01 |
323 080 40
|
Wiper motor |
1 |
InternBDB: SWF 402 676 | InternKon: 438 095 40 / 28
|
|
|
|
02 |
414 816 40
|
Wiper linkage |
1 |
InternBDB: SWF 105 615 75 ? | InternKon: 438 095 40 / 26
|
|
|
|
03 |
226 972 40
|
Single nozzle |
1 |
InternBDB: WRD 100 078 | InternKon: 438 095 40 / 33
|
|
|
|
04 |
365 754 40
|
Rubber ring |
2 |
InternBDB: Ш 16
|
|
|
|
05 |
323 968 40
|
Lock nut |
1 |
InternBDB: SWF 911 591 | InternKon: 438 095 40 / 32
|
|
|
|
06 |
365 755 40
|
Rubber ring |
2 |
InternBDB: Ш 20
|
|
|
|
10 |
323 041 40
|
Wiper arm |
1 |
InternBDB: SWF 104 506 540 mm | InternKon: 438 095 40 / 29
|
|
|
|
11 |
323 042 40
|
Guide arm |
1 |
InternBDB: SWF 104 507 | InternKon: 438 095 40 / 27
|
|
|
|
12 |
255 938 40
|
Wiper blade |
1 |
InternBDB: SWF 111 046 600 mm | InternKon: 438 095 40 / 30
|
|
|
|
13 |
270 343 40
|
Linkage |
-2 |
InternBDB: SWF 103 101 | InternKon: 438 095 40 / 31
|
|
|
|
14 |
286 019 40
|
Retainer |
1 |
InternKon: 283 200 40 / 15
|
|
|
|
15 |
196 484 40
|
Water reservoir |
1 |
InternBDB: SWF 3,5 l | InternKon: 283 200 40 / 20
|
|
|
|
16 |
196 482 40
|
Pump |
1 |
InternBDB: SWF 24 V Nr. 500441 | InternKon: 283 200 40 / 21
|
|
|
|
17 |
307 728 99
|
Screw |
4 |
InternBDB: M6x15 /933 | InternKon: 283 200 40 / 50
|
|
|
|
18 |
332 110 99
|
Nut |
7 |
InternBDB: M 6 /934 | InternKon: 283 200 40 / 58
|
|
|
|
19 |
319 561 99
|
Screw |
2 |
InternBDB: M4x40 /912 | InternKon: 283 200 40 / 52
|
|
|
|
20 |
196 488 40
|
Hose Ш 6x500
Bulk ware, state length
required |
1 |
InternKon: 283 200 40 / 68
|
|
|
|
21 |
196 488 40
|
Hose Ш 6x4000
Bulk ware, state length
required |
1 |
InternKon: 283 200 40 / 34
|
|
|
|
22 |
269 530 40
|
Cable muff |
2 |
InternBDB: GHE 4700037 | InternKon: 283 200 40 / 25
|
|
|
|
23 |
332 442 99
|
Nut |
2 |
InternBDB: M 4/934 | InternKon: 283 200 40 / 59
|
|
|
|
24 |
346 499 99
|
Lock washer |
7 |
InternBDB: B 6 /128 | InternKon: 283 200 40 / 63
|
|
|
|
25 |
269 613 40
|
Cellular rubber 10x130x250
Bulk ware, state length
required |
1 |
InternBDB: Manke Z 125 | InternKon: 283 200 40 / 32
|
|
|
|
30 |
344 774 40
|
Wiper motor (120 ?) |
1 |
InternBDB: SWF 402 231 | InternKon: 310 045 40 / 1
|
|
|
|
31 |
414 475 40
|
Wiper arm |
1 |
InternBDB: E-ST 300 mm | InternKon: 310 045 40 / 2
|
|
|
|
32 |
269 615 40
|
Wiper blade |
1 |
InternBDB: 103 343 300 mm | InternKon: 310 045 40 / 3
|
|
|
|
33 |
323 609 40
|
Plastic washer |
2 |
InternKon: 310 045 40 / 4
|
|
|
|
34 |
323 610 40
|
Plastic washer |
2 |
InternKon: 310 045 40 / 5
|
|
