01 |
405 862 40
|
Cylinder, fig-nos: 02-21 |
1 |
InternBDB: E-ST
|
|
|
|
02 |
405 863 40
|
Barrel |
1 |
InternKon: 405 862 40 / 1
|
|
|
|
03 |
405 864 40
|
Piston |
1 |
InternKon: 405 862 40 / 2
|
|
|
|
04 |
405 865 40
|
Bottom |
1 |
InternKon: 405 862 40 / 3
|
|
|
|
05 |
541 261 40
|
Disk |
1 |
InternKon: 405 862 40 / 4
|
|
|
|
06 |
405 867 40
|
Spring |
1 |
InternBDB: 1,6x10x36 | InternKon: 405 862 40 / 5
|
|
|
|
07 |
405 868 40
|
Spring |
1 |
InternBDB: 2x20x225 | InternKon: 405 862 40 / 6
|
|
|
|
08 |
502 968 98
|
O-ring |
1 |
InternBDB: 18x3/NB80 | InternKon: 405 862 40 / 7
|
|
|
|
09 |
324 235 40
|
Backring |
2 |
InternBDB: Techno Parts SP01182344 | InternKon: 405 862 40 / 8
|
|
|
|
10 |
323 902 40
|
Stripper |
1 |
InternBDB: Praedifa 18x26x7/ A1N90 1035 | InternKon: 405 862 40 / 9
|
|
|
|
11 |
300 257 99
|
Angle joint |
1 |
InternBDB: AS10/71802 | InternKon: 405 862 40 / 10
|
|
|
|
12 |
319 315 99
|
Screw |
1 |
InternBDB: M6x60/912 | InternKon: 405 862 40 / 11
|
|
|
|
13 |
325 221 99
|
Thread pin |
1 |
InternBDB: M12x16/914 | InternKon: 405 862 40 / 12
|
|
|
|
14 |
307 810 99
|
Bolt |
1 |
InternBDB: M12x60/933 | InternKon: 405 862 40 / 13
|
|
|
|
15 |
332 110 99
|
Nut |
1 |
InternBDB: M6/934 | InternKon: 405 862 40 / 14
|
|
|
|
16 |
332 334 99
|
Nut |
1 |
InternBDB: M12/934 | InternKon: 405 862 40 / 15
|
|
|
|
17 |
500 383 98
|
O-ring |
1 |
InternBDB: 31,42x2,62B/ NB 90 | InternKon: 405 862 40 / 16
|
|
|
|
18 |
340 463 99
|
Washer |
1 |
InternBDB: 6,4/125 | InternKon: 405 862 40 / 17
|
|
|
|
19 |
328 262 99
|
Stud |
1 |
InternBDB: M10x25/938 | InternKon: 405 862 40 / 18
|
|
|
|
20 |
332 113 99
|
Nut |
1 |
InternBDB: M10/934 | InternKon: 405 862 40 / 19
|
|
|
|
21 |
300 258 99
|
Angle joint |
1 |
InternBDB: GE-AS16/71802 | InternKon: 405 862 40 / 20
|
|
|
|
|$$22 |
695 889 73
|
Seal kit , fig-nos: 08-10,17 |
1 |
|
|
|
|
30 |
370 313 99
|
Union |
3 |
InternBDB: DL12 /2353 | InternKon: 651 674 40 / 48
|
|
|
|
31 |
490 478 40
|
Throttle |
1 |
InternBDB: B10/Rexroth 152 066 | InternKon: 651 674 40 / 45
|
|
|
|
32 |
255 694 40
|
Plug |
1 |
InternBDB: VSTI G3/8ED | InternKon: 651 674 40 / 47
|
|
|
|
33 |
502 752 99
|
Twist union |
2 |
InternBDB: B 12-L | InternKon: 651 674 40 / 50
|
|
|
|
34 |
215 424 99
|
Pipe Ш 12
Bulk ware, state length
required |
-2 |
InternBDB: 12x1,5 /2391 | InternKon: 651 674 40 / 51
|
|
|
|
35 |
371 953 99
|
Union |
1 |
InternBDB: FFL12 /2353 | InternKon: 651 674 40 / 49
|
|
|
|
36 |
371 974 99
|
Union |
3 |
InternBDB: FFS 12 /2353 | InternKon: 651 674 40 / 52
|
|
|
|
39 |
635 344 40
|
Solenoid valve |
1 |
InternBDB: Vickers DG 4V-3-2A-M-U-H7-60-EN50 | InternKon: 651 674 40 / 43
|
|
|
|
40 |
180 325 40
|
Base plate |
1 |
InternBDB: G342/1 3/8" | InternKon: 651 674 40 / 44
|
|
|
|
41 |
508 373 40
|
Retainer |
1 |
InternKon: 651 674 40 / 46
|
|
|
|
42 |
319 125 99
|
Screw |
4 |
InternBDB: M5x30 /912 | InternKon: 651 674 40 / 15
|
|
|
|
43 |
320 214 99
|
Screw |
2 |
InternBDB: M6x20 /912 | InternKon: 651 674 40 / 16
|
|
|
|
44 |
507 025 98
|
Nut |
2 |
InternBDB: M6 /985 | InternKon: 651 674 40 / 14
|
|
|
|
45 |
500 287 98
|
O-ring |
4 |
InternBDB: 007 111 9,25x1,78
|
|
|
|
50 |
371 452 99
|
Union |
1 |
InternBDB: GE12-PL/R1/4 | InternKon: 456 311 40 / 57
|
|
|
|
51 |
643 810 40
|
Hose assy. NW 10x3000 (Cat) |
1 |
InternBDB: DOL 12 /DOL 12-90 WN 341 951 40 | InternKon: 456 311 40 / 61
|
|
|
|
52 |
643 802 40
|
Hose assy. NW 10x4000 (CU) |
1 |
InternBDB: DOL 12 /DOL 12-90 WN 341 951 40 | InternKon: 456 309 40 / 56
|
|
|
|
53 |
007 140 98
|
Union |
1 |
InternBDB: Voss 12-LM | InternKon: 646 600 40 / 60
|
|
|
|
54 |
643 884 40
|
Hose assy. NW 10x2750 |
1 |
InternBDB: DOL 12 /DOL 12 WN 341 951 40 | InternKon: 646 600 40 / 39
|
|
|
|
55 |
504 780 98
|
Clamp |
2 |
InternBDB: L-3-G-20 /3015 | InternKon: 646 600 40 / 111
|
|
|
|
56 |
533 992 99
|
Plate |
2 |
InternBDB: L-AP-K-3 /3015 | InternKon: 646 600 40 / 112
|
|
|
|
57 |
319 133 99
|
Screw |
4 |
InternBDB: M6x30 /912 | InternKon: 646 600 40 / 113
|
|
