01 |
907 220 40
|
Control block assy. |
1 |
InternBDB: Rexroth MO-3166-2 Nr. 758 467
|
|
|
|
02 |
319 256 99
|
Bolt |
4 |
InternBDB: M10x25 /912 | InternKon: 758 467 / 19
|
|
|
|
03 |
767 743 73
|
Cover |
1 |
InternBDB: 859 615 | InternKon: 758 467 / 14
|
|
|
|
04 |
500 581 98
|
O-ring |
2 |
InternBDB: 82,14x3,53 | InternKon: 758 467 / 16
|
|
|
|
05 |
792 331 73
|
Pin |
1 |
InternBDB: 189 032 | InternKon: 758 467 / 10
|
|
|
|
06 |
994 476
|
Spring plate |
2 |
InternBDB: 152 040 | InternKon: 758 467 / 11
|
|
|
|
07 |
994 472
|
Spring |
1 |
InternBDB: 001 600 | InternKon: 758 467 / 12
|
|
|
|
08 |
994 473
|
Spring |
1 |
InternBDB: 001 599 | InternKon: 758 467 / 13
|
|
|
|
09 |
792 332 73
|
Piston |
1 |
InternBDB: 760 980 | InternKon: 758 467 / 02
|
|
|
|
10 |
754 581
|
Cover |
1 |
InternBDB: 684 393 | InternKon: 758 467 / 15
|
|
|
|
11 |
|
Pressure relief valve, 320 bar |
1 |
InternBDB: 754 542 | InternKon: 758 467 / 50
|
090-0186 |
|
|
12 |
994 471
|
Plug |
1 |
InternBDB: 147 997 | InternKon: 758 467 / 20
|
|
|
|
13 |
500 580 98
|
O-ring |
1 |
InternBDB: 44x3 | InternKon: 758 467 / 23
|
|
|
|
14 |
255 012 40
|
Spring |
1 |
InternBDB: 008 862 | InternKon: 758 467 / 22
|
|
|
|
15 |
255 011 40
|
Taper |
1 |
InternBDB: 147 996 | InternKon: 758 467 / 21
|
|
|
|
16 |
763 274 73
|
Plug |
6 |
InternBDB: 023 943 | InternKon: 758 467 / 26
|
|
|
|
17 |
971 158
|
O-ring |
6 |
InternBDB: 29x3
|
|
|
|
18 |
763 273 73
|
Plug |
3 |
InternBDB: 023 945 | InternKon: 758 467 / 27
|
|
|
|
19 |
500 582 98
|
O-ring |
3 |
InternBDB: 38x3
|
|
|
|
20 |
754 708
|
Plug |
3 |
InternBDB: 001 729 | InternKon: 758 467 / 28
|
|
|
|
21 |
319 255 99
|
Bolt |
8 |
InternBDB: M10x20 /912 10.9 | InternKon: 758 467 / 50
|
|
|
|
22 |
767 744 73
|
Plate |
2 |
InternBDB: 544 037 | InternKon: 758 467 / 54
|
|
|
|
23 |
994 484
|
Seal kit - piston axle |
1 |
InternBDB: 309 648 | InternKon: 758 467 / 800
|
|
|
|
24 |
|
Housing |
1 |
InternKon: 758 467 / 1
|
|
