01 |
|
Lighting equipment |
-2 |
|
715-2105h |
|
|
02 |
|
Battery cables |
-2 |
|
715-2130e |
|
|
03 |
|
Cables oil tank |
-2 |
|
515-2144m |
|
|
04 |
|
Compressor arr. |
-2 |
|
715-2185c |
|
|
05 |
|
Electr. parts - ladder |
-2 |
|
715-2143d |
|
|
06 |
|
Switch cabinet arr. |
-2 |
|
715-2190h |
|
|
07 |
|
Electr. parts - movement signal |
-2 |
|
715-2152b |
|
|
08 |
|
Electric - cab support |
-2 |
|
715-2135h |
|
|
09 |
|
Cables - control blocks - h.p.-filter |
-2 |
|
715-2145e |
|
|
10 |
|
Cables - control- and filter plate front |
-2 |
|
715-2146a |
|
|
10 |
|
Cables - control- and filter plate rear |
-2 |
|
715-2147a |
|
|
11 |
|
Cables - medium voltage |
-2 |
|
715-2196f |
|
|
12 |
|
Cables - PDG |
-2 |
|
515-2155f |
|
|
13 |
906 801 40
|
Cable channel 50/50 |
-2 |
InternBDB: RSV 50.50 230 4998
|
|
|
|
14 |
919 435 40
|
Retainer |
40 |
|
|
|
|
15 |
307 727 99
|
Bolt |
40 |
InternBDB: M6x12 /933 | InternKon: 894 513 40 / 4
|
|
|
|
16 |
896 742 40
|
Cable channel 110 |
-2 |
InternBDB: Sievert RSV 110.300 230 4968
|
|
|
|
17 |
514 072 98
|
Bolt |
50 |
InternBDB: M8x12 /933 10.9
|
|
|
|
18 |
350 763 99
|
Washer |
50 |
InternBDB: R 9,0 /440
|
|
|
|
19 |
916 655 40
|
Holding device |
4 |
|
|
|
|
20 |
350 762 99
|
Washer |
40 |
InternBDB: R6,6/440 | InternKon: 894 513 40 / 6
|
|
|
|
21 |
906 413 40
|
Cable channel 50/100 |
-2 |
InternBDB: RSV 50.100 230 4965 | InternKon: 894 513 40 / 1
|
|
|
|
22 |
916 436 40
|
Holding device |
3 |
InternKon: 894 513 40 / 12
|
|
|
|
23 |
906 802 40
|
Cable channel 110/150 |
-2 |
InternBDB: RSV 110.150 230 4966 | InternKon: 894 513 40 / 2
|
|
|
|
24 |
919 438 40
|
Holding device |
2 |
InternKon: 894 513 40 / 3
|
|
|
|
25 |
919 437 40
|
Holding device |
8 |
InternKon: 894 513 40 / 13
|
|
|
|
26 |
916 658 40
|
Holding device |
2 |
|
|
|
|
27 |
|
Slip ring mounting |
1 |
|
612-2192f |
|
|
28 |
921 565 40
|
Ground cable assy. |
12 |
InternKon: 944 719 40 / 51
|
|
|
|
29 |
907 200 40
|
Cabel 30x1,0 |
-2 |
InternKon: 944 719 40 / 48
|
|
|
|
30 |
907 201 40
|
Cabel 20x2,5 |
-2 |
InternKon: 944 719 40 / 49
|
|
|
|
31 |
654 422 40
|
Cable lug 50/12 |
24 |
InternBDB: M12 106 R/12 50mm/M12 | InternKon: 921 565 40 / 1
|
|
|
|
32 |
932 691 40
|
Cable 50,0 |
-2 |
InternKon: 921 565 40 / 2
|
|
|
|
33 |
|
Lighting equipment travel unit |
-2 |
InternBDB: 944 989 40
|
715-2110 |
|
|
34 |
|
Mounting Horn |
-2 |
InternBDB: 944 987 40
|
715-2151 |
