01 |
004 398 98
|
Coupling |
1 |
InternBDB: 10-L | InternKon: 913 571 40 / 30
|
|
|
|
02 |
215 424 99
|
Pipe Ш 12 |
-2 |
InternBDB: 12x1,5 /2391 | InternKon: 913 571 40 / 31
|
|
|
|
03 |
906 347 40
|
Olive |
18 |
InternBDB: ES-4 L12 Voss 0011152000 | InternKon: 913 571 40 / 32
|
|
|
|
04 |
371 274 99
|
Union nut |
18 |
InternBDB: AL 12 /3870 | InternKon: 913 571 40 / 33
|
|
|
|
05 |
215 811 99
|
Pipe Ш 15 |
-2 |
InternBDB: 913 577 40 15x1,5 /2391 | InternKon: 913 571 40 / 34
|
|
|
|
06 |
516 192 98
|
Socket |
2 |
InternBDB: RI 1 1/4 AX 1 WN 655 908 40 | InternKon: 913 571 40 / 35
|
|
|
|
07 |
374 439 99
|
Socket |
2 |
InternBDB: L 28 E-G 1 /3901 | InternKon: 913 571 40 / 36
|
|
|
|
08 |
516 161 98
|
Socket |
2 |
InternBDB: L 28 /3942 | InternKon: 913 571 40 / 37
|
|
|
|
09 |
215 816 99
|
Pipe Ш 28 |
-2 |
InternBDB: 311 847 40 28x2,5 /2391 | InternKon: 913 571 40 / 38
|
|
|
|
10 |
906 350 40
|
Olive |
2 |
InternBDB: ES-4 L28 Voss 0011352000 | InternKon: 913 571 40 / 39
|
|
|
|
11 |
371 278 99
|
Union nut |
2 |
InternBDB: AL 28 /3870 | InternKon: 913 571 40 / 40
|
|
|
|
12 |
374 431 99
|
Socket |
2 |
InternBDB: L 28 E-M /3901 | InternKon: 913 571 40 / 41
|
|
|
|
13 |
371 459 99
|
Socket |
15 |
InternBDB: L 12 E-G 3/8 /3901 | InternKon: 913 571 40 / 42
|
|
|
|
14 |
374 412 99
|
Socket |
4 |
InternBDB: S 30 E-G 1 1/4 /3901 | InternKon: 913 571 40 / 43
|
|
|
|
15 |
516 166 98
|
Socket |
3 |
InternBDB: S 30 /3942 | InternKon: 913 571 40 / 44
|
|
|
|
16 |
516 100 98
|
Socket |
2 |
InternBDB: GZR 30/25-PS WN 655 910 40 | InternKon: 913 571 40 / 45
|
|
|
|
17 |
374 419 99
|
Socket |
2 |
InternBDB: S 25 E-G 1 /3901 | InternKon: 913 571 40 / 46
|
|
|
|
18 |
516 623 98
|
Socket |
2 |
InternBDB: S 25 G /3945 | InternKon: 913 571 40 / 47
|
|
|
|
19 |
906 763 40
|
Union |
2 |
InternBDB: TR 30/25/25 PS /OMD Ermeto | InternKon: 913 571 40 / 48
|
|
|
|
20 |
374 439 99
|
Socket |
2 |
InternBDB: L 28 E-G 1 /3901 | InternKon: 913 571 40 / 49
|
|
|
|
21 |
004 684 98
|
Coupling |
2 |
InternBDB: 25-S WN 341 985 40 | InternKon: 913 571 40 / 50
|
|
|
|
22 |
374 416 99
|
Socket |
16 |
InternBDB: L 10 E-G 1/4 /3901 | InternKon: 913 571 40 / 51
|
|
|
|
23 |
516 156 98
|
Socket |
5 |
InternBDB: L 10 /3942 | InternKon: 913 571 40 / 52
|
|
|
|
24 |
372 876 99
|
Socket |
8 |
