|$0 |
723-57-21103
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35820-UP
|
|
|
|
|$1 |
723-57-21101
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35653-35819 | SCC: A2
|
|
|
|
|$2 |
723-57-21100
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35001-35652 | SCC: B1
|
|
|
|
|$3 |
723-50-62500
|
Valve Assembly |
1 |
SN: 35001-UP
|
|
|
|
1 |
|
Block |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
2 |
|
Spool |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
3 |
723-40-71560
|
Spring |
1 |
SN: 35001-UP
|
|
|
|
4 |
702-21-55620
|
Plug |
1 |
SN: 35001-UP
|
|
|
|
5 |
723-50-61510
|
Plug |
1 |
SN: 35001-UP
|
|
|
|
6 |
07002-61423
|
O-ring |
2 |
SN: 35001-UP
|
|
|
|
7 |
723-40-73700
|
Valve, Relief |
1 |
SN: 35001-UP
|
|
|
|
8 |
702-16-57270
|
O-ring |
1 |
SN: 35001-UP
|
|
|
|
9 |
07002-61623
|
O-ring |
1 |
SN: 35001-UP
|
|
|
|
|$13 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$14 |
|
[B1]-This shows discontinued part. The part specified in the above line is supplied instead. |
-1 |
SN: UP
|
|
|
|
|$15 |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
