PC3000-6E S/N 06262

Komatsu parts book diagram for PC3000-6E S/N 06262: INSTALLATION TOOL FOR CYLINDERS

01 02 03 04 04 05 06 06 06 07 07 07 08 08 08 09 09 10 10 11 11

	#	Part Number	Partname	Quantity	Options	Reference
	01	909 383 40	Installation tool assy. Boom cylinder	1	InternBDB: D 412 \| InternKon: 909 376 40 / 1
	02	909 379 40	Installation tool assy. Stick cylinder	1	InternBDB: D 311 \| InternKon: 909 376 40 / 2
	03	909 378 40	Installation tool assy. Bucket cylinder	1	InternBDB: D 320 \| InternKon: 909 376 40 / 3
	04	909 382 40	Half clamp	2	InternBDB: D 412 \| InternKon: 909 383 40 / 1
	05	652 962 40	Plate	2	InternBDB: 12x100x200 \| InternKon: 909 383 40 / 2
	06	308 324 99	Bolt	4	InternBDB: M 24x80 / 931 \| InternKon: 909 383 40 / 3
	07	332 359 99	Nut	4	InternBDB: M 24 / 934 \| InternKon: 909 383 40 / 4
	08	340 471 99	Washer	4	InternBDB: 25 / 125 \| InternKon: 909 383 40 / 5
	09	909 373 40	Half clamp	2	InternBDB: D 311 \| InternKon: 909 379 40 / 1
	10	480 583 40	Plate	2	InternBDB: 12x100x155 \| InternKon: 909 379 40 / 2
	11	319 442 99	Half clamp	2	InternBDB: D 320 \| InternKon: 909 378 40 / 1

Komatsu PC3000-6E S/N 06262 parts catalog PDF

INSTALLATION TOOL FOR CYLINDERS (485-4990) in PC3000-6E S/N 06262. Diagram image and parts list.