InternBDB: RI 3/8 x 1/4 WN 010 917 99 | InternKon: 913 571 40 / 53
|
|
|
|
25 |
516 173 98
|
Socket |
8 |
InternBDB: L 10 /3944 | InternKon: 913 571 40 / 54
|
|
|
|
26 |
516 224 98
|
Socket |
2 |
InternBDB: L 10 /3943 | InternKon: 913 571 40 / 55
|
|
|
|
27 |
516 184 98
|
Socket |
5 |
InternBDB: L 12-G /3945 | InternKon: 913 571 40 / 56
|
|
|
|
28 |
516 174 98
|
Socket |
11 |
InternBDB: L 12 /3944 | InternKon: 913 571 40 / 57
|
|
|
|
29 |
635 997 40
|
Socket |
2 |
InternBDB: GR 18/12-L /OMD Ermeto | InternKon: 913 571 40 / 58
|
|
|
|
30 |
371 949 99
|
Test socket |
4 |
InternBDB: MAV-EV 12-LR WN 011 644 99 | InternKon: 913 571 40 / 59
|
|
|
|
31 |
255 694 40
|
Plug |
6 |
InternBDB: Vsti R 3/8 ED WN 341 913 40 | InternKon: 913 571 40 / 60
|
|
|
|
32 |
516 185 98
|
Socket |
1 |
InternBDB: L 18-G /3945 | InternKon: 913 571 40 / 61
|
|
|
|
33 |
516 159 98
|
Socket |
2 |
InternBDB: L 18 /3942 | InternKon: 913 571 40 / 62
|
|
|
|
34 |
634 298 40
|
Socket |
1 |
InternBDB: GR 22/18-L /OMD Ermeto | InternKon: 913 571 40 / 63
|
|
|
|
35 |
374 437 99
|
Socket |
1 |
InternBDB: L 18 E-G 1/2 /3901 | InternKon: 913 571 40 / 64
|
|
|
|
36 |
374 436 99
|
Socket |
2 |
InternBDB: L 15 E-G 1/2 /3901 | InternKon: 913 571 40 / 65
|
|
|
|
37 |
516 175 98
|
Socket |
3 |
InternBDB: L 15 /3944 | InternKon: 913 571 40 / 66
|
|
|
|
39 |
516 157 98
|
Socket |
15 |
InternBDB: L 12 /3942 | InternKon: 913 571 40 / 68
|
|
|
|
40 |
551 987 40
|
Union |
4 |
InternBDB: RED 15/12-PL /OMD Ermeto | InternKon: 913 571 40 / 69
|
|
|
|
41 |
551 442 40
|
Valve |
1 |
InternBDB: RHD 15-PL /OMD Ermeto | InternKon: 913 571 40 / 70
|
|
|
|
42 |
374 425 99
|
Socket |
1 |
InternBDB: L 42 E-G 1 1/2 /3901 | InternKon: 913 571 40 / 71
|
|
|
|
43 |
516 168 98
|
Socket |
3 |
InternBDB: L 15 /3943 | InternKon: 913 571 40 / 72
|
|
|
|
44 |
006 525 98
|
Coupling |
1 |
InternBDB: 15-L WN 341 985 40 | InternKon: 913 571 40 / 73
|
|
|
|
45 |
215 424 99
|
Pipe Ш 12 |
-2 |
InternBDB: 404 718 40 12x1,5x80 /2391 | InternKon: 913 571 40 / 75
|
|
|
|
46 |
511 015 98
|
Socket |
2 |
InternBDB: L 12 /3908 | InternKon: 913 571 40 / 76
|
|
|
|
47 |
502 752 98
|
Coupling |
1 |
InternBDB: 12-L WN 341 985 40 | InternKon: 913 571 40 / 77
|
|
|
|
48 |
371 948 99
|
Coupling |
1 |
InternBDB: MAV-EV 10-LR WN 011 644 99 | InternKon: 913 571 40 / 78
