01 |
900 599 40
|
Stick, assy consist of fig. nos 2 - 10, 19, 20, 21 |
1 |
|
|
|
|
02 |
900 580 40
|
Stick ( weldment ) |
1 |
InternBDB: H 455S | InternKon: 900 599 40 / 1
|
|
|
|
03 |
936 901 40
|
Freeze-in bushing |
2 |
InternBDB: BU362 / 319x261 | InternKon: 900 599 40 / 2
|
|
|
|
04 |
908 625 40
|
Flanged bush bronze |
2 |
InternBDB: 240 | InternKon: 900 599 40 / 3
|
|
|
|
05 |
908 618 40
|
Flanged bush bronze |
2 |
InternBDB: 185 | InternKon: 900 599 40 / 4
|
|
|
|
06 |
905 213 40
|
Freeze-in bushing |
2 |
InternBDB: BU 203 / 169x201 | InternKon: 900 599 40 / 5
|
|
|
|
07 |
630 341 40
|
Freeze-in bushing |
2 |
InternBDB: BU 233 / 199x201 | InternKon: 900 599 40 / 6
|
|
|
|
08 |
907 032 40
|
Seal ring |
2 |
InternBDB: 320/7,5x4 RXYD091613T46 | InternKon: 900 599 40 / 7
|
|
|
|
09 |
907 022 40
|
Seal ring |
4 |
InternBDB: 170/ 7x4 RXYD091603T46 | InternKon: 900 599 40 / 8
|
|
|
|
10 |
907 024 40
|
Seal ring |
4 |
InternBDB: 200/7x4 RXYD091605T46 | InternKon: 900 599 40 / 9
|
|
|
|
15 |
937 015 40
|
Pin |
2 |
InternKon: 924 979 40 / 3
|
|
|
|
16 |
887 374 40
|
Retainer |
2 |
InternKon: 924 979 40 / 4
|
|
|
|
17 |
340 472 99
|
Washer |
4 |
InternBDB: A 31 / 140 HV / 125 | InternKon: 924 979 40 / 6
|
|
|
|
18 |
302 552 99
|
Bolt |
4 |
InternBDB: M30x120 / 931 | InternKon: 924 979 40 / 5
|
|
|
|
19 |
908 664 40
|
Ring |
2 |
InternBDB: 430x330x15 | InternKon: 900 599 40 / 10
|
|
|
|
20 |
907 374 40
|
Clevis |
2 |
InternBDB: C14 VC-Sch 4,0 / 7984331 RUD | InternKon: 900 599 40 / 11
|
|
|
|
21 |
932 749 40
|
Link oval |
2 |
InternBDB: A40 15T Globus | InternKon: 900 599 40 / 12
|
|
|
|
40 |
937 016 40
|
Pin |
2 |
InternBDB: 530 | InternKon: 913 968 40 / 3
|
|
|
|
41 |
637 549 40
|
Achsel stirrup |
2 |
InternKon: 913 968 40 / 4
|
|
|
|
42 |
308 353 99
|
Bolt |
4 |
InternBDB: M36x140 10.9 / 931 | InternKon: 913 968 40 / 5
|
|
|
|
43 |
340 523 99
|
Washer |
4 |
InternBDB: B 37 140HV | InternKon: 913 968 40 / 7
|
|
