01 |
|
Spread beam headlamp |
4 |
InternBDB: Hella 1 GA 998 534-011 896 745 40 | InternKon: 934 940 40 / 4
|
991-0377 |
|
|
02 |
340 461 99
|
Washer |
32 |
InternBDB: 5,3 /125 | InternKon: 934 940 40 / 10
|
|
|
|
03 |
507 036 98
|
Nut |
16 |
InternBDB: M 5 /985 | InternKon: 934 940 40 / 11
|
|
|
|
04 |
504 010 98
|
Bolt |
32 |
InternBDB: M5x16 /933 | InternKon: 934 940 40 / 9
|
|
|
|
05 |
910 023 40
|
Plate |
1 |
InternKon: 934 940 40 / 8
|
|
|
|
06 |
440 461 40
|
Wall socket 63A |
2 |
InternBDB: Sievert 136A 6H400V 5-pol | InternKon: 934 940 40 / 17
|
|
|
|
07 |
440 462 40
|
Plug |
2 |
InternBDB: Sievert 1114 6H 400V | InternKon: 934 940 40 / 19
|
|
|
|
08 |
321 015 99
|
Bolt |
4 |
InternBDB: M6x25/84 | InternKon: 934 940 40 / 18
|
|
|
|
09 |
440 373 40
|
Camswitch |
1 |
InternBDB: Klцckner-Mцller T02/1I 20A 3-pol. | InternKon: 934 940 40 / 7
|
|
|
|
10 |
621 314 40
|
Safety cut off |
1 |
InternBDB: Klцckner-Mцller P1-25/I-SI-SW+H/11-P1/P3Z | InternKon: 934 939 40 / 12
|
|
|
|
11 |
057 278 40
|
Socket |
2 |
InternBDB: 0352 221 001 | InternKon: 934 939 40 / 11
|
|
|
|
12 |
517 328 98
|
Reducing M25/M20 |
6 |
InternBDB: M25x1,5/M20x1,5 DIN 50262 | InternKon: 921 576 40 / 35
|
|
|
|
13 |
517 327 98
|
Reducing M20/M16 |
7 |
InternBDB: M20x1,5/M16x1,5 DIN 50262 | InternKon: 921 576 40 / 34
|
|
|
|
14 |
517 326 98
|
Reducing M16/M12 |
8 |
InternBDB: M16x1,5/M12x1,5 DIN 50262 | InternKon: 921 576 40 / 33
|
|
|
|
15 |
655 649 40
|
Protecting hose DN 10 |
-2 |
InternBDB: VCST-10B PMA | InternKon: 921 576 40 / 22
|
|
|
|
16 |
898 629 40
|
Rotaflare light yellow assy. |
1 |
|
|
|
|
17 |
898 612 40
|
Retainer |
1 |
InternKon: 898 629 40 / 1
|
|
|
|
18 |
896 497 40
|
Rotaflare light 24 yellow |
1 |
InternBDB: Hella 2 RL 006 846-01 | InternKon: 898 629 40 / 2
|
|
|
|
19 |
515 213 40
|
Cable 1,0 |
-2 |
InternKon: 898 629 40 / 7
|
|
|
|
20 |
180 322 40
|
Plug |
1 |
InternBDB: Bosch 0986 352 000 | InternKon: 898 629 40 / 5
|
|
|
|
21 |
323 960 40
|
Tab |
2 |
InternBDB: 6,3x0,8 35135 | InternKon: 898 629 40 / 6
|
|
|
|
22 |
904 476 40
|
Cable union DN 10 |
7 |
InternBDB: PMA BVNV-M120 | InternKon: 921 576 40 / 15
|
|
|
|
23 |
903 422 40
|
Plug head light assy. |
4 |
InternKon: 923 580 40 / 1
|
|
|
|
24 |
907 692 40
|
Fitting DN 16/12 |
4 |
InternBDB: BVIR-M162 | InternKon: 923 580 40 / 3
|
|
|
|
25 |
907 704 40
|
Cable union |
5 |
InternBDB: Pflitsch21650 YNPM 3x3,5 | InternKon: 923 580 40 / 4
|
|
|
|
26 |
896 521 40
|
End pin |
5 |
InternBDB: Pflitsch B0 4,0x25 916 610 40/21 | InternKon: 923 580 40 / 7
|
|
|
