PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: ALTERNATOR - MOUNTING

02 03 04 04 05 07 10 13 14 15 16 17 17 18 19 20 21 22

	#	Part Number	Partname	Quantity	Options	Reference
	02		Altenator	1	InternBDB: Prestolit 150A Cummins 363 2009
	03		Bolt	1	InternBDB: 1/2- x 13 x 1 1/4 Inch / Cummins S 145 \| InternKon: EE 6030 / 1
	04	768 101 73	Washer	3	InternBDB: 1/2 Inch. / Cummins 306 73 44 \| InternKon: EE 6030 / 11
	05	796 479 73	Link, adjusting	1	InternBDB: Cummins 362 97 35 \| InternKon: EE 6030 / 14
	07	694 530	Bolt	1	InternBDB: 7/16-14 x 1 1/4 Inch / Cummins 206326 \| InternKon: EE 6030 / 10
	10	796 480 73	Pulley	1	InternBDB: Cummins 362 97 34 \| InternKon: EE 6030 / 13
	13	768 103 73	Pulley	1	InternBDB: Cummins 301 55 46 \| InternKon: PU 6002 / 2
	14	796 481 73	Resilient sleeve	2	InternBDB: Cummins 362 75 88 \| InternKon: EE 6030 / 5
	15	762 301 73	Belt	1	InternBDB: Cummins 302 46 14 \| InternKon: EE 6030 / 12
	16	792 133 73	Support, Altenator	1	InternBDB: Cummins 362 85 78 \| InternKon: EE 6030 / 6
	17	696 802 73	Washer	3	InternBDB: 7/16 / Cummins 203 760 \| InternKon: EE 6030 / 3
	18	764 533 73	Nut	1	InternBDB: 1/2-20 UNF. / Cummins 70897 \| InternKon: EE 6030 / 8
	19	768 105 73	Bolt	1	InternBDB: 1/2-20 x 6 1/2 / Cummins 158829 \| InternKon: EE 6030 / 9
	20	768 106 73	Resilient sleeve	2	InternBDB: Cummins 207509 \| InternKon: EE 6030 / 4
	21	696 803 73	Bolt	2	InternBDB: 7/16-14 UNC x 5 1/4 / S167B \| InternKon: EE 6030 / 2
	22	930 594 40	Belt protection Generator	1	InternBDB: Cummins 3633874 + Nacharbeit 796 306 73

Komatsu PC3000-6 S/N 46174 parts catalog PDF

ALTERNATOR - MOUNTING (485-1297a) in PC3000-6 S/N 46174. Diagram image and parts list.
