AFE47-FE 730E S/N A30512 - A30517 ROSSING URANIUM

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB8838	STATIC EXCITER PANEL, ALTERNATOR FIELD	1
?	TR1306	CAPSCREW - 1/4" - 20NC X 1"	12
?	VE7202	FLAT WASHER - 1/4"	-1
?	VE5129	BUS BAR WITH SCREW	1
?	VE5130	BUS BAR WITH SCREW	1
?	VE5131	SCREW, SL FLAT HEAD - 1/4" - 20, 1/2" LONG	2
?	VE0037	RECTIFIER WITH CLAMP	4
?	VE0301	BUS BAR	2
?	VE0302	BUS BAR	2
?	VE0297	BUS BAR WITH SCREWS	2
?	VE4905	CAPSCREW - #10 - 32NF X 1 1/4"	8
?	VS6662	FLAT WASHER - #10	-1
?	DC3101	LOCKWASHER - #10	16
?	SF2755	NUT - #10 - 32NF	10
?	VE0036	DIODE WITH CLAMP	2
?	VS7514	TERMINAL BOARD - 6 POLE	2
?	VE4904	INDICATING PLATE	2
?	VE4916	MACHINE SCREW - #10 - 32NF X 1/2"	6
?	VE7272	SEALANT (GE N-SIL 122 WHITE)	-1
?	VE4917	CABLE CLAMP - 7/16"	1
?	VE5133	CABLE, CLAMP - 1/2"	1
?	VE4921	MACHINE SCREW - #10 - 32NF X 1"	6
?	VP9525	ROLL PIN - 1/8" DIAMETER - 1/2" LONG	4
?	VE5136	PIN, SPRING DOWEL - 1/8" DIAMETER, 5/8" LONG	2
?	BF0932	SENSOR, THERMISTOR - 100,000 OHM	1
?	VE6320	CAPSCREW - 1/4" - 20NC X 1 1/8"	4
?	DC3584	LOCKWASHER - 1/4"	-1
?	VE4902	NUT - 1/4" - 20NC	-1
?	C5746	CAPSCREW - 1/4" - 20NC X 3/4"	5
?	VE4383	MACHINE SCREW - #4 - 40NC X 1/2"	4

Komatsu AFE47-FE 730E S/N A30512 - A30517 ROSSING URANIUM parts catalog PDF

PANEL - AFSE (PB8838) (64071A) in AFE47-FE 730E S/N A30512 - A30517 ROSSING URANIUM. Diagram image and parts list.
