washer |
4 |
InternBDB: 10,5 /125 | InternKon: 445 128 40 / 12
|
|
|
|
16 |
304 136 99
|
Bolt |
4 |
InternBDB: M10x45 /931 10.9 | InternKon: 445 128 40 / 13
|
|
|
|
17 |
332 113 99
|
Nut |
8 |
InternBDB: M 10 /934 | InternKon: 445 128 40 / 14
|
|
|
|
18 |
332 334 99
|
Nut |
1 |
InternBDB: M 12 /934 | InternKon: 445 128 40 / 15
|
|
|
|
19 |
504 011 98
|
Bolt |
2 |
InternBDB: M12x50 /931 10.9 | InternKon: 445 128 40 / 16
|
|
|
|
20 |
308 460 99
|
Bolt |
2 |
InternBDB: M12x50 /931 10.9 | InternKon: 445 128 40 / 17
|
|
|
|
21 |
350 562 99
|
Grease nipple |
1 |
InternBDB: AM 10x1 /71412 5.8 | InternKon: 445 128 40 / 18
|
|
