HYDR. CONTROL | H135S S/N 61064 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
\|$$1		Graphic 1	-1
01	256 396 40	Accumulator	1	InternBDB: Integral D 2,0-150 200-1315-102-541 \| InternKon: 651 673 40 / 5
02	635 344 40	Solenoid valve	2	InternBDB: Vickers DG 4V-3-2A-M-U-H7-60-EN50 \| InternKon: 651 673 40 / 6
03	180 325 40	Base plate	2	InternBDB: G 342/1 \| InternKon: 651 673 40 / 7
04	421 532 40	Distributor	1	InternKon: 651 673 40 / 52
05	390 404 40	Manifold	1	InternKon: 651 673 40 / 28
06	126 017 40	Retainer	1	InternKon: 651 673 40 / 10
07	307 777 99	Bolt	2	InternBDB: M10x25 /933 \| InternKon: 651 673 40 / 12
08	346 500 99	Lock washer	2	InternBDB: 10 /128 \| InternKon: 651 673 40 / 13
09	319 139 99	Screw	4	InternBDB: M8x15 /912 \| InternKon: 651 673 40 / 14
10	343 854 99	Lock washer	4	InternBDB: 8 /7980 \| InternKon: 651 673 40 / 15
11	255 694 40	Plug	4	InternBDB: Vsti G 3/8 ed \| InternKon: 651 673 40 / 16
12	319 125 99	Screw	8	InternBDB: M5x30 /912 \| InternKon: 651 673 40 / 17
13	308 534 99	Screw	4	InternBDB: M6x30 /912 \| InternKon: 651 673 40 / 62
14	507 025 98	Nut	4	InternBDB: M 6 /985 \| InternKon: 651 673 40 / 63
15	332 110 99	Nut	4	InternBDB: M 6 /934 \| InternKon: 651 673 40 / 20
16	346 499 99	Lock washer	4	InternBDB: 6 /128 \| InternKon: 651 673 40 / 21
17	308 542 99	Bolt	4	InternBDB: M6x70 /931 \| InternKon: 651 673 40 / 29
18	371 453 99	Union	1	InternBDB: GE 12-PL / R 1/2 \| InternKon: 651 673 40 / 35
19	153 646 40	Test coupling	1	InternBDB: AR 1/4 \| InternKon: 651 673 40 / 41
21	643 839 40	Hose assy. DN 10x750	2	InternBDB: DOL 12 /DOL 12 - 90 WN 341 951 40 \| InternKon: 651 673 40 / 73
22	371 452 99	Union	7	InternBDB: GE 12-PL / R 1/4 \| InternKon: 651 673 40 / 34
23	370 313 99	Union	10	InternBDB: DL 12 /2353 \| InternKon: 651 673 40 / 32
24	370 312 99	Union	4	InternBDB: DL 10 /2353 \| InternKon: 651 673 40 / 31
27	643 828 40	Hose assy. DN 8x1550	2	InternBDB: DOL 10 /DOL 12 WN 341 951 40 \| InternKon: 651 673 40 / 54
28	643 829 40	Hose assy. DN 8x1250	2	InternKon: 651 673 40 / 55
29	371 953 99	Union	3	InternBDB: FFL 12 /2353 \| InternKon: 651 673 40 / 37
30	371 854 99	Breech block	3	InternBDB: Bus 12-L/S \| InternKon: 651 673 40 / 39
31	215 424 99	Pipe Ш 12 Bulk ware, state length required	-2	InternBDB: 12x1,5 /2391 \| InternKon: 651 673 40 / 42
32	515 210 40	Cube plug	4
33	348 678 40	Gasket	4
58	643 837 40	Hose assy. DN 10x600	1	InternBDB: DOL 12 /DOL 12 - 90 WN 341 951 40 \| InternKon: 651 673 40 / 71
59	619 829 40	Hose assy. DN 10x400	1	InternBDB: DOL 12 /DOL 12 - 90 WN 341 951 40 \| InternKon: 651 673 40 / 75
\|$$34		Graphic 2	-1
35	372 452 99	Union	1	InternBDB: DL 22 /2353 \| InternKon: 651 673 40 / 33
36	371 336 99	Socket	1	InternBDB: EVGE 22-PLR- ed \| InternKon: 651 673 40 / 38
37	371 347 99	Non-return valve	1	InternBDB: RHD 22-PL \| InternKon: 651 673 40 / 22
38	643 800 40	Hose assy. DN 20x800	1	InternBDB: DOL 22 /DOL 22 WN 341 951 40 \| InternKon: 646 800 40 / 68
39	652 001 40	Hose assy. DN 20x2850	1	InternBDB: DOS 25 /DOL 22 - 90 WN 341 951 40 \| InternKon: 646 800 40 / 47
40	643 843 40	Hose assy. DN 20x8430	1	InternBDB: DOL 22-90 /DOS 25 WN 341 951 40 \| InternKon: 651 673 40 / 77
41	643 844 40	Hose assy. DN 20x7650	1	InternBDB: DOL 22-90 /DOL 22 WN 341 951 40 \| InternKon: 651 673 40 / 78
42	372 452 99	Union	3	InternBDB: DL 22 /2353 \| InternKon: 646 800 40 / 53
43	007 143 98	Union	1	InternBDB: Voss 22-LR \| InternKon: 651 674 40 / 33
44	373 562 99	Socket	1	InternBDB: RI 3/4x1 \| InternKon: 651 674 40 / 28
45	372 463 99	Union	1	InternBDB: DS 25 /2353 \| InternKon: 651 674 40 / 22
46	427 949 40	Pipe assy. Ш 25	1	InternKon: 651 674 40 / 38
47	006 909 98	Union	2	InternBDB: Voss 25-SM \| InternKon: 651 674 40 / 34
48	511 718 98	Clamp	4	InternBDB: S-6-E /3015 \| InternKon: 646 800 40 / 118
49	511 194 98	Plate	4	InternBDB: S-AP-A-6 /3015 \| InternKon: 646 800 40 / 119
50	511 196 98	Plate	4	InternBDB: S-DP-A-6 /3015 \| InternKon: 646 800 40 / 129
51	308 679 99	Bolt	8	InternBDB: M20x190 /931 \| InternKon: 646 800 40 / 97
52	504 923 98	Clamp	2	InternBDB: S-3-G-32 /3015 \| InternKon: 646 800 40 / 117
53	534 005 99	Plate	2	InternBDB: S-AP-A-3 /3015 \| InternKon: 646 800 40 / 121
54	534 004 99	Plate	2	InternBDB: S-DP-A-3 /3015 \| InternKon: 646 800 40 / 122
60	308 581 99	Bolt	4	InternBDB: M10x70 /931 \| InternKon: 646 800 40 / 123
