EXHAUST SYSTEM | PC3000-6 S/N 46174 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	912 486 40	Holding device, muffler	2	InternKon: 923 986 40 / 2
02	923 988 40	Exhaust pipe	1	InternKon: 923 986 40 / 4
03	894 302 40	Exhaust pipe assy.	2	InternKon: 923 986 40 / 3
04	923 989 40	Exhaust pipe	1	InternKon: 923 986 40 / 5
05	906 476 40	Weather protecting cap	2	InternBDB: 10" \| InternKon: 923 986 40 / 6
06	894 258 40	Strap retainer	4	InternKon: 923 986 40 / 8
07	210 976 40	Muffler	2	InternBDB: 10" MOM19-0001 \| InternKon: 923 986 40 / 1
08	635 521 40	Clamp	4	InternBDB: 10 \| InternKon: 923 986 40 / 11
09	230 179 40	Clamp	2	InternKon: 923 986 40 / 12
10	230 178 40	Clamp	2	InternKon: 923 986 40 / 13
11	635 520 40	Flex. pipe	2	InternKon: 923 986 40 / 9
12	502 434 98	Bolt	16	InternBDB: M16x90 / 933 / 10.9 \| InternKon: 923 986 40 / 17
13	510 733 98	Resilient sleeve	26	InternBDB: 17/30x50 / 34194840 \| InternKon: 923 986 40 / 14
14	332 355 99	Nut	16	InternBDB: M 16 / 934 / 10 \| InternKon: 923 986 40 / 21
15	332 336 99	Nut	26	InternBDB: M 16 / 934 / 8 \| InternKon: 923 986 40 / 20
17	307 779 99	Bolt	20	InternBDB: M10x30 /933 / 8.8 \| InternKon: 923 986 40 / 16
18	507 037 98	Nut	12	InternBDB: M 10 /985 / 8.8 \| InternKon: 923 986 40 / 18
19	307 807 99	Bolt	4	InternBDB: M12x45 /933 \| InternKon: 923 986 40 / 15
20	332 334 99	Nut	8	InternBDB: M 12 / 943 \| InternKon: 923 986 40 / 19
21	340 688 99	Washer	8	InternBDB: 17 / 7349 \| InternKon: 923 986 40 / 23
22	934 482 40	Muffler extention pipe	2	InternKon: 936 000 40 / 1
23	307 800 99	Bolt	9	InternBDB: 6KTSHR M12 X 20 8.8 DIN 00933 \| InternKon: 925 891 40 / 3
24	517 118 98	Lock washer	9	InternBDB: SG-SHB 12 STZN WN 65593840 \| InternKon: 925 891 40 / 4
25	935 272 40	Plate	2	InternKon: 923 986 40 / 10
29	340 465 99	Washer	24	InternBDB: B 10,5 /125 \| InternKon: 923 986 40 / 22
30	925 250 40	Motor heat protection, rear	1	InternKon: 925 891 40 / 1
31	942 445 40	Motor heat protection, front	1	InternKon: 925 891 40 / 2
32	308 636 99	Bolt	10	InternBDB: M16x80/931 \| InternKon: 936 000 40 / 4
35	940 017 40	Foam profile	-2	InternBDB: Gewehr, Silikon 5x40 selbstklebend \| InternKon: 923 986 40 / 24
36	942 446 40	Motor heat protection, front	1	InternKon: 925 891 40 / 5
37	942 447 40	Retainer	1	InternBDB: 30x5x149 \| InternKon: 925 891 40 / 6
38	507 037 98	Nut	4	InternBDB: M10 DIN00985 \| InternKon: 925 891 40 / 7
39	340 465 99	Washer	4	InternBDB: 10,5 DIN00125 \| InternKon: 925 891 40 / 8