|
27 |
515 214 40
|
Cable 2,5 |
-2 |
InternKon: 923 580 40 / 9
|
|
|
|
28 |
056 071 40
|
Cable sleeve 2,5 |
50 |
InternKon: 923 580 40 / 8
|
|
|
|
29 |
|
Junction box |
1 |
InternBDB: 921 534 40 | InternKon: 894 522 40 / 17
|
715-2180a |
|
|
30 |
919 435 40
|
Retainer |
35 |
InternKon: 894 522 40 / 11
|
|
|
|
31 |
056 070 40
|
Cable sleeve 1,0-1,5 |
46 |
InternKon: 921 576 40 / 31
|
|
|
|
32 |
515 213 40
|
Cable 1,0 |
-2 |
InternKon: 921 576 40 / 27
|
|
|
|
33 |
919 442 40
|
Retainer |
22 |
InternKon: 894 522 40 / 14
|
|
|
|
34 |
056 059 40
|
Cable sleeve |
4 |
InternBDB: GHE 47 000 27 | InternKon: 894 522 40 / 23
|
|
|
|
35 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
InternBDB: PMA VCST-12 B | InternKon: 923 580 40 / 6
|
|
|
|
37 |
655 625 40
|
Distributor DN 12/10 |
1 |
InternBDB: BVYR-121010 TTT 916 664 40/02 | InternKon: 923 580 40 / 2
|
|
|
|
38 |
655 081 40
|
Cable 2,5 br |
-2 |
InternKon: 934 495 40 / 4
|
|
|
|
39 |
655 629 40
|
T-Distributor DN 17 |
2 |
InternBDB: PMA BFTL-171717 GGG | InternKon: 921 576 40 / 5
|
|
|
|
40 |
655 632 40
|
Pipe adapter DN 17/10 |
4 |
InternBDB: BAVR-17 G 10 T | InternKon: 921 576 40 / 9
|
|
|
|
41 |
907 478 40
|
Cable union DN 17 |
3 |
InternBDB: BVNV-P 167 G | InternKon: 921 576 40 / 17
|
|
|
|
42 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
InternBDB: VCSG-17 B | InternKon: 921 576 40 / 24
|
|
|
|
44 |
256 514 40
|
Name plate |
20 |
InternKon: 921 576 40 / 29
|
|
|
|
45 |
056 292 40
|
Cable strap |
20 |
InternBDB: TY 23 M | InternKon: 921 576 40 / 30
|
|
|
|
47 |
655 634 40
|
Pipe adapter DN 23/17 |
1 |
InternBDB: BAVR-23 G 17 G | InternKon: 921 576 40 / 11
|
|
|
|
48 |
655 630 40
|
T-Distributor DN 29/23 |
2 |
InternBDB: BFTL-292323 GGG | InternKon: 921 576 40 / 6
|
|
|
|
49 |
906 079 40
|
T-Distributor DN 29 |
2 |
InternBDB: BFTL-292929 GGG | InternKon: 921 576 40 / 7
|
|
|
|
50 |
655 631 40
|
Pipe adapter DN 12/10 |
4 |
InternBDB: BAVR-12T10T | InternKon: 921 576 40 / 10
|
|
|
|
51 |
655 809 40
|
Pipe adapter DN 29/10 |
2 |
InternBDB: BAVR-29 G 10 T | InternKon: 921 576 40 / 12
|
|
|
|
52 |
517 323 98
|
Nut |
3 |
InternBDB: M25x1,5/DIN 50262 | InternKon: 921 576 40 / 39
|
|
|
|
53 |
320 976 99
|
Screw |
12 |
InternBDB: M4x20 /84 | InternKon: 938 438 40 / 16
|
|
|
|
54 |
906 413 40
|
Cable channel |
-2 |
InternBDB: RSV 50.100 | InternKon: 894 522 40 / 15
|
|
|
|
55 |
319 914 99
|
Screw |
6 |
InternBDB: M8x16 /912 | InternKon: 894 522 40 / 12
|
|
|
|
56 |
346 510 99
|
Lock washer |
6 |
InternBDB: 8 /128 | InternKon: 894 522 40 / 13
|
