01 |
793 974 73
|
Main pump |
1 |
InternBDB: HPV 375+375 (708-2K-00011 DFL 500~) | InternKon: 926 984 40 / 2
|
|
|
|
02 |
793 982 73
|
Main pump assy. fig-nos. 01,10-16 |
1 |
InternBDB: HPV 375 + 375 + HPF 125 (708-2K-00021 DFM 500~) | InternKon: 926 984 40 / 3
|
|
|
|
03 |
793 976 73
|
Main pump assy. fig-nos. 01,12,13,20,21,24-29 |
1 |
InternBDB: HPV 375 + 375 + SAL 63 (708-2K-00031 DFN 500~) | InternKon: 926 984 40 / 4
|
|
|
|
04 |
793 975 73
|
Pump |
1 |
InternBDB: SAR (3) 56 (7051236140) | InternKon: 926 984 40 / 5
|
|
|
|
05 |
307 888 99
|
Bolt |
18 |
InternBDB: M 24x65 8.8 DIN 00933 | InternKon: 926 984 40 / 12
|
|
|
|
06 |
340 471 99
|
Washer |
18 |
InternBDB: B 25,0 | InternKon: 926 984 40 / 13
|
|
|
|
07 |
307 587 99
|
Bolt |
4 |
InternBDB: M 12x30 / DIN 933 | InternKon: 926 984 40 / 14
|
|
|
|
08 |
340 652 99
|
Washer |
4 |
InternBDB: B 13,0 DIN 125 | InternKon: 926 984 40 / 15
|
|
|
|
09 |
971 154
|
O-Ring |
3 |
InternBDB: 170x3 70 Sh / DIN 3771 | InternKon: 915 376 40 / 37
|
|
|
|
10 |
793 406 73
|
Fan pump |
1 |
InternBDB: HPF 125 (708-1G-00020)
|
|
|
|
11 |
793 977 73
|
Coupling |
1 |
InternBDB: 708-2K-19160
|
|
|
|
12 |
793 978 73
|
Seal |
2 |
InternBDB: 708-2K-19140
|
|
|
|
13 |
793 979 73
|
Snap ring |
2 |
InternBDB: 04065-06220
|
|
|
|
14 |
793 980 73
|
O-Ring |
2 |
InternBDB: 07000-A-5165
|
|
|
|
15 |
795 137 73
|
Washer |
4 |
|
|
|
|
16 |
793 981 73
|
Bolt |
4 |
InternBDB: 01010 61445
|
|
|
|
17 |
006 657 98
|
O-Ring |
1 |
InternBDB: 125x3 70Sh / DIN 3771 | InternKon: 915 376 40 / 41
|
|
|
|
18 |
796 004 73
|
Shaft seal |
3 |
InternBDB: 708-2K-12230
|
|
|
|
19 |
796 005 73
|
Spacer |
3 |
InternBDB: 887-0132-126
|
|
|
|
20 |
793 407 73
|
Gear pump |
1 |
InternBDB: 705-21-36240
|
|
|
|
21 |
793 983 73
|
Coupling |
1 |
InternBDB: 708-2K-19180
|
|
|
|
22 |
796 006 73
|
Snap ring |
3 |
InternBDB: 04065-01204
|
|
|
|
24 |
793 984 73
|
Plate |
1 |
InternBDB: 708-2K-19170
|
|
|
|
25 |
793 985 73
|
O-Ring |
1 |
InternBDB: 07000-A-2100
|
|
|
|
26 |
793 986 73
|
Bolt |
4 |
InternBDB: M14x2x55 (01010-61455)
|
|
|
|
28 |
793 988 73
|
Bolt |
2 |
InternBDB: M12x1,75x35 (07372-21235)
|
|
|
|
29 |
795 138 73
|
Washer |
2 |
|
|
