01 |
|
Metering valve |
3 |
InternBDB: 269 880 40 | InternKon: 659 265 40 / 1
|
991-0091 |
|
|
02 |
654 130 40
|
Protection cap |
12 |
InternBDB: 83272 | InternKon: 659 265 40 / 2
|
|
|
|
03 |
215 642 99
|
Pipe Ш 12
Bulk ware, state length
required |
1 |
InternBDB: 12x2 /2391 | InternKon: 659 265 40 / 42
|
|
|
|
04 |
372 182 99
|
Union |
2 |
InternBDB: DDS 12 /2353 | InternKon: 659 265 40 / 10
|
|
|
|
05 |
512 055 98
|
Thread pin |
18 |
InternBDB: PM 12x80 /32500 | InternKon: 659 265 40 / 27
|
|
|
|
06 |
334 600 99
|
Nut |
18 |
InternBDB: M 12 /985 | InternKon: 659 265 40 / 28
|
|
|
|
07 |
373 772 99
|
Union |
2 |
InternBDB: TR 25/12/25-S | InternKon: 659 265 40 / 11
|
|
|
|
08 |
372 415 99
|
Union |
1 |
InternBDB: ES 25 /2353 | InternKon: 659 265 40 / 12
|
|
|
|
09 |
512 672 98
|
Hose assy. DN 20x4400 mm |
1 |
InternBDB: DOS 25 /DOS 25 WN 341 951 40 | InternKon: 659 265 40 / 37
|
|
|
|
11 |
659 261 40
|
Pipe assy. Ш 25 |
1 |
InternKon: 659 265 40 / 40
|
|
|
|
12 |
659 262 40
|
Pipe assy. Ш 25 |
1 |
InternKon: 659 265 40 / 41
|
|
|
|
13 |
635 896 40
|
Tube protection 12x9x1.5
Bulk ware, state length
required |
-2 |
InternBDB: 100 121 005 Baier u. Kцppel | InternKon: 659 265 40 / 15
|
|
|
|
14 |
170 427 40
|
Cable strap |
50 |
InternBDB: TY 27 M | InternKon: 659 265 40 / 23
|
|
|
|
15 |
511 565 98
|
Thread pin |
6 |
InternBDB: PM 8x50 /32500 | InternKon: 659 265 40 / 4
|
|
|
|
16 |
340 112 99
|
Washer |
6 |
InternBDB: A 18 /7989 | InternKon: 659 265 40 / 3
|
|
|
|
17 |
324 672 40
|
Plug |
2 |
InternBDB: 3/8 - NPT | InternKon: 659 265 40 / 6
|
|
|
|
18 |
334 599 99
|
Nut |
6 |
InternBDB: M 8 /985 | InternKon: 659 265 40 / 5
|
|
|
|
19 |
512 273 98
|
Socket |
2 |
InternBDB: EVGE 12-S 3/8 NPT | InternKon: 659 265 40 / 8
|
|
|
|
20 |
372 483 99
|
Union |
2 |
InternBDB: GE 12-PS /3/8 NPT | InternKon: 659 265 40 / 9
|
|
|
|
21 |
634 978 40
|
Cover plate |
10 |
InternBDB: DPAL 4S Stauffenberg | InternKon: 659 265 40 / 26
|
|
|
|
22 |
323 945 40
|
Thread pin |
50 |
InternBDB: M6x15 /32501 | InternKon: 659 265 40 / 21
|
|
|
|
23 |
373 588 99
|
Union |
12 |
InternBDB: GE-6-PL / 1/8 NPT | InternKon: 659 265 40 / 7
|
|
|
|
25 |
534 002 99
|
Weld on plate |
1 |
InternBDB: S-AP-A-2 /3015 | InternKon: 659 265 40 / 29
|
|
|
|
27 |
308 579 99
|
Bolt |
2 |
InternBDB: M10x60 /931 | InternKon: 659 265 40 / 30
|
|
|
|
28 |
006 912 98
|
Union |
12 |
InternBDB: Voss 6-SR | InternKon: 659 265 40 / 18
|
|
|
|
31 |
006 302 98
|
Clamp |
40 |
InternBDB: RSGU 1100 15/15 | InternKon: 659 265 40 / 20
|
|
|
|
32 |
534 092 99
|
Clamp |
10 |
InternBDB: RSGU 1100 8/15 | InternKon: 659 265 40 / 19
|
|
|
|
33 |
507 025 98
|
Nut |
50 |
InternBDB: M 6 /985 | InternKon: 659 265 40 / 22
|
|
|
|
34 |
651 255 40
|
Clamp |
9 |
InternBDB: TL S-2-R-25 | InternKon: 659 265 40 / 25
|
|
|
|
35 |
515 029 40
|
Hose connection 90° |
12 |
InternBDB: Lincoln 532-30739-1 | InternKon: 659 265 40 / 13
|
|
|
|
36 |
515 028 40
|
Collet |
24 |
InternBDB: 432-23031-1 | InternKon: 659 265 40 / 17
|
|
|
|
38 |
515 027 40
|
Hose connection |
12 |
InternBDB: 432-23030-1 | InternKon: 659 265 40 / 16
|
|
|
|
39 |
509 308 98
|
Locking plate |
1 |
InternBDB: SI 4 WN 011 839 99 | InternKon: 659 265 40 / 31
|
|
|
|
40 |
576 160 40
|
Plastic hose 8.4x2.1
Bulk ware, state length
required |
-2 |
InternBDB: Lincoln 504-36033-3 | InternKon: 659 265 40 / 14
|
|
