PC3000-6 S/N 46174

01 02 03 04 04 05 09 100 101 102 11 12 123 124 13 13 137 15 15 16 21 22 22 23 23 24 24 26 26 26 26 29 30 33 35 36 36 36 37 37 38 39 40 41 42 43 44 45 46 46 47 48 49 50 50 51 52 52 52 52 52 52 53 54 54 55 56 57 58 58 58 59 59 59 60 61 61 61 62 62 65 65 66 69 69 81 81 99 99

#	Part Number	Partname	Quantity	Options
01	915 376 40	Pump distributor gear	1	InternBDB: L+S GFC 430 / 1007 0/6159/1007/1
02	806 759 73	Joint shaft flange	1	InternBDB: 169 343 20 2 0231 / 9042 3 \| InternKon: 0/6159/1007/1 / 02
03		Spur gear	1	InternBDB: 165 702 15 1 0306 / 9129 0 \| InternKon: 0/6159/1007/1 / 03
04		Spur gear	3	InternBDB: 165 702 16 1 0306 / 9130 1 \| InternKon: 0/6159/1007/1 / 04
05		Housing	1	InternBDB: 165 702 06 0 0125 / 9476 3 \| InternKon: 0/6159/1007/1 / 01
09	806 760 73	Spacer ring	1	InternBDB: 169 343 21 4 0403 / 9338 3 \| InternKon: 0/6159/1007/1 / 09
11		Coupler	1	InternBDB: 165 702 19 3 0343 / 9924 2 \| InternKon: 0/6159/1007/1 / 11
12	763 772 73	Bearing cover	1	InternBDB: 169 343 82 1 0582 / 9094 4 \| InternKon: 0/6159/1007/1 / 12
13	793 408 73	Cover	2	InternBDB: 165 702 21 4 0438 / 9770 0 \| InternKon: 0/6159/1007/1 / 13
15		Mounting flange	3	InternBDB: 165 702 09 0 0582 / 9128 1 \| InternKon: 0/6159/1007/1 / 15
16		Mounting flange	1	InternBDB: 165 702 12 1 0582 / 9129 1 \| InternKon: 0/6159/1007/1 / 16
21		Oil distributor	1	InternBDB: 165 702 17 2 0940 / 9214 2 \| InternKon: 0/6159/1007/1 / 21
22	806 232 73	Unit of measurement	1	InternBDB: 169 341 06 3 0940 / 9151 1 \| InternKon: 0/6159/1007/1 / 22
23	806 233 73	Seal	1	InternBDB: 10 ND 16 / DIN 2576 \| InternKon: 0/6159/1007/1 / 23
24		Dipstick	1	InternBDB: G 1/2 x 235 LSN 627 1005 \| InternKon: 0/6159/1007/1 / 24
26	501 954 98	Ball bearing	6	InternBDB: 6224 J / DIN 625 164 103 43 \| InternKon: 0/6159/1007/1 / 26
29	360 626 99	Ball bearing	1	InternBDB: 6322 M/C3 / DIN 625 164 103 82 \| InternKon: 0/6159/1007/1 / 29
30	508 999 98	Roller bearing	1	InternBDB: NJ 2220 EM / DIN 5412 164 113 18 \| InternKon: 0/6159/1007/1 / 30
33	367 090 99	Shaft seal ring	2	InternBDB: 160x190x15 A / DIN 3760 164 614 17 \| InternKon: 0/6159/1007/1 / 33
35	510 511 98	Shaft seal ring	2	InternBDB: 110x140x12 A / DIN 3760 164 613 83 \| InternKon: 0/6159/1007/1 / 35
36	508 921 98	Shaft seal ring	6	InternBDB: 115x140x12 A 164 613 04 \| InternKon: 0/6159/1007/1 / 36
37	971 154	O-ring	3	InternBDB: 170x3 DIN 3771 164 632 47 \| InternKon: 0/6159/1007/1 / 37
38	508 919 98	O-ring	3	InternBDB: 550x5, 70 Sh DIN 3771 164 633 48 \| InternKon: 0/6159/1007/1 / 38
39	504 588 98	O-ring	1	InternBDB: 410x4, 70 Sh DIN 3771 164 633 12 \| InternKon: 0/6159/1007/1 / 39
40	534 081 99	O-ring	1	InternBDB: 150x3 DIN 3771 164 632 35 \| InternKon: 0/6159/1007/1 / 40
41	006 657 98	O-ring	1	InternBDB: 125x3 70 Sh DIN 3771 164 632 01 \| InternKon: 0/6159/1007/1 / 41
42	997 670	O-ring	1	InternBDB: 40x3 70 Sh DIN 3771 164 631 22 \| InternKon: 0/6159/1007/1 / 42
43		O-ring	1	InternBDB: 93x4 70 Sh DIN 3771 164 631 87 \| InternKon: 0/6159/1007/1 / 43
