01 |
|
Pump unit |
1 |
InternBDB: 936 534 40 | InternKon: 934 937 40 / 45
|
991-0449b |
|
|
02 |
308 556 99
|
Bolt |
3 |
InternBDB: M8x50 /931 | InternKon: 934 937 40 / 49
|
|
|
|
03 |
334 599 99
|
Nut |
3 |
InternBDB: M 8 /985 | InternKon: 934 937 40 / 56
|
|
|
|
04 |
576 471 40
|
Union |
1 |
InternBDB: Red 35/28-PL | InternKon: 934 937 40 / 104
|
|
|
|
05 |
374 460 99
|
Socket |
3 |
InternBDB: L 35 E-G 1 1/4 | InternKon: 934 937 40 / 92
|
|
|
|
06 |
943 013 40
|
Retainer |
1 |
|
|
|
|
07 |
643 814 40
|
Hose assy. DN 25x700 |
1 |
InternBDB: DOL 28 /DOL 28 | InternKon: 934 937 40 / 114
|
|
|
|
08 |
943 014 40
|
Retainer |
1 |
|
|
|
|
09 |
516 235 98
|
Socket |
1 |
InternBDB: SWDS-L22xM26x1,5 Type E /ISO 8434 | InternKon: 934 937 40 / 67
|
|
|
|
10 |
513 597 98
|
Hose assy. DN 32x560 |
1 |
InternBDB: DOL 35 /DOL 35 | InternKon: 934 937 40 / 115
|
|
|
|
11 |
516 849 98
|
Union |
1 |
InternBDB: T-L 35 ISO 08434 | InternKon: 934 937 40 / 106
|
|
|
|
12 |
516 162 98
|
Socket |
2 |
InternBDB: L 35 /3942 | InternKon: 934 937 40 / 93
|
|
|
|
13 |
516 171 98
|
Socket |
1 |
InternBDB: L 35 /3943 | InternKon: 934 937 40 / 90
|
|
|
|
14 |
516 751 98
|
Union |
3 |
InternBDB: BH-L 35 ISO 08434 | InternKon: 934 937 40 / 112
|
|
|
|
15 |
516 188 98
|
Socket |
6 |
InternBDB: L 35-G /3945 | InternKon: 934 937 40 / 109
|
|
|
|
16 |
516 753 98
|
Ball cock |
3 |
InternBDB: G11/4 MSNI /34196040 | InternKon: 934 937 40 / 108
|
|
|
|
17 |
516 473 98
|
Socket |
1 |
InternBDB: L 35 /3944 | InternKon: 934 937 40 / 107
|
|
|
|
18 |
517 999 98
|
Hose assy. DN 32x2100 |
1 |
InternBDB: DOL 35 /DOL 35-45 | InternKon: 934 937 40 / 116
|
|
|
|
19 |
507 557 98
|
Nut |
3 |
InternBDB: M45x2,0 /80705 | InternKon: 934 937 40 / 113
|
|
|
|
20 |
340 507 99
|
Washer |
6 |
InternBDB: A Ш8,4 /DIN125 | InternKon: 934 937 40 / 52
|
|
|
|
21 |
634 301 40
|
Union |
1 |
InternBDB: GR 28/22-L/OMD | InternKon: 934 937 40 / 91
|
|
|
|
22 |
516 161 98
|
Union |
1 |
InternBDB: SWE-L28 | InternKon: 934 937 40 / 105
|
|
|
|
23 |
374 422 99
|
Socket |
1 |
InternBDB: SDS-L35-M42x2 Type E | InternKon: 934 937 40 / 111
|
|
|
|
31 |
517 997 98
|
Hose assy. DN 32x2300 |
1 |
InternBDB: DOL 35 /DOL 35-45 | InternKon: 913 585 40 / 40
|
|
|
|
32 |
517 998 98
|
Hose assy. DN 32x3600 |
1 |
InternBDB: DOL 35 /DOL 35-45 | InternKon: 913 585 40 / 41
|
|
|
|
33 |
551 457 40
|
Union |
1 |
InternBDB: Red 35/22-PL /OMD | InternKon: 913 585 40 / 70
|
|
|
|
34 |
511 701 98
|
Socket |
1 |
InternBDB: L 35 /3902 | InternKon: 913 585 40 / 71
|
|
|
|
35 |
516 160 98
|
Socket |
3 |
InternBDB: L 22 /3942 | InternKon: 913 585 40 / 75
|
|
|
|
36 |
516 281 98
|
Socket |
1 |
InternBDB: L 22 /3944 | InternKon: 913 585 40 / 76
|
|
