AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE9541	SEAL, O-RING (5)	1
?	BF3732	RING, BACKUP (5)	1
?	VE9590	SEAL, O-RING (5)	1
?	VE9580	RING, BACKUP (5)	2
?	VE9583	SEAL, O-RING (5)	1
?	VE9581	RING, PISTON (5)	1
?	VE9585	SEAL, O-RING (5)	1
?	VE9582	RING, BACKUP (5)	1
?	VE9598	SEAL, O-RING (4)	1
?	VE9541	SEAL, O-RING (4)	1
?	VE9532	SEAL, SHAFT (4)	1
?	VE9539	SEAL, O-RING (4)	1
?	VE9549	GASKET (2)/(3)	1
?	VE9551	O-RING (1)/(2)/(3)	1
?	VE9586	SEAL (5)	1
?	VE9618	NOTE: (1) INCLUDED IN VE9618 GASKET/SEAL KIT.	-1
?	VE9614	(2) INCLUDED IN VE9614 PUMP GASKET/SEAL KIT.	-1
?	BF1368	(3) INCLUDED IN BF1368 VALVE PLATE KIT.	-1
?	BF1369	(4) INCLUDED IN BF1369 HOUSING KIT.	-1
?	BF3727	(5) INCLUDED IN BF3727 CONTROL PISTON KIT.	-1

Komatsu AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO parts catalog PDF

STEERING PUMP HOUSING (REAR) (PC1142) (40734) in AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO. Diagram image and parts list.
