|$0 |
723-57-21103
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35001-UP
|
|
|
|
|$1 |
723-57-21102
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35820-35924 | SCC: A2
|
|
|
|
|$2 |
723-57-21101
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35653-35819 | SCC: A2
|
|
|
|
|$3 |
723-57-21100
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35001-35652 | SCC: B1
|
|
|
|
|$4 |
|
Valve Assembly |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
1 |
|
Valve Body |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
2 |
723-56-31770
|
O-ring |
1 |
SN: 35001-UP
|
|
|
|
3 |
723-56-31720
|
O-ring |
1 |
SN: 35001-UP
|
|
|
|
4 |
723-56-31730
|
O-ring |
1 |
SN: 35001-UP
|
|
|
|
5 |
723-56-32710
|
O-ring |
1 |
SN: 35001-UP
|
|
|
|
6 |
723-56-31740
|
Ring, Back-up |
1 |
SN: 35001-UP
|
|
|
|
7 |
07000-B1008
|
O-ring |
2 |
SN: 35001-UP
|
|
|
|
8 |
|
Spool |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
9 |
|
Plug |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
10 |
|
O-ring |
1 |
SN: 35001-UP | SCC: C1
|
|
|
|
11 |
723-56-31211
|
Retainer |
2 |
SN: 35001-UP
|
|
|
|
12 |
723-36-14110
|
Spring |
2 |
SN: 35001-UP
|
|
|
|
13 |
723-56-31510
|
Case |
2 |
SN: 35001-UP
|
|
|
|
14 |
723-56-31780
|
O-ring |
2 |
SN: 35001-UP
|
|
|
|
15 |
01252-60630
|
Bolt, Hexagon Socket Head |
4 |
SN: 35001-UP
|
|
|
|
|$20 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$21 |
|
[B1]-This shows discontinued part. The part specified in the above line is supplied instead. |
-1 |
SN: UP
|
|
|
|
|$22 |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
