01 |
|
Hydr. cylinder |
1 |
InternBDB: 915 830 40 | InternKon: KO-900 600 40 / 05 / 01
|
515-4180c |
|
|
02 |
913 963 40
|
Piping, assy. r.h.
fig-nos. 05-20 |
1 |
InternBDB: E-ST | InternKon: 913 969 40 / 02
|
|
|
|
03 |
913 962 40
|
Piping, assy. l.h.
fig-nos. 05-20 |
1 |
InternBDB: E-ST | InternKon: 913 968 40 / 03
|
|
|
|
05 |
650 489 40
|
Connecting block |
1 |
InternKon: 913 962 40 913 963 40 / 1
|
|
|
|
06 |
768 607 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 904 533 40 | InternKon: 913 962 40 913 963 40 / 2
|
|
|
|
08 |
505 440 98
|
Half clamp |
2 |
InternBDB: S4-R-65 | InternKon: 913 962 40 913 963 40 / 6
|
|
|
|
09 |
534 008 98
|
Cover plate |
2 |
InternBDB: S-DP-A-4 | InternKon: 913 962 40 913 963 40 / 7
|
|
|
|
10 |
504 448 98
|
Flange |
2 |
InternBDB: FE 6500-32/6 | InternKon: 913 962 40 913 963 40 / 3
|
|
|
|
11 |
504 449 98
|
Collar ring |
1 |
InternBDB: KO-6580-32 | InternKon: 913 962 40 913 963 40 / 4
|
|
|
|
12 |
504 461 98
|
Collar ring |
1 |
InternBDB: K-6580-32 | InternKon: 913 962 40 913 963 40 / 5
|
|
|
|
13 |
385 243 40
|
Quadring |
1 |
InternBDB: 58,1x2,79x3,2 | InternKon: 913 962 40 913 963 40 / 8
|
|
|
|
15 |
514 779 98
|
Quadring |
4 |
InternBDB: DKAR-00232-N90 | InternKon: 913 962 40 913 963 40 / 9
|
|
|
|
16 |
308 615 99
|
Bolt |
4 |
InternBDB: M12x130 /931 | InternKon: 913 962 40 913 963 40 / 12
|
|
|
|
17 |
319 323 99
|
Bolt |
4 |
InternBDB: M20x90 /912 | InternKon: 913 962 40 913 963 40 / 10
|
|
|
|
18 |
319 351 99
|
Bolt |
4 |
InternBDB: M16x160 /912 | InternKon: 913 962 40 913 963 40 / 11
|
|
|
|
20 |
509 310 98
|
Lock Washer |
1 |
InternBDB: SI 6 | InternKon: 913 962 40 913 963 40 / 13
|
|
|
|
28 |
307 523 99
|
Bolt |
2 |
InternBDB: M 12x16/ 8.8/ 933
|
|
