AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	PB9881	STEERING CONTROL VALVE ASSEMBLY (SEE INDEX)	1	60104
?	HA7382	HOSE (TO PORT "L")	1
?	HA5569	HOSE (TO PORT "R" - STEERING)	1
?	HA7382	HOSE (TO PORT "T")	1
?	HA5569	HOSE (TO PORT "P" - STEERING)	1
?	WB0584	FITTING, STRAIGHT	8
?	WB0593	FITTING, STRAIGHT	1
?	WB0574	FITTING, STRAIGHT	2
?	PC1955	RETARD/BRAKE VALVE ASSEMBLY (SEE INDEX)	1	61159
?	MM0594	CAPSCREW - M8 X 1.25 X 25	8
?	MM0470	LOCKWASHER - M8	8
?	HA7331	HOSE (TO PORT "P2")	1
?	HA7331	HOSE (TO PORT "P1")	1
?	HA7331	HOSE (TO PORT "B1")	1
?	HA7331	HOSE (TO PORT "B2")	1
?	HA7389	HOSE (TO PORT "T")	1
?	HA7360	HOSE (TO PORT "PX")	1
?	HA7358	HOSE (TO PORT "LS")	1
?	EC7875	PLATE, COVER	1

Komatsu AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO parts catalog PDF

HYDRAULIC FILTER (HOIST/BRAKE COOLING) (EH1241) (60088) in AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO. Diagram image and parts list.
