01 |
461 516 40
|
Hydr.-pump assy. |
1 |
InternBDB: Hydromatik A7F0 80/60 R-PZB 11 417 775 AT-Nr. 669 735 73
|
|
|
|
02 |
319 161 99
|
Bolt |
1 |
InternBDB: M12x65 /912 | InternKon: 212.22.11.41 / 17
|
|
|
|
03 |
319 157 99
|
Bolt |
7 |
InternBDB: M12x35 /912 | InternKon: 212.22.11.41 / 16
|
|
|
|
04 |
806 153 73
|
Connector plate |
1 |
InternBDB: 417 492 | InternKon: 212.22.11.41 / 02
|
|
|
|
05 |
806 154 73
|
Seal |
1 |
InternBDB: 435 081 | InternKon: 212.22.11.41 / 04
|
|
|
|
06 |
806 155 73
|
Threaded pin |
1 |
InternBDB: 152 620 | InternKon: 212.22.11.41 / 08
|
|
|
|
07 |
964 767
|
Flanged nut |
2 |
InternBDB: 152 459 M 12 | InternKon: 212.22.11.41 / 12
|
|
|
|
08 |
806 156 73
|
Threaded pin |
1 |
InternBDB: 083 504 | InternKon: 212.22.11.41 / 09
|
|
|
|
09 |
|
Housing |
1 |
InternBDB: 417 717 | InternKon: 212.22.11.41 / 06
|
|
|
|
10 |
344 840 99
|
Pin |
2 |
InternBDB: 10 M6x20 /7 | InternKon: 212.22.11.41 / 18
|
|
|
|
11 |
964 732
|
Plug |
3 |
InternBDB: vsti 18x1,5 ed/sa 153 153 815 | InternKon: 212.22.11.41 / 10
|
|
|
|
12 |
806 157 73
|
Transmission assy.
consist. of fig-nos: 13-15,23-29 |
1 |
InternBDB: 410 211 | InternKon: 212.22.11.41 / 01
|
|
|
|
13 |
754 767 73
|
Control lens, clockwise rotation |
1 |
InternBDB: 419 312 | InternKon: 212.22.11.41 / 03
|
|
|
|
14 |
806 158 73
|
Regulation journal |
1 |
InternBDB: 417 664 | InternKon: 212.22.11.41 / 05
|
|
|
|
15 |
754 768 73
|
Transmission, hydr.-part
consist. of fig-nos: 16-22 |
1 |
InternBDB: 410 209
|
|
|
|
16 |
756 714 73
|
Cylinder |
1 |
InternBDB: 421 289 | InternKon: 201.22.03.90 / 01
|
|
|
|
17 |
754 770 73
|
Spring plate |
1 |
InternBDB: 412 411 | InternKon: 201.22.03.90 / 06
|
|
|
|
18 |
754 771 73
|
Cup spring |
4 |
InternBDB: 408 894 | InternKon: 201.22.03.90 / 07
|
|
|
|
19 |
754 773 73
|
Trunnion |
1 |
InternBDB: 408 762 | InternKon: 201.22.03.90 / 03
|
|
|
|
20 |
439 419 73
|
Piston with rings |
7 |
InternBDB: 425 704 +2 x 156 265 | InternKon: 201.22.03.90 / 04
|
|
|
|
21 |
753 599
|
Bolt |
14 |
InternBDB: 153 617 | InternKon: 201.22.03.90 / 12
|
|
|
|
22 |
964 750
|
Withdrawal plate |
1 |
InternBDB: 062 847 | InternKon: 201.22.03.90 / 11
|
|
|
|
23 |
756 716 73
|
Drive shaft with bearing set |
1 |
InternBDB: 270 740
|
|
|
|
24 |
342 675 99
|
Circlip |
1 |
InternBDB: 125x4 /472 | InternKon: 201.22.03.90 / 12
|
|
|
|
25 |
756 717 73
|
Support ring |
1 |
InternBDB: 156 267 | InternKon: 201.22.03.90 / 06
|
|
|
|
26 |
504 305 98
|
O-ring |
1 |
InternBDB: 120,24x3,53 248-7509 | InternKon: 201.22.03.90 / 15
|
|
|
|
27 |
180 863 40
|
Shaft seal |
1 |
InternBDB: 50x72x7 /7,5 827 SK 084 516 | InternKon: 201.22.03.90 / 14
|
|
|
|
28 |
756 718 73
|
Cover |
1 |
InternBDB: 408 870 | InternKon: 201.22.03.90 / 04
|
|
|
|
29 |
756 719 73
|
Snap ring |
1 |
InternBDB: 154 361 | InternKon: 201.22.03.90 / 13
|
|
