MAIN PUMP CONTROL | PC5500-6 S/N 15056 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

Diagram image 1 of 2

PC5500-6 S/N 15056

01 01 01 02 03 04 07 07 08 08 09 09 10 10 10 11 12 13 13 14 20

PC5500-6 S/N 15056

01 01 01 02 03 04 07 07 08 08 09 10 10 10 11 11 12 12 12 13 20

#	Part Number	Partname	Quantity	Options
01	653 512 40	Hose assy. DN 08 x 770	6	InternBDB: 120 / DOL 10 / DOL 10 - 90 \| InternKon: 913 528 40 / 17
02	641 588 40	Hose assy. DN 16 x 850	2	InternBDB: 120 / DOL 18 / DOL 18 - 90 \| InternKon: 913 528 40 / 16
03	653 514 40	Hose assy. DN 16 x 700	2	InternBDB: 120 / DOL 18 / DOL 18 - 90 \| InternKon: 913 528 40 / 15
04	516 823 98	Hose assy. DN 16 x 1750	2	InternBDB: 120 / DOL 18 / DOL 18 - 90 \| InternKon: 913 550 40 / 14
07	907 211 40	Orifice 1.7	6	InternBDB: Vershr. GE 10-LM 10x1,5 ED mit Blende 1,7 mm \| InternKon: 913 550 40 / 29
08	516 156 98	Socket	3	InternBDB: L 10/ 3942 \| InternKon: 913 550 40 / 30
09	516 214 98	Socket	3	InternBDB: L 18-M / 3945 \| InternKon: 913 550 40 / 20
10	634 396 40	Union	6	InternBDB: RED 18/10-PL/OMD/ Ermeto \| InternKon: 913 550 40 / 26
11	374 408 99	Union	3	InternBDB: L-18 / 3901 \| InternKon: 913 550 40 / 24
12	516 169 98	Socket	4	InternBDB: L 18 / 3943 \| InternKon: 913 550 40 / 25
13	516 613 98	Union	3	InternBDB: K-L 18 \| InternKon: 913 550 40 / 21
14	516 159 98	Socket	1	InternBDB: L 18 / 3942 \| InternKon: 913 550 40 / 22
20	510 923 98	Hose assy. DN 08 x1670	1	InternBDB: 240 / DOL 10 / DOL 10 90 \| InternKon: 913 550 40 / 23
