PUMP AND DISTRIBUTOR GEAR ARR. | H135S S/N 61064

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

H135S S/N 61064

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Pump distributor gear	1	InternBDB: 604 779 40 \| InternKon: 456 308 40 / 1	090-2371
?		Hydraulic pump	3	InternBDB: 592 240 40 \| InternKon: 456 308 40 / 2	090-2372
?		Fan pump	1	InternBDB: 414 579 40 \| InternKon: 456 308 40 / 3	090-1807
?	635 054 40	Lube oil pump	2	InternBDB: Sauer SNP 2/25 DC 0.01 F \| InternKon: 456 308 40 / 4
?	635 056 40	Control oil pump	1	InternBDB: SNP 2/25 SC 0.01.1 F \| InternKon: 456 308 40 / 5
?	414 577 40	Adapter	3	InternBDB: BF 312 T \| InternKon: 456 308 40 / 6
?	436 070 40	Valve adapter	1	InternKon: 456 308 40 / 11
?	436 069 40	Flange	1	InternKon: 456 308 40 / 12
?	440 016 40	Non-return valve	1	InternBDB: Gestra RK 41-DN 25 \| InternKon: 456 308 40 / 13
?	634 807 40	Hose assy. NW 25x600	1	InternBDB: DOL 28 /DOL 28 WN 341 951 40 \| InternKon: 456 308 40 / 14
?	504 251 98	O-ring to fig-no. 01	3	InternBDB: 180x3
?	374 439 99	Socket	1	InternBDB: L 28 R /3901 \| InternKon: 456 308 40 / 17
?	006 895 98	Union	1	InternBDB: Voss 28-LR \| InternKon: 456 308 40 / 41
?	319 159 99	Bolt	4	InternBDB: M12x50 /912 \| InternKon: 456 308 40 / 42
?	343 112 99	Lock washer	8	InternBDB: 12 /128 \| InternKon: 456 308 40 / 39
?	308 665 99	Bolt	24	InternBDB: M20x65 /931 \| InternKon: 456 308 40 / 34
?	307 756 99	Bolt	12	InternBDB: M8x30 /933 \| InternKon: 456 308 40 / 32
?	307 806 99	Bolt	4	InternBDB: M12x40 /933 \| InternKon: 456 308 40 / 33
?	346 510 99	Lock washer	12	InternBDB: 8 /128 \| InternKon: 456 308 40 / 38
?	346 511 99	Lock washer	24	InternBDB: 20 /128 \| InternKon: 456 308 40 / 40
?		for air conditioner only	-1
?	635 055 40	Air condition pump refer to /item 03	1		116-2040b
?	757 599 73	Repair kit to fig-nos: 04,05+23	1	InternBDB: 272 000
?	765 553 73	Pilot oil pump - stage 1	-2	InternBDB: SNP2 /25 SCO 41F 172 834
?	765 554 73	Air condition pump - stage 2	-2	InternBDB: SNP2 /19 SFR 03 F 173 620
?	765 555 73	Coupling piece	-2	InternBDB: 270 486
?	764 575 73	Repair kit - stage 2	-2	InternBDB: 272 001
?	308 597 99	Bolt	4	InternBDB: M10x220 /931
?	006 657 98	O-ring to fig-no. 01	1	InternBDB: 125x3
?	504 436 98	O-ring to fig-no. 01	3	InternBDB: 35x2,5
