01 |
436 914 40
|
Control plate |
1 |
InternKon: 420 120 40 / 1
|
|
|
|
02 |
411 776 40
|
Control box |
1 |
InternKon: 420 120 40 / 2
|
|
|
|
03 |
411 777 40
|
Control box |
1 |
InternKon: 420 120 40 / 3
|
|
|
|
04 |
421 505 40
|
Seat base |
1 |
InternKon: 420 120 40 / 6
|
|
|
|
05 |
420 061 40
|
Cover |
1 |
InternKon: 420 120 40 / 9
|
|
|
|
06 |
421 516 40
|
Seat plate |
1 |
InternKon: 420 120 40 / 10
|
|
|
|
08 |
421 518 40
|
Instrument panel |
1 |
InternKon: 420 120 40 / 13
|
|
|
|
09 |
436 925 40
|
Air duct |
1 |
InternKon: 420 120 40 / 14
|
|
|
|
11 |
420 063 40
|
Cover |
1 |
InternKon: 420 120 40 / 20
|
|
|
|
12 |
420 065 40
|
Cover |
1 |
InternKon: 420 120 40 / 25
|
|
|
|
13 |
420 062 40
|
Cover |
1 |
InternKon: 420 120 40 / 90
|
|
|
|
14 |
501 670 98
|
Screw |
27 |
InternBDB: B 3,9x13 / 7973 | InternKon: 420 120 40 / 74
|
|
|
|
15 |
505 292 98
|
Bolt |
4 |
InternBDB: 7/16-20 UNFX 2 1/2 | InternKon: 420 120 40 / 62
|
|
|
|
16 |
320 214 99
|
Screw |
8 |
InternBDB: M6x20 /912 | InternKon: 420 120 40 / 68
|
|
|
|
18 |
307 728 99
|
Bolt |
8 |
InternBDB: M6x15 /933 | InternKon: 420 120 40 / 70
|
|
|
|
19 |
307 631 99
|
Bolt |
25 |
InternBDB: M6x10 /933 | InternKon: 420 120 40 / 71
|
|
|
|
20 |
346 499 99
|
Lock washer |
33 |
InternBDB: 6 /128 | InternKon: 420 120 40 / 82
|
|
|
|
21 |
343 853 99
|
Lock washer |
8 |
InternBDB: 6 /7980 | InternKon: 420 120 40 / 81
|
|
|
|
22 |
340 605 99
|
Washer |
4 |
InternBDB: 12 /1440 | InternKon: 420 120 40 / 84
|
|
|
|
23 |
420 127 40
|
Retainer |
2 |
InternKon: 420 120 40 / 99
|
|
|
|
24 |
505 293 98
|
Nut |
2 |
InternBDB: 7/16-20 UNF | InternKon: 420 120 40 / 77
|
|
|
|
25 |
421 548 40
|
Retainer, r.h. |
1 |
InternKon: 420 120 40 / 4
|
|
|
|
26 |
421 546 40
|
Retainer, l.h. |
1 |
InternKon: 420 120 40 / 5
|
|
|
|
27 |
318 573 99
|
Screw |
8 |
InternBDB: M4x10 /964 | InternKon: 420 120 40 / 87
|
|
|
|
28 |
255 477 40
|
Breather |
1 |
InternBDB: Hornkohl u. Wolf 13 /386 | InternKon: 420 120 40 / 56
|
|
|
|
29 |
298 561 40
|
Moulding material 10x90x120 |
1 |
InternBDB: 269 979 40 | InternKon: 420 120 40 / 52
|
|
|
|
35 |
320 974 99
|
Screw |
3 |
InternBDB: AM4x10 /84 | InternKon: 409 990 40 / 79
|
|
|
|
36 |
410 659 40
|
Base board |
1 |
InternKon: 409 990 40 / 78
|
|
