01 |
|
see page Lube stations |
2 |
InternKon: 872 260 40 / 1
|
|
|
|
02 |
208 893 40
|
Protective plug |
2 |
InternBDB: 63-6591-620 056 | InternKon: 872 260 40 / 48
|
|
|
|
03 |
509 857 98
|
Thread pin |
12 |
InternBDB: PM 12x35 / 32500 | InternKon: 872 260 40 / 11
|
|
|
|
04 |
340 467 99
|
Washer |
12 |
InternBDB: B 13 /125 | InternKon: 872 260 40 / 12
|
|
|
|
05 |
334 600 99
|
Nut |
12 |
InternBDB: M 12 /985 | InternKon: 872 260 40 / 13
|
|
|
|
06 |
653 698 40
|
Hose assy. DN 20x2000 |
1 |
InternBDB: DOS 25 /DOS 25-90 | InternKon: 872 260 40 / 19
|
|
|
|
07 |
514 228 98
|
Hose assy. DN 20x1300 |
1 |
InternBDB: DOL 22 /22-90 | InternKon: 872 260 40 / 18
|
|
|
|
08 |
640 429 40
|
Hose assy. DN 10x1460 |
1 |
InternBDB: DOL 12 /12-90 | InternKon: 872 260 40 / 16
|
|
|
|
09 |
512 716 98
|
Hose assy. DN 8x1600 |
1 |
InternBDB: DOL 10 /10-90 | InternKon: 872 260 40 / 17
|
|
|
|
10 |
323 064 40
|
Coupler plug |
2 |
InternBDB: 62-6511-308-022 | InternKon: 872 260 40 / 49
|
|
|
|
11 |
368 236 40
|
Protective plug |
2 |
InternBDB: 63-6591-310-05 | InternKon: 872 260 40 / 40
|
|
|
|
12 |
627 121 40
|
Hose assy. DN 12x1700 |
1 |
InternBDB: DOL 15 /DOL 15-90 | InternKon: 872 260 40 / 21
|
|
|
|
13 |
371 952 99
|
Union |
1 |
InternBDB: FFL 10 /2353 | InternKon: 872 260 40 / 33
|
|
|
|
14 |
372 710 99
|
Union |
1 |
InternBDB: KL 12 /2353 | InternKon: 872 260 40 / 28
|
|
|
|
15 |
515 599 98
|
Hose assy. DN 20x1100 |
1 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 872 260 40 / 39
|
|
|
|
16 |
372 589 99
|
Union |
1 |
InternBDB: RL 12 / 2353 | InternKon: 872 260 40 / 27
|
|
|
|
17 |
208 894 40
|
Coupler plug |
2 |
InternBDB: 62A-6511-4130-22 | InternKon: 872 260 40 / 41
|
|
|
|
18 |
208 897 40
|
Protective plug |
2 |
InternBDB: 63-6591-41-30 | InternKon: 872 260 40 / 42
|
|
|
|
19 |
373 732 99
|
Union |
1 |
InternBDB: TR 15/22/15-PL | InternKon: 872 260 40 / 37
|
|
|
|
22 |
372 603 99
|
Union |
2 |
InternBDB: RS 25 / 2353 | InternKon: 872 260 40 / 31
|
|
|
|
23 |
514 450 98
|
Hose assy. DN 20x1800 |
1 |
InternBDB: DOS 25 /DOS 25-90 | InternKon: 872 260 40 / 35
|
|
|
|
24 |
515 713 40
|
Union |
1 |
InternBDB: GV 15-LR | InternKon: 872 260 40 / 36
|
|
|
|
25 |
372 592 99
|
Union |
3 |
InternBDB: RL 22 / 2353 | InternKon: 872 260 40 / 29
|
|
|
|
26 |
512 685 98
|
Hose assy. DN 10x11100 |
1 |
InternBDB: DOL 12 /12-90 | InternKon: 872 258 40 / 1
|
|
|
|
27 |
514 130 98
|
Hose assy. DN 20x13300 |
1 |