|
|
|
|
49 |
513 515 98
|
Coupling |
3 |
InternBDB: 12-L WN 341 993 40 | InternKon: 913 571 40 / 80
|
|
|
|
50 |
576 472 40
|
Socket |
2 |
InternBDB: GR 15/12-L /OMD Ermeto | InternKon: 913 571 40 / 81
|
|
|
|
51 |
343 873 40
|
Valve |
1 |
InternBDB: 12-L 690 997 Voss | InternKon: 913 571 40 / 82
|
|
|
|
52 |
551 456 40
|
Union |
1 |
InternBDB: RED 15/10-PL /OMD Ermeto | InternKon: 913 571 40 / 83
|
|
|
|
53 |
551 379 40
|
Union |
2 |
InternBDB: RED 12/10-PL /OMD Ermeto | InternKon: 913 571 40 / 84
|
|
|
|
54 |
906 348 40
|
Olive |
6 |
InternBDB: ES-4 L15 Voss 0011202000 | InternKon: 913 571 40 / 85
|
|
|
|
55 |
371 275 99
|
Union nut |
6 |
InternBDB: AL 15 /3870 | InternKon: 913 571 40 / 86
|
|
|
|
67 |
655 560 40
|
Throttle |
1 |
InternBDB: 1,0 mm 694 344 Vickers | InternKon: 913 571 40 / 103
|
|
|
|
68 |
655 426 40
|
Union |
3 |
InternBDB: GV 12-LR WN 655 906 40 | InternKon: 913 571 40 / 105
|
|
|
|
69 |
906 765 40
|
Valve |
3 |
InternBDB: RHD 12-PL /OMD Ermeto | InternKon: 913 571 40 / 106
|
|
|
|
70 |
374 407 99
|
Socket |
2 |
InternBDB: L 15 E-M /3901 | InternKon: 913 571 40 / 107
|
|
|
|
71 |
516 167 98
|
Socket |
4 |
InternBDB: L 12 /3943 | InternKon: 913 571 40 / 108
|
|
|
|
75 |
643 993 40
|
Hose assy. DN 08x400 |
1 |
InternBDB: 240 DOL 10 /DOL 10-90 WN 341 951 40 | InternKon: 913 571 40 / 112
|
|
|
|
76 |
516 307 98
|
Hose assy. DN 08x300 |
5 |
InternBDB: 050 DOL 10 /DOL 10-90 WN 341 951 40-1 | InternKon: 913 571 40 / 113
|
|
|
|
77 |
516 312 98
|
Hose assy. DN 08x850 |
1 |
InternBDB: 050 DOL 10 /DOL 10-90 WN 341 951 40-1 | InternKon: 913 571 40 / 114
|
|
|
|
78 |
516 317 98
|
Hose assy. DN 08x500 |
2 |
InternBDB: 050 DOL 10 /DOL 10-90 WN 341 951 40-1 | InternKon: 913 571 40 / 115
|
|
|
|
79 |
215 635 99
|
Pipe Ш 10 |
-2 |
InternBDB: 10x1 /2391 | InternKon: 913 571 40 / 116
|
|
|
|
83 |
514 993 98
|
Hose assy. DN 10x600 |
1 |
InternBDB: 050 DOL 12 /DOL 12 WN 341 951 40-1 | InternKon: 913 571 40 / 120
|
|
|
|
85 |
515 553 98
|
Hose assy. DN 10x700 |
1 |
InternBDB: 050 DOL 12 /DOL 12 WN 341 951 40-1 | InternKon: 913 571 40 / 123
|
|
|
|
86 |
515 750 98
|
Hose assy. DN 10x850 |
4 |
InternBDB: 050 DOL 12 /DOL 12-90 WN 341 951 40-1 | InternKon: 913 571 40 / 124
|
|
|
|
88 |
215 811 99
|
Pipe Ш 15 |
-2 |
InternBDB: 913 578 40 15x1,5 /2391 | InternKon: 913 571 40 / 126
