01 |
345 596 40
|
Hose assy. NW 32x1960 lg. |
2 |
InternBDB: TL | InternKon: 646 800 40 / 10
|
|
|
|
02 |
643 846 40
|
Hose assy. NW 32x2316 lg. |
1 |
InternBDB: FS 1 1/2 FS 1 1/2 - 90 WN 341 951 40 | InternKon: 646 800 40 / 9
|
|
|
|
03 |
697 271 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 427 943 40 | InternKon: 646 800 40 / 15
|
|
|
|
04 |
697 272 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 427 944 40 | InternKon: 646 800 40 / 16
|
|
|
|
05 |
765 414 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 508 364 40 | InternKon: 646 800 40 / 17
|
|
|
|
06 |
006 639 98
|
Half flange |
12 |
InternBDB: 40 /420 | InternKon: 646 800 40 / 74
|
|
|
|
07 |
356 209 40
|
Seal ring |
9 |
InternBDB: FR 76-5937- 2200 | InternKon: 646 800 40 / 80
|
|
|
|
08 |
319 288 99
|
Bolt |
12 |
InternBDB: M16x50 /912 | InternKon: 646 800 40 / 85
|
|
|
|
09 |
319 293 99
|
Bolt |
12 |
InternBDB: M16x100 /912 10.9 | InternKon: 646 800 40 / 87
|
|
|
|
10 |
334 601 99
|
Nut |
12 |
InternBDB: M 16 /985 | InternKon: 646 800 40 / 89
|
|
|
|
11 |
500 127 98
|
Flange |
6 |
InternBDB: FE 5000-24/6 | InternKon: 646 800 40 / 76
|
|
|
|
12 |
500 203 98
|
Collar ring |
3 |
InternBDB: KO-5060-24 | InternKon: 646 800 40 / 78
|
|
|
|
13 |
501 898 98
|
Collar ring |
3 |
InternBDB: K-5060-24 | InternKon: 646 800 40 / 77
|
|
|
|
14 |
319 289 99
|
Bolt |
12 |
InternBDB: M16x60 /912 10.9 | InternKon: 646 800 40 / 86
|
|
|
|
15 |
643 890 40
|
Hose assy. NW 50x2000 lg. |
1 |
InternBDB: FL 2 1/2 - 90 FL 2 1/2 - 90 WN 341 951 40 | InternKon: 646 800 40 / 57
|
|
|
|
16 |
643 889 40
|
Hose NW 50x1300 lg. |
1 |
InternBDB: FL 2 1/2 - 90 FL 2 1/2 - 90 WN 341 951 40 | InternKon: 646 800 40 / 140
|
|
|
|
17 |
643 888 40
|
Hose NW 50x750 lg. |
1 |
InternBDB: FL 2 1/2 - 90 FL 2 1/2 - 90 WN 341 951 40 | InternKon: 646 800 40 / 139
|
|
|
|
20 |
007 630 98
|
Half flange |
12 |
InternBDB: 60 /210 | InternKon: 646 800 40 / 72
|
|
|
|
21 |
007 697 98
|
O-ring |
6 |
InternBDB: 69,4x3,5 B NB 90 | InternKon: 646 800 40 / 81
|
|
|
|
22 |
319 157 99
|
Bolt |
24 |
InternBDB: M12x35 /912 | InternKon: 646 800 40 / 83
|
|
|
|
23 |
534 008 99
|
Plate |
12 |
InternBDB: S-DP-A-4 /3015 | InternKon: 646 800 40 / 5
|
|
|
|
24 |
502 371 98
|
Clamp |
10 |
InternBDB: S-4-E /3015 | InternKon: 646 800 40 / 6
|
|
|
|
25 |
502 624 98
|
Insert |
3 |
InternBDB: S-4-45,5 /3015 | InternKon: 646 800 40 / 7
|
|
|
|
26 |
534 009 99
|
Plate |
12 |
InternBDB: S-AP-A-4 /3015 | InternKon: 646 800 40 / 105
|
|
|
|
27 |
308 612 99
|
Bolt |
18 |
InternBDB: M12x100 /931 | InternKon: 646 800 40 / 107
|
|
|
|
28 |
502 626 98
|
Insert |
2 |
InternBDB: S-4-56,4 /3015 | InternKon: 646 800 40 / 110
|
|
|
|
29 |
502 976 98
|
Clamp |
14 |
InternBDB: S-4-R-50 /3015 | InternKon: 646 800 40 / 108
|
|
|
|
30 |
509 310 98
|
Locking plate |
14 |
InternBDB: SI 6 | InternKon: 646 800 40 / 109
|
|
|
|
31 |
308 621 99
|
Bolt |
2 |
InternBDB: M12x190 /931 | InternKon: 646 800 40 / 135
|
|
