01 |
697 695 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 457 010 40 | InternKon: 651 600 40 / 6
|
|
|
|
02 |
698 064 73
|
Pipe assy. Ш 38 |
2 |
InternBDB: 508 362 40 | InternKon: 651 600 40 / 4
|
|
|
|
03 |
764 154 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 594 134 40 | InternKon: 651 600 40 / 7
|
|
|
|
04 |
697 166 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 436 046 40 | InternKon: 651 600 40 / 8
|
|
|
|
05 |
697 167 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 436 047 40 | InternKon: 651 600 40 / 9
|
|
|
|
06 |
697 168 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 436 048 40 | InternKon: 651 600 40 / 10
|
|
|
|
07 |
764 155 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 594 135 40 | InternKon: 651 600 40 / 11
|
|
|
|
08 |
764 156 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 594 136 40 | InternKon: 651 600 40 / 12
|
|
|
|
09 |
764 157 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 594 137 40 | InternKon: 651 600 40 / 13
|
|
|
|
10 |
697 172 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 436 052 40 | InternKon: 651 600 40 / 14
|
|
|
|
11 |
764 158 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 594 138 40 | InternKon: 651 600 40 / 15
|
|
|
|
12 |
764 159 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 594 139 40 | InternKon: 651 600 40 / 16
|
|
|
|
13 |
697 175 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 436 055 40 | InternKon: 651 600 40 / 17
|
|
|
|
14 |
697 176 73
|
Pipe assy. Ш 50 |
1 |
InternBDB: 436 056 40 | InternKon: 651 600 40 / 18
|
|
|
|
15 |
500 129 98
|
Flange |
8 |
InternBDB: FE-3800-20/6 | InternKon: 651 600 40 / 25
|
|
|
|
16 |
501 871 98
|
Collar ring |
8 |
InternBDB: K-3850-20 | InternKon: 651 600 40 / 26
|
|
|
|
17 |
500 127 98
|
Flange |
24 |
InternBDB: FE-5000-24/6 | InternKon: 651 600 40 / 27
|
|
|
|
18 |
501 898 98
|
Collar ring |
24 |
InternBDB: K-5060-24 | InternKon: 651 600 40 / 28
|
|
|
|
19 |
356 210 40
|
Seal ring |
8 |
InternBDB: FR 76-5957-2200 | InternKon: 651 600 40 / 23
|
|
|
|
20 |
356 209 40
|
Seal ring |
24 |
InternBDB: FR 76-5937-2200 | InternKon: 651 600 40 / 24
|
|
|
|
21 |
319 484 99
|
Bolt |
32 |
InternBDB: M14x40 /912 | InternKon: 651 600 40 / 32
|
|
|
|
22 |
319 289 99
|
Bolt |
96 |
InternBDB: M16x60 /912 | InternKon: 651 600 40 / 33
|
|
|
|
23 |
764 245 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 608 412 40 | InternKon: 651 620 40 / 9
|
|
