PC170LC-11 S/N 37001-UP

Komatsu parts book diagram for PC170LC-11 S/N 37001-UP: CONTROL VALVE, BRACKET(#35001-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	21K-62-52190	Bracket	1	SN: 35001-UP
	?	203-62-61581	Spacer	4	SN: 35001-UP
	?	07000-13025	O-ring	8	SN: 35001-UP
	?	203-54-21110	Cushion	8	SN: 35001-UP
	?	203-62-61572	Plate	4	SN: 35001-UP
	?	01643-31645	Washer	4	SN: 35001-UP
	?	01011-81600	Bolt	4	SN: 35001-UP
	?	01643-31645	Washer	4	SN: 35001-UP
	?	01010-81640	Bolt	4	SN: 35001-UP
	?	7861-93-1891	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 36505-UP
	?	7861-93-1890	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 35893-36504 \| SCC: A2
	?	7861-93-1870	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 35001-35892 \| SCC: A1
	?	07002-61823	O-ring	1	SN: 35001-UP
	?	07049-01012	Plug	4	SN: 35001-UP
	?		[A1]-This part and the part specified in the line immediately above are interchangeable.	-1	SN: UP
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP

Komatsu PC170LC-11 S/N 37001-UP parts catalog PDF

CONTROL VALVE, BRACKET(#35001-) (H0120-001034) in PC170LC-11 S/N 37001-UP. Diagram image and parts list.
