ELECTRIC PARTS - CENTRAL LUBRIC. AND AUTOM. BUCKET LIMIT. | H455-SD S/N 15009

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
00		Transmitter housing	1	InternKon: 630 178 40 / 2	116-9550
01	255 034 40	Housing, empty	4	InternBDB: Bopla /17105
02	145 760 40	Socket	1	InternBDB: SBM 653-200 260
03	145 774 40	Contact element	-2	InternBDB: 653-200 760
04	047 249 40	Dust cap	1	InternBDB: 653-200 262
05	047 250 40	Plug	1	InternBDB: 653-200 268
06	145 761 40	Contact element	-2	InternBDB: 653-200 759
07	180 688 40	Spout	1	InternBDB: 7,5
08	145 763 40	Dust cap	1	InternBDB: 635-200 271
09	346 524 40	Plug	1	InternBDB: VG 95234-E- 10SL-3SN
10	356 238 40	Cable protection hose PG 9 Bulk ware, state length required	-2	InternBDB: Sievert 220.101.010
11	356 246 40	Socket	4	InternBDB: Sievert 520.030.009
12	323 950 40	Cable union PG 9	1	InternBDB: 5010.100.009
13	471 861 99	Cable Bulk ware, state length required	-2	InternBDB: 1 qmm bl 1qmm bl
14	323 413 40	Cable (for cold weather design) Bulk ware, state length required	-2	InternBDB: SIF 1 qmm bl SIF 1qmm bl
15	356 240 40	Cable protection hose PG 13,5 Bulk ware, state length required	-2	InternBDB: 220.101.015 \| InternKon: 630 179 40 / 13
16	356 248 40	Socket	-2	InternBDB: 520.030.013 \| InternKon: 630 179 40 / 11
17	323 952 40	Cable union PG 13,5	-2	InternBDB: 5010.100.013 \| InternKon: 630 179 40 / 12
18	621 015 40	Cable 3x1 Bulk ware, state length required	-2	InternBDB: KGW 3x1 Purwill-Orange 622 224 \| InternKon: 630 179 40 / 14
19	621 016 40	Plug	1	InternBDB: Banka 332 817 /851.06.EC8-3AS-50L \| InternKon: 630 179 40 / 15
20	174 411 40	Cable strap	-2	InternBDB: TY 25 M \| InternKon: 630 179 40 / 25
