SUCTION LINES | H135S S/N 61064 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	385 743 40	Intake	1	InternKon: 439 899 40 / 1
02	385 739 40	Seal	3	InternKon: 439 899 40 / 2
03	307 823 99	Bolt	12	InternBDB: M16x35 /933 \| InternKon: 439 899 40 / 24
04	343 116 99	Lock washer	12	InternBDB: 16 /128 \| InternKon: 439 899 40 / 25
05	414 998 40	Suction hose	2	InternBDB: TL ESPA 140x320 \| InternKon: 410 878 40 / 29
06	414 999 40	Suction hose	1	InternBDB: TL ESPA 140x680 \| InternKon: 410 878 40 / 30
07	505 966 98	Clamp	6	InternBDB: 2S 156x25 \| InternKon: 410 878 40 / 31
08	374 439 99	Socket	5	InternBDB: L 28 R /3901 \| InternKon: 410 878 40 / 36
09	643 817 40	Hose assy. NW 25x1100	1	InternBDB: DOL 28 /DOL 28-45 WN 341 951 40 \| InternKon: 410 878 40 / 32
10	643 815 40	Hose assy. NW 25x1550	1	InternBDB: DOL 28 /DOL 28 WN 341 951 40 \| InternKon: 410 878 40 / 33
11	319 258 99	Bolt	4	InternBDB: M10x35 /912 10.9 \| InternKon: 410 878 40 / 35
12	502 774 98	Flange connection	1	InternBDB: GFS 34/28-L WN 223 959 40 \| InternKon: 410 878 40 / 37
13	006 720 98	O-ring	1	InternBDB: 33x3,5 B NB 90 \| InternKon: 410 878 40 / 38
14	504 827 98	Clamp	4	InternBDB: H-CS 5/38 \| InternKon: 410 878 40 / 87
15	534 004 99	Plate	2	InternBDB: DS 5 \| InternKon: 410 878 40 / 88
16	534 005 99	Plate	2	InternBDB: ES 5 \| InternKon: 410 878 40 / 89
17	308 581 99	Bolt	4	InternBDB: M10x70 /931 \| InternKon: 410 878 40 / 90
18	456 362 40	Intake	1	InternKon: 439 899 40 / 28
19	456 363 40	Intake	1	InternKon: 439 899 40 / 29
20	643 816 40	Hose assy. NW 25x1250	1	InternBDB: DOL 28 /DOL 28 WN 341 951 40 \| InternKon: 410 878 40 / 34
