Hydr. cylinder |
2 |
InternBDB: 902 700 40 | InternKon: 904 559 40 / 01
|
515-4280c |
|
|
? |
911 392 40
|
Piping, assy. r.h.
fig-nos. 05-26 |
1 |
InternBDB: E-ST
|
|
|
|
? |
911 393 40
|
Piping, assy. l.h.
fig-nos. 05-26 |
1 |
InternBDB: E-ST
|
|
|
|
? |
911 398 40
|
Clamp clip |
1 |
InternBDB: 406 | InternKon: 911 393 40 / 1
|
|
|
|
? |
904 548 40
|
Retainer |
1 |
InternBDB: 406 , 680 | InternKon: 911 393 40 / 2
|
|
|
|
? |
399 344 40
|
Connecting block 2 |
1 |
InternBDB: 148x152 | InternKon: 911 393 40 / 3
|
|
|
|
? |
650 489 40
|
Connecting block 2" 80x80 |
1 |
InternBDB: 146x162 | InternKon: 911 393 40 / 4
|
|
|
|
? |
792 295 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 911 396 40 | InternKon: 911 393 40 / 5
|
|
|
|
? |
792 296 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 911 394 40 | InternKon: 911 393 40 / 6
|
|
|
|
? |
512 101 98
|
Half clamp |
6 |
InternBDB: S-5-R-65 | InternKon: 911 393 40 / 7
|
|
|
|
? |
500 398 98
|
Cover plate |
7 |
InternBDB: S-DP-A-5 | InternKon: 911 393 40 / 8
|
|
|
|
? |
504 448 98
|
Flange |
4 |
InternBDB: FE 6500-32/6 | InternKon: 911 393 40 / 9
|
|
|
|
? |
504 449 98
|
Collar ring |
2 |
InternBDB: KO-6580-32 | InternKon: 911 393 40 / 10
|
|
|
|
? |
504 461 98
|
Collar ring |
2 |
InternBDB: K-6580-32 | InternKon: 911 393 40 / 11
|
|
|
|
? |
385 243 40
|
Quadring |
2 |
InternBDB: 58,1x2,79x3,2 NBR 90 | InternKon: 911 393 40 / 12
|
|
|
|
? |
367 135 99
|
O-ring |
1 |
InternBDB: 67x4 B NB 90 | InternKon: 911 393 40 / 13
|
|
|
|
? |
007 697 98
|
O-ring |
1 |
InternBDB: 69,4x3,53 B NB 90 | InternKon: 911 393 40 / 14
|
|
|
|
? |
319 323 99
|
Bolt |
8 |
InternBDB: M20x90 /912 | InternKon: 911 393 40 / 15
|
|
|
|
? |
319 351 99
|
Bolt |
4 |
InternBDB: M16x160 /912 | InternKon: 911 393 40 / 17
|
|
|
|
? |
319 212 99
|
Bolt |
4 |
InternBDB: M16x150 /912 | InternKon: 911 393 40 / 16
|
|
|
|
? |
304 357 99
|
Bolt |
2 |
InternBDB: M16x160 / 10.9 | InternKon: 911 393 40 / 18
|
|
|
|
? |
308 421 99
|
Bolt |
4 |
InternBDB: M16x180 / 10.9 | InternKon: 911 393 40 / 19
|
|
|
|
? |
334 601 99
|
Nut |
8 |
InternBDB: M16 / 8 | InternKon: 911 393 40 / 20
|
|
|
|
? |
340 469 99
|
Washer |
2 |
InternBDB: Ш 17 / 140HV | InternKon: 911 393 40 / 21
|
|
