WEAR PACKAGE BACK PANEL AND BULLCLAM 12 CBM WP3 | PC3000-6E S/N 06262

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

Diagram image 1 of 3

PC3000-6E S/N 06262

? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6E S/N 06262

? ? ?

PC3000-6E S/N 06262

? ? ?

#	Part Number	Partname	Quantity	Options
?	947 214 40	Bucket heel shroud	2	InternBDB: 130x224x917 \| InternKon: 947 213 40 / 1
?	947 215 40	Wear plate	2	InternBDB: 20x590x536 \| InternKon: 947 213 40 / 2
?	947 216 40	Wear plate	2	InternBDB: 20x677x792 \| InternKon: 947 213 40 / 3
?	947 217 40	Wear plate	4	InternBDB: 20x160x853 \| InternKon: 947 213 40 / 4
?	947 218 40	Wear plate le.	1	InternBDB: 20x80x1569 \| InternKon: 947 213 40 / 5
?	947 219 40	Wear plate ri.	1	InternBDB: 20x80x1569 \| InternKon: 947 213 40 / 6
?	946 705 40	Plate	6	InternBDB: 20x110x1080 \| InternKon: 947 213 40 / 7
?	947 220 40	Plate	2	InternBDB: 20x160x275 \| InternKon: 947 213 40 / 8
?	946 703 40	Plate	12	InternBDB: 20x100x780 \| InternKon: 947 213 40 / 9
?	538 705 40	Plate	6	InternBDB: 20x100x660 \| InternKon: 947 213 40 / 10
?	946 704 40	Plate	12	InternBDB: 20x100x130 \| InternKon: 947 213 40 / 11
?	946 702 40	Plate	6	InternBDB: 15x130x660 \| InternKon: 947 213 40 / 12
?	946 701 40	Plate	12	InternBDB: 15x130x1300 \| InternKon: 947 213 40 / 13
?	906 989 40	Bucket heel shroud	10	InternBDB: ES 6697-3HX 70-3550 \| InternKon: 947 213 40 / 14
?		Back Panel	-1
?	946 723 40	Plate	10	InternBDB: 15x100x1670 \| InternKon: 947 221 40 / 1
?	946 722 40	Plate	4	InternBDB: 15x100x1520 \| InternKon: 947 221 40 / 2
?	946 721 40	Plate	4	InternBDB: 15x100x1370 \| InternKon: 947 221 40 / 3
