01 |
946 424 40
|
MS-Cable SS-MV assy. |
1 |
InternBDB: Elimo | InternKon: 944 797 40 / 1
|
|
|
|
02 |
946 425 40
|
MS-Cable M-K assy. |
1 |
InternBDB: Elimo | InternKon: 944 797 40 / 3
|
|
|
|
03 |
946 426 40
|
MS-Cable SRK-SS assy. |
1 |
InternBDB: Elimo | InternKon: 944 797 40 / 3
|
|
|
|
04 |
946 427 40
|
MS-Cable KK- SRK assy. |
1 |
InternBDB: Elimo | InternKon: 944 797 40 / 5
|
|
|
|
08 |
512 053 98
|
Grommet |
7 |
InternBDB: S-4-48 /3015
|
|
|
|
09 |
534 009 99
|
Weld on plate |
7 |
InternBDB: S-AP-A-4 /3015 | InternKon: 946 309 40 / 9
|
|
|
|
10 |
534 008 99
|
Cover plate |
14 |
InternBDB: S-DP-A-4 /3015 | InternKon: 946 309 40 / 10
|
|
|
|
11 |
518 265 98
|
Clamp set |
7 |
InternBDB: S-4-R-48 ,3/3015 | InternKon: 946 309 40 / 11
|
|
|
|
12 |
308 612 99
|
Bolt |
26 |
InternBDB: M12x100 /931 | InternKon: 946 309 40 / 12
|
|
|
|
13 |
903 508 40
|
Plate |
2 |
InternKon: 946 309 40 / 13
|
|
|
|
14 |
946 320 40
|
Retainer |
2 |
InternKon: 946 309 40 / 14
|
|
|
|
15 |
463 778 40
|
Angle |
1 |
InternKon: 946 309 40 / 15
|
|
|
|
16 |
431 043 40
|
Angle |
1 |
InternKon: 946 309 40 / 16
|
|
|
|
17 |
946 321 40
|
Retainer |
1 |
InternKon: 946 309 40 / 17
|
|
|
|
18 |
946 323 40
|
Retainer |
1 |
InternKon: 946 309 40 / 20
|
|
|
|
19 |
913 494 40
|
Weld on plate |
1 |
InternKon: 946 309 40 / 22
|
|
|
|
20 |
655 696 40
|
Cable protection hose DN 29 |
-2 |
|
|
|
|
21 |
655 697 40
|
Cable union DN 29 |
-2 |
InternBDB: PMA BVNV - P 299 G
|
|
|
|
22 |
509 063 98
|
Clamp set |
7 |
InternBDB: S-4-G-45/3015 | InternKon: 946 309 40 / 8
|
|
|
|
23 |
907 478 40
|
Cable union DN 17 |
1 |
InternBDB: PMA BVNV - M207 | InternKon: 939 004 40 / 3
|
|
|
|
24 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
InternKon: 939 004 40 / 1
|
|
|
|
25 |
907 641 40
|
Wire end ferrule |
32 |
InternBDB: 0,5-10 GH | InternKon: 939 004 40 / 2
|
|
|
|
26 |
256 514 40
|
Plate |
1 |
InternKon: 939 004 40 / 4
|
|
|
|
27 |
940 169 40
|
Cable |
-2 |
InternBDB: 4x1,0 | InternKon: 939 004 40 / 5
|
|
|
|
28 |
939 004 40
|
Harness - winding temperature - motor 1 |
1 |
InternKon: 946 414 40 / 6
|
|
|
|
29 |
343 006 99
|
Washer |
26 |
InternBDB: 13/93 | InternKon: 946 309 40 / 18
|
|
|
|
30 |
504 787 98
|
Catch |
7 |
InternBDB: S-4 DIN 03015
|
|
|
|
31 |
504 786 98
|
Screw |
14 |
InternBDB: S-4 DIN03015 | InternKon: 946 309 40 / 19
|
|
