01 |
|
Switch cabinet |
1 |
InternBDB: 947 314 40 / 952 411 40 | InternKon: 947 320 40 / 3
|
991-0877 |
|
|
02 |
939 923 40
|
Switch cabinet ZSB |
1 |
InternBDB: 939 922 40 SK | InternKon: 945 725 40 / 9
|
|
|
|
03 |
308 395 99
|
Bolt (Standard) |
16 |
InternBDB: M 30x190 /931
|
|
|
|
04 |
516 587 98
|
Bolt (Cold weather design) |
16 |
InternBDB: M 30x190 /931 | InternKon: 945 725 40 / 13
|
|
|
|
05 |
255 057 40
|
Washer |
4 |
InternBDB: 31 / 55x45 / 34194840 | InternKon: 945 725 40 / 18
|
|
|
|
06 |
308 341 99
|
Bolt (Standard) |
4 |
InternBDB: M 30x230 /931
|
|
|
|
07 |
501 139 98
|
Bolt (Cold weather design) |
4 |
InternBDB: M 30x230 /931 | InternKon: 945 725 40 / 17
|
|
|
|
08 |
621 707 40
|
Resilient sleeve |
16 |
InternBDB: 31 | InternKon: 945 725 40 / 16
|
|
|
|
09 |
340 465 99
|
Washer |
12 |
InternBDB: SHB B 10,5 140HV DIN 00125 | InternKon: 946 463 40 / 1
|
|
|
|
10 |
946 210 40
|
Retainer assy. |
1 |
InternKon: 946 463 40 / 2
|
|
|
|
11 |
513 917 98
|
Bolt |
10 |
InternBDB: M10 X 20 10.9 A2E DIN 00933 | InternKon: 946 463 40 / 3
|
|
|
|
12 |
946 209 40
|
Retainer assy. |
4 |
InternKon: 946 463 40 / 4
|
|
|
|
13 |
081 480 40
|
Hinge pin |
5 |
InternBDB: GHE 6010048 ST | InternKon: 946 463 40 / 5
|
|
|
|
14 |
655 530 40
|
Strab |
5 |
InternKon: 946 463 40 / 6
|
|
|
|
15 |
534 004 99
|
Cover plate |
6 |
InternBDB: S-DP-A-3 W1 DIN 03015 | InternKon: 946 463 40 / 7
|
|
|
|
16 |
516 095 98
|
Clamp set |
6 |
InternBDB: S-3-G-42 PA DIN 03015 | InternKon: 946 463 40 / 8
|
|
|
|
17 |
308 581 99
|
Bolt |
12 |
InternBDB: M10X 70 8.8 DIN 00931 | InternKon: 946 463 40 / 9
|
|
|
|
18 |
340 508 99
|
Disc |
3 |
InternBDB: SHB A 10,5 ST A2C DIN 00125 | InternKon: 946 463 40 / 10
|
|
|
|
19 |
2080619170
|
Clip |
3 |
InternKon: 946 463 40 / 11
|
|
|
|
20 |
507 037 98
|
Nut |
3 |
InternBDB: M10 8 DIN 00985 | InternKon: 946 463 40 / 12
|
|
|
|
21 |
308 610 99
|
Bolt |
3 |
InternBDB: M 12x80 / 931 | InternKon: 945 725 40 / 47
|
|
|
|
22 |
903 998 40
|
Plate |
1 |
InternKon: 945 725 40 / 45
|
|
|
|
23 |
334 600 99
|
Nut |
3 |
InternBDB: M 12 / 985 | InternKon: 945 725 40 / 48
|
|