|
|
|
|
89 |
516 308 98
|
|
1 |
InternBDB: 050 DOL 10 /DOL 10-90 WN 341 951 40-1 | InternKon: 913 571 40 / 127
|
|
|
|
90 |
510 924 98
|
Hose assy. DN 08x590 |
1 |
InternBDB: 240 DOL 10 /DOL 10-90 WN 341 951 40 | InternKon: 913 571 40 / 128
|
|
|
|
91 |
215 811 99
|
Pipe Ш 15 |
-2 |
InternBDB: 914 961 40 15x1,5 /2391 | InternKon: 913 571 40 / 129
|
|
|
|
92 |
906 930 40
|
Union |
1 |
InternBDB: Voss 28-LM /OMD | InternKon: 913 571 40 / 130
|
|
|
|
94 |
515 357 98
|
Union |
1 |
InternBDB: Red 42/15-PL WN 341 994 40 | InternKon: 913 571 40 / 132
|
|
|
|
97 |
533 985 99
|
Clamp set |
2 |
InternBDB: L-1-R-12 /3015 | InternKon: 913 571 40 / 135
|
|
|
|
98 |
533 986 99
|
Weld on plate |
2 |
InternBDB: L-AP-K-1 /3015 | InternKon: 913 571 40 / 136
|
|
|
|
99 |
320 214 99
|
Screw |
4 |
InternBDB: M6x20 /912 8.8 B2E | InternKon: 913 571 40 / 137
|
|
|
|
100 |
255 171 40
|
Plug |
1 |
InternBDB: Vsti M10x1,0 ED WN 341 913 40 | InternKon: 913 571 40 / 138
|
|
|
|
101 |
371 273 99
|
Union nut |
5 |
InternBDB: AL 30 /3870 | InternKon: 913 571 40 / 139
|
|
|
|
102 |
906 346 40
|
Olive |
5 |
InternBDB: ES-4 L10 Voss 0011102000 | InternKon: 913 571 40 / 140
|
|
|
|
103 |
516 050 98
|
Hose assy. DN 10x1090 |
1 |
InternBDB: 050 DOL 12 /DOL 12 90 WN 341 951 40-1 | InternKon: 913 571 40 / 141
|
|
|
|
104 |
517 073 98
|
Union |
1 |
InternBDB: 10 LR/OMD | InternKon: 913 571 40 / 142
|
|
|
|
105 |
911 433 40
|
Orifice D=1,00 mm |
1 |
InternKon: 913 571 40 / 143
|
|
|
|
106 |
504 369 98
|
Socket |
1 |
InternBDB: S-L12 /8434 | InternKon: 913 571 40 / 22
|
|
|
|
120 |
512 671 98
|
Hose assy. DN 10 x 5900 |
1 |
InternBDB: 240 / DOL 12 DOL 12 | InternKon: 933 976 40 / 19
|
|
|
|
123 |
512 295 98
|
Hose assy. DN10 x 1080 |
1 |
InternBDB: 240 / DOL 12 DOL 12 | InternKon: 933 976 40 / 16
|
|
|
|
124 |
513 837 98
|
Hose assy. DN16 x 5300 |
1 |
InternBDB: 120 / DOL 18 DOL 18 | InternKon: 933 976 40 / 15
|
|
|
|
126 |
647 878 40
|
Hose assy. DN10 x 990 |
1 |
InternBDB: 240 / DOL 12 DOL 12 90 | InternKon: 933 976 40 / 13
|
|
|
|
127 |
515 857 40
|
Hose assy. DN25 x 1100 |
1 |
InternBDB: 120 / DOL 28 DOL 28 90 | InternKon: 933 976 40 / 12
|
|
|
|
128 |
592 040 40
|
Hose assy. DN20 x 5000 |
1 |
InternBDB: SHL120 20X 5000 DOL 22 DOL 22 WN 34195140 | InternKon: 933 976 40 / 24
|
|