InternBDB: DOL 22 /22-90 | InternKon: 872 258 40 / 2
|
|
|
|
28 |
372 173 99
|
Union |
2 |
InternBDB: DDL 15 /2353 | InternKon: 872 260 40 / 22
|
|
|
|
29 |
|
Lube filter |
2 |
InternBDB: 634 602 40 | InternKon: 872 260 40 / 2
|
090-3139 |
|
|
30 |
872 259 40
|
Retainer |
1 |
InternKon: 872 260 40 / 6
|
|
|
|
31 |
308 608 99
|
Bolt |
4 |
InternBDB: M12x70 /931 | InternKon: 872 260 40 / 7
|
|
|
|
32 |
510 741 98
|
Resilient sleeve 13/25x50 |
4 |
InternKon: 872 260 40 / 8
|
|
|
|
33 |
307 775 99
|
Bolt |
8 |
InternBDB: M10x20 /933 | InternKon: 872 260 40 / 9
|
|
|
|
34 |
346 500 99
|
Lock washer |
8 |
InternBDB: 10 /128 | InternKon: 872 260 40 / 10
|
|
|
|
35 |
372 883 99
|
Socket |
2 |
InternBDB: RI 1 x 3/4 | InternKon: 872 260 40 / 25
|
|
|
|
36 |
374 438 99
|
Socket |
2 |
InternBDB: L 22 E-G 3/4 | InternKon: 872 260 40 / 26
|
|
|
|
37 |
372 884 99
|
Socket |
4 |
InternBDB: RI 1 1/4 x 3/4 | InternKon: 872 260 40 / 39
|
|
|
|
38 |
502 682 98
|
Half clamp |
8 |
InternBDB: S-2-G-28 /3015 | InternKon: 872 260 40 / 43
|
|
|
|
39 |
514 159 98
|
Hose DN 20x460 |
1 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 872 260 40 / 20
|
|
|
|
40 |
514 114 98
|
Hose assy. DN 20x1700 |
1 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 872 260 40 / 15
|
|
|
|
41 |
515 584 40
|
Hose assy. DN 20x1900 |
1 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 872 260 40 / 14
|
|
|
|
42 |
534 002 99
|
Weld on plate |
4 |
InternBDB: S-AP-A-2 /3015 | InternKon: 872 260 40 / 44
|
|
|
|
43 |
007 143 98
|
Union |
4 |
InternBDB: Voss 22-LR | InternKon: 872 260 40 / 23
|
|
|
|
44 |
534 001 99
|
Cover plate |
4 |
InternBDB: S-DP-A-2 /3015 | InternKon: 872 260 40 / 45
|
|
|
|
45 |
308 579 99
|
Bolt |
8 |
InternBDB: M10x60 /931 | InternKon: 872 260 40 / 46
|
|
|
|
46 |
343 005 99
|
Washer |
8 |
InternBDB: 10,5 /93 | InternKon: 872 260 40 / 47
|
|
|
|
47 |
007 135 98
|
Union |
1 |
InternBDB: Voss28-LM | InternKon: 872 258 40 / 18
|
|
|
|
48 |
514 482 98
|
Union |
1 |
InternBDB: RED 28/22 | InternKon: 872 258 40 / 19
|
|
|
|
49 |
515 765 98
|
Union |
1 |
InternBDB: Red 12/10-PL | InternKon: 872 260 40 / 34
|
|
|
|
50 |
372 171 99
|
Union |
1 |
InternBDB: DDL 10 /2353
|
|
|
|
51 |
372 175 99
|
Union |
2 |
InternBDB: DDL 22 /2353
|
|
|
|
52 |
372 185 99
|
Union |
4 |
InternBDB: DDS 20 /2353
|
|
|
|
53 |
371 977 99
|
Union |
2 |
InternBDB: FFS 20 /2353
|
|
|
|
54 |
372 981 99
|
Union |
1 |
InternBDB: KOR 25/20
|
|