44		O-ring	2	InternBDB: 35x5 70 Sh DIN 3771 164 631 15 \| InternKon: 0/6159/1007/1 / 44
45	319 281 99	Bolt	4	InternBDB: M12x110 / DIN 912 164 451 11 \| InternKon: 0/6159/1007/1 / 45
46		Bolt	24	InternBDB: M20x60 / DIN 4017 164 413 67 \| InternKon: 0/6159/1007/1 / 46
47	320 152 99	Bolt	4	InternBDB: M12x75 / DIN 912 164 451 04 \| InternKon: 0/6159/1007/1 / 47
48	504 202 98	Bolt	8	InternBDB: M16x45 / DIN 933 164 412 76 \| InternKon: 0/6159/1007/1 / 48
49	307 802 99	Bolt	6	InternBDB: M12x25 / DIN 933 164 411 93 \| InternKon: 0/6159/1007/1 / 49
50	512 831 98	Bolt	3	InternBDB: M10x25 / DIN 912 164 450 72 \| InternKon: 0/6159/1007/1 / 50
51		Screw plug	1	InternBDB: VSTI M26x1,5 A3C 164 361 64 \| InternKon: 0/6159/1007/1 / 51
52		Screw plug	12	InternBDB: M12x1,5 / DIN 908 164 361 69 \| InternKon: 0/6159/1007/1 / 52
53	180 113 40	Screw plug	1	InternBDB: VSTIR G 1/4" A3C 164 361 54 \| InternKon: 0/6159/1007/1 / 53
54	180 477 40	Screw plug	2	InternBDB: G 1/2" / DIN 910 164 442 03 \| InternKon: 0/6159/1007/1 / 54
55	508 923 98	Screw plug	1	InternBDB: G 3/4" 14 NPT/ DIN 906 164 441 01 \| InternKon: 0/6159/1007/1 / 55
56	313 314 99	Screw plug	1	InternBDB: M22x1,5 / DIN 910 164 441 86 \| InternKon: 0/6159/1007/1 / 56
57	313 126 99	Screw plug	1	InternBDB: M48x2 / DIN 910 164 441 95 \| InternKon: 0/6159/1007/1 / 57
58	313 316 99	Screw plug	2	InternBDB: M33x2 / DIN 910 164 441 94 \| InternKon: 0/6159/1007/1 / 58
59	340 294 99	Seal ring	3	InternBDB: A22x27x1,5 / DIN 7603 164 620 45 \| InternKon: 0/6159/1007/1 / 59
60	339 967 99	Seal ring	1	InternBDB: A48x55x2 / DIN 7603 164 620 58 \| InternKon: 0/6159/1007/1 / 60
61	340 323 99	Seal ring	2	InternBDB: A33x39x2 / DIN 7603 164 620 56 \| InternKon: 0/6159/1007/1 / 61
62	806 234 73	Cover plug	3	InternBDB: VK 100x12 164 512 62 \| InternKon: 0/6159/1007/1 / 62
65	342 670 99	Snap ring	3	InternBDB: 100x3 / DIN 472 164 522 65 \| InternKon: 0/6159/1007/1 / 65
66	342 707 99	Snap ring	1	InternBDB: 280x5 / DIN 472 164 523 55 \| InternKon: 0/6159/1007/1 / 66
69		Fitting	4	InternBDB: GE 8-PLM 164 372 46 \| InternKon: 0/6159/1007/1 / 69
81	806 236 73	Pipe	4	InternBDB: DIN 2391/C 169 341 08 4 0995 / 9091 1 \| InternKon: 0/6159/1007/1 / 81
99	308 604 99	Bolt	4	InternBDB: M12x50 / DIN 931 164 411 99 \| InternKon: 0/6159/1007/1 / 99
100		Flange	1	InternBDB: 165 723 27 1 0583 / 9769 0 \| InternKon: 0/6159/1007/1 / 100
101		O-ring	1	InternBDB: 59x3 / DIN 3771 164 631 34 \| InternKon: 0/6159/1007/1 / 101
102	319 155 99	Bolt	4	InternBDB: M12x25 / DIN 912 164 450 72 \| InternKon: 0/6159/1007/1 / 102
123	763 773 73	Spacer ring	1	InternBDB: GFC 385 169 343 93 4 0403 / 9343 0 1 \| InternKon: 0/6159/1007/1 / 123
124	512 711 98	O-ring	1	InternBDB: 130x4 / DIN 3771 164 632 14 \| InternKon: 0/6159/1007/1 / 124
137	770 126 73	Plug	1	InternBDB: GPN 600 B 498 164 690 57 \| InternKon: 0/6159/1007/1 / 137

Komatsu PC3000-6 S/N 46174 parts catalog PDF

PUMP DISTRIBUTOR GEAR (991-0600) in PC3000-6 S/N 46174. Diagram image and parts list.
