PILOT OIL UNIT | H65 26051 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	368 162 40	Pilot oil unit, assy.	1	InternBDB: Rexroth 4TH6 T06-10 / 1 M AT-Nr.668 836
02	754 443	Repair kit - control consist. of fig-nos: 03-11	1	InternBDB: 309 325.000
03		Protection cap These parts are not sold separately	1
04		Nut These parts are not sold separately	3
05		Screw These parts are not sold separately	1
06		Disk These parts are not sold separately	2
07		Screw These parts are not sold separately	1
08		Screw These parts are not sold separately	2
09		Locking plate These parts are not sold separately	1
10		Lever half These parts are not sold separately	2
11		Adapter These parts are not sold separately	1
12	754 444	Bellow	1	InternBDB: 188 733.000
13	333 286 99	Nut	1	InternBDB: 111 366.099
14	754 445	Nut	1	InternBDB: 188 579.000
15	754 446	Shift disk	1	InternBDB: 184 060.000
16	754 447	Cardan	1	InternBDB: 184 081.001
17	754 448	Retainer	1	InternBDB: 188 767.000
18	754 449	Gasket	1	InternBDB: 188 766.000
19	754 450	Repair kit - tappet consist. of fig-nos: 20-23	1	InternBDB: 309 299.000
20		Tappet guide These parts are not sold separately	4
21		Seal ring These parts are not sold separately	4	InternBDB: 14x2
22		Seal ring These parts are not sold separately	4	InternBDB: 10x13,6x2,3
23		Tappet These parts are not sold separately	4
24	754 451	Lock pad	4	InternBDB: 180 719.001
25	754 452	Spring plate	4	InternBDB: 184 000.002
26	754 453	Compression spring	4	InternBDB: 190 036.000
27	754 454	Return spring	4	InternBDB: 184 011.001
28	994 954	Shim ring 0,1	4	InternBDB: 181 213.000
29	994 955	Shim ring 0,2	4	InternBDB: 181 214.000
30	989 568	Shim ring 0,5	4	InternBDB: 182 646.000
31		Piston These parts are not sold separately	4
32	754 455	Upper part	1	InternBDB: 187 877.001
33	500 095 98	O-ring	1	InternBDB: 14x2
34	972 166	O-ring	1	InternBDB: 59,99x2,62
35	344 969 99	Pin	2	InternBDB: 5x12 /7
36		Lower part These parts are not sold separately	1
37	504 708 98	O-ring	1	InternBDB: 13,6x2,7
38		Screw These parts are not sold separately	1	InternBDB: 191 853.000
\|$$39	754 579	Repair kit consist. of fig-nos: 33-35,37,38	-2	InternBDB: 309 759
