PC170LC-11 S/N 37001-UP

Komatsu parts book diagram for PC170LC-11 S/N 37001-UP: CONTROL VALVE, 7-VALVE (24/30)(#35001-)

? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	723-57-21103	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping	1	SN: 35820-UP
	?	723-57-21101	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping	1	SN: 35653-35819 \| SCC: A2
	?	723-57-21100	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping	1	SN: 35001-35652 \| SCC: B1
	?	723-20-95400	Valve Assembly	1	SN: 35001-UP
	?	723-20-95170	Block	1	SN: 35001-UP
	?	723-20-95150	Valve	1	SN: 35001-UP
	?	723-11-18180	Spring	1	SN: 35001-UP
	?	723-11-27850	Plug	1	SN: 35001-UP
	?	07002-61023	O-ring	1	SN: 35001-UP
	?	723-20-95140	Spacer	1	SN: 35001-UP
	?	07000-B1007	O-ring	2	SN: 35001-UP
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
	?		[B1]-This shows discontinued part. The part specified in the above line is supplied instead.	-1	SN: UP

Komatsu PC170LC-11 S/N 37001-UP parts catalog PDF

CONTROL VALVE, 7-VALVE (24/30)(#35001-) (H0120-001024) in PC170LC-11 S/N 37001-UP. Diagram image and parts list.
