01 |
|
Metering valve |
10 |
InternBDB: 269 881 40 | InternKon: 886 379 40 / 3
|
991-0323 |
|
|
02 |
634 775 40
|
Clamp |
20 |
InternBDB: Staufenberg DM 50,8 M 12 | InternKon: 886 379 40 / 4
|
|
|
|
03 |
511 885 98
|
Thread pin |
40 |
InternBDB: PM 12x90 /32500 | InternKon: 886 379 40 / 11
|
|
|
|
04 |
006 912 98
|
Union |
8 |
InternBDB: Voss 6-SR | InternKon: 886 379 40 / 2
|
|
|
|
05 |
334 600 99
|
Nut |
44 |
InternBDB: M 12 /985 | InternKon: 886 379 40 / 13
|
|
|
|
06 |
576 160 40
|
Hose DN 4
Bulk ware, state length
required |
-2 |
InternKon: 886 379 40 / 9
|
|
|
|
07 |
372 456 99
|
Union |
2 |
InternBDB: DS 6 /2353 | InternKon: 886 379 40 / 5
|
|
|
|
08 |
007 139 98
|
Union |
10 |
InternBDB: Voss 8 LR | InternKon: 886 379 40 / 27
|
|
|
|
09 |
372 170 99
|
Union |
10 |
InternBDB: DDL 8 /2353 | InternKon: 886 379 40 / 22
|
|
|
|
10 |
576 270 40
|
Union |
10 |
InternBDB: GE 6-PL /1/4 NPT | InternKon: 886 379 40 / 20
|
|
|
|
11 |
515 028 40
|
Collet |
20 |
InternBDB: 432-23031-1 | InternKon: 886 379 40 / 6
|
|
|
|
12 |
515 027 40
|
Hose connection |
8 |
InternBDB: 432-23030-1 | InternKon: 886 379 40 / 7
|
|
|
|
13 |
515 029 40
|
Hose connection 90° |
12 |
InternBDB: 532-30739-1 | InternKon: 886 379 40 / 8
|
|
|
|
14 |
269 888 40
|
Hose DN 12
Bulk ware, state length
required |
-2 |
InternBDB: Aeroquip FC-195-08 | InternKon: 886 379 40 / 32
|
|
|
|
15 |
006 300 98
|
Clamp |
6 |
InternBDB: RSGU 1100 10/15 | InternKon: 886 379 40 / 18
|
|
|
|
16 |
145 831 40
|
Clamp |
6 |
InternBDB: RSGU 1100 20/15 | InternKon: 886 379 40 / 19
|
|
|
|
17 |
323 945 40
|
Thread pin |
6 |
InternBDB: M6x15 /32501 | InternKon: 886 379 40 / 15
|
|
|
|
18 |
323 946 40
|
Thread pin |
6 |
InternBDB: M6x20 /32501 | InternKon: 886 379 40 / 16
|
|
|
|
19 |
332 331 99
|
Nut |
12 |
InternBDB: M 6 /934 | InternKon: 886 379 40 / 17
|
|
|
|
20 |
269 966 40
|
Socket |
4 |
InternBDB: GC 2542-08 | InternKon: 886 379 40 / 33
|
|
|
|
21 |
886 378 40
|
Distribution block |
2 |
InternKon: 886 379 40 / 1
|
|
|
|
22 |
360 806 40
|
Nipple |
2 |
InternBDB: 11.327-13-08 | InternKon: 886 379 40 / 34
|
|
|
|
23 |
372 426 99
|
Union |
2 |
InternBDB: CL 15 /2353 | InternKon: 886 379 40 / 28
|
|
|
|
24 |
370 304 99
|
Union |
2 |
InternBDB: EL 15 /2353 | InternKon: 886 379 40 / 29
|
|
|
|
25 |
371 855 99
|
Breech block |
2 |
InternBDB: 15-L | InternKon: 886 379 40 / 30
|
|
|
|
26 |
141 508 40
|
Base |
4 |
InternKon: 886 379 40 / 36
|
|
|
|
27 |
324 709 40
|
Nipple |
2 |
InternBDB: 11.331-13-08 | InternKon: 886 379 40 / 35
|
|
|
|
28 |
507 286 98
|
Thread pin |
4 |
InternBDB: PM 12x50 /32500 | InternKon: 886 379 40 / 12
|
|
|
|
29 |
635 588 40
|
Collet |
20 |
InternBDB: Tecalamit 4.126 174.1 / HAF 6,3 | InternKon: 886 379 40 / 24
|
|
|
|
30 |
635 586 40
|
Mandrel with pipe socket |
20 |
InternBDB: Tecalamit 4.126 174.1 / BE 8-L-6,3 F | InternKon: 886 379 40 / 25
|
|
|
|
31 |
635 584 40
|
Hose
Bulk ware, state length
required |
-2 |
InternBDB: Tecalamit 2.420 063.1 / AF-GE 6,3 | InternKon: 886 379 40 / 23
|
|
|
|
32 |
654 063 40
|
Socket |
10 |
InternBDB: Hansaflex VNNW 06 HL 1/2 | InternKon: 886 379 40 / 21
|
|
|
|
33 |
635 896 40
|
Tube protection
Bulk ware, state length
required |
-2 |
InternBDB: 100 121 005 Beka | InternKon: 886 379 40 / 10
|
|
|
|
34 |
340 111 99
|
Washer |
4 |
InternBDB: A 14 /7989 | InternKon: 886 379 40 / 14
|
|
|
|
35 |
504 149 98
|
Washer |
4 |
InternBDB: 13 /433 | InternKon: 886 379 40 / 26
|
|
|
|
36 |
174 411 40
|
Cable strap |
16 |
InternBDB: TY 25 M | InternKon: 886 379 40 / 31
|
|
|
|
37 |
307 631 99
|
Bolt |
4 |
InternBDB: M6x10 /933 | InternKon: 886 379 40 / 37
|
|
