ELECTRIC - CAB SUPPORT | H455S S/N 15005 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
01		Switch framing	1	InternBDB: 659 875 40 \| InternKon: 659 874 40 / 1	515-2165a
02	385 224 40	Socket	5	InternBDB: Contact 10.5830 \| InternKon: 659 874 40 / 32
03	358 264 40	Safety cover	5	InternBDB: 10.4816 \| InternKon: 659 874 40 / 35
04	358 223 40	Mounting box	-2	InternBDB: 10.4720
05	358 263 40	Safety cover	-2	InternBDB: 10.4815
06	385 225 40	Plug insert	-2	InternBDB: 10.5330 H-A 16 BS (1-16) \| InternKon: 659 874 40 / 33
07	385 226 40	Plug insert	-2	InternBDB: 10.5430 H-A 16 BS (17-32) \| InternKon: 659 874 40 / 34
08	385 227 40	Insert	-2	InternBDB: 10.5320 H-A 16 SS (1-16) \| InternKon: 659 874 40 / 141
09	385 228 40	Insert	-2	InternBDB: 10.5420 H-A 16 SS (17-32) \| InternKon: 659 874 40 / 142
10	621 748 40	Cable channel Bulk ware, state length required	-2	InternBDB: Tehalit KBL 80150 \| InternKon: 659 874 40 / 144
11	621 750 40	Cover Bulk ware, state length required	-2	InternBDB: KBA 80150 \| InternKon: 659 874 40 / 152
12	647 869 40	Plate	1	InternKon: 659 874 40 / 165
13	320 975 99	Screw	-2	InternBDB: AM 4x16 /84
14	346 508 99	Lock washer	-2	InternBDB: 4 /128
15	600 815 99	Reducing 29-21	4	InternBDB: Sievert 246 6452 H-PG 29-21/DIN 46320
16	323 354 40	Cable union	-2	InternBDB: 5010.100.021 \| InternKon: 659 874 40 / 41
17	356 250 40	Socket	-2	InternBDB: 520.030.021 \| InternKon: 659 874 40 / 45
18	256 242 40	Cable protection hose PG 21 Bulk ware, state length required	-2	InternBDB: Sievert 220.101.021 \| InternKon: 659 874 40 / 94
19	356 241 40	Cable protection hose PG 16 Bulk ware, state length required	-2	InternBDB: 220.101.017 \| InternKon: 659 874 40 / 62
20	356 249 40	Socket	-2	InternBDB: 520.030.016 \| InternKon: 659 874 40 / 72
21	323 413 40	Cable Bulk ware, state length required	-2	InternBDB: SIF 1 qmm bl.
22	270 788 40	Cable Bulk ware, state length required	-2	InternBDB: 2x0,75
23	308 977 40	Cable Bulk ware, state length required	-2	InternBDB: 1,5 qmm bl.
24	308 963 40	Cable Bulk ware, state length required	-2	InternBDB: 6 qmm sw
25	661 681 40	Plate	1	InternKon: 659 874 40 / 173
26	647 872 40	Plate	2	InternKon: 659 874 40 / 167
27	356 243 40	Cable protection hose PG 29 Bulk ware, state length required	-2	InternBDB: 220.101.029 \| InternKon: 659 874 40 / 95
28	356 251 40	Socket	-2	InternKon: 659 874 40 / 46
29	323 355 40	Cable union	-2	InternBDB: 5010.100.029 \| InternKon: 659 874 40 / 42
30	324 217 40	Mounting box	-2	InternBDB: 10.4620
31	551 474 40	Rail Bulk ware, state length required	-2	InternBDB: 111 8021 \| InternKon: 659 874 40 / 80
32	358 273 40	Series clamping	-2	InternBDB: Sievert 2255014 \| InternKon: 659 874 40 / 81
33	358 274 40	Series clamping	-2	InternBDB: 2255022 \| InternKon: 659 874 40 / 82
34	358 275 40	Adapter	-2	InternBDB: 2055 UE \| InternKon: 659 874 40 / 83
35	358 261 40	Safety cover	-2	InternBDB: 10.4695
36	661 682 40	Plate	1	InternKon: 659 874 40 / 174
37	661 678 40	Plate	1	InternKon: 659 874 40 / 172
38	635 677 40	Cable 4x1 Bulk ware, state length required	1	InternBDB: 4x1,0 KIW PURWIL-CU \| InternKon: 659 874 40 / 124