|
|
|
57 |
321 010 99
|
Screw |
6 |
InternBDB: M5x25 /84 | InternKon: 938 438 40 / 17
|
|
|
|
58 |
916 658 40
|
Retainer |
3 |
InternKon: 938 438 40 / 9
|
|
|
|
59 |
635 143 40
|
Emergency switch-off |
4 |
InternBDB: Klцckner-Mцller FAK-R/V/KC11A/I | InternKon: 938 438 40 / 13
|
|
|
|
60 |
923 578 40
|
Harness - lighting equipment outer |
1 |
InternKon: 934 940 40 / 1
|
|
|
|
61 |
923 580 40
|
Harness - lighting equipment counterweight |
1 |
InternKon: 934 940 40 / 2
|
|
|
|
62 |
319 140 99
|
Bolt |
20 |
InternBDB: M8x20/912 | InternKon: 894 522 40 / 5
|
|
|
|
63 |
145 831 40
|
Clamp 20/15 |
1 |
InternBDB: RSGU 1100 20/15 | InternKon: 898 699 40 / 1
|
|
|
|
64 |
510 210 98
|
Thread pin |
30 |
InternBDB: PM 6x20 /32500 | InternKon: 898 699 40 / 2
|
|
|
|
65 |
507 025 98
|
Nut |
37 |
InternBDB: M 6 /985 | InternKon: 898 699 40 / 3
|
|
|
|
66 |
006 301 98
|
Clamp 12/15 |
17 |
InternBDB: RSGU 1100 12/15 | InternKon: 910 019 40 / 1
|
|
|
|
67 |
340 628 99
|
Washer |
20 |
InternBDB: 8/1440 | InternKon: 894 522 40 / 7
|
|
|
|
68 |
350 762 99
|
Washer |
41 |
InternBDB: 6,6 /440 | InternKon: 894 522 40 / 9
|
|
|
|
69 |
655 635 40
|
Pipe adapter DN 29/17 |
1 |
InternBDB: BAVR-29 G 17 G | InternKon: 921 576 40 / 14
|
|
|
|
70 |
655 652 40
|
Protecting hose DN 23 |
-2 |
InternBDB: VCSG-23B | InternKon: 921 576 40 / 25
|
|
|
|
71 |
655 696 40
|
Protecting hose DN 29 |
-2 |
InternBDB: VCSG-29B | InternKon: 921 576 40 / 26
|
|
|
|
72 |
655 084 40
|
Cable 6,0 br |
-2 |
InternKon: 921 550 40 / 4
|
|
|
|
73 |
655 085 40
|
Cable 6,0 gr/ge |
-2 |
InternKon: 921 550 40 / 5
|
|
|
|
74 |
940 463 40
|
Insulating tube |
-2 |
InternBDB: 7x0,7/40621 | InternKon: 921 576 40 / 38
|
|
|
|
75 |
921 576 40
|
Harness - engine housing |
1 |
InternKon: 938 432 40 / 33
|
|
|
|
76 |
551 362 40
|
Camswitch |
2 |
InternBDB: T0-1-8220/I | InternKon: 938 438 40 / 10
|
|
|
|
77 |
940 271 40
|
Cable union DN 10 |
1 |
InternBDB: BVNV-M200 | InternKon: 923 578 40 / 1
|
|
|
|
78 |
324 484 40
|
Cable end sleeve |
8 |
InternBDB: 6,0 203131-27 grÑŒn | InternKon: 921 550 40 / 1
|
|
|
|
79 |
634 135 40
|
Fluorescent lamp |
4 |
InternBDB: KE-CL-DW 6318 /24-0 | InternKon: 894 522 40 / 1
|
|
|
|
80 |
621 339 40
|
Fluorescent lamp |
7 |
InternBDB: MH-CL-DW 6336 /230-0 230V36W50HZ | InternKon: 894 522 40 / 2
|
|
|
|
81 |
764 201 73
|
Fluorescent lamp |
7 |
InternBDB: PL-L 36 W /84 /4P
|
|
|
|
82 |
766 904 73
|
Fluorescent lamp |
4 |
InternBDB: 201 884 18W
|
|
|
|
83 |
334 599 99
|
Nut |
20 |
InternBDB: M8/985 | InternKon: 894 522 40 / 6
|
|
|
|
84 |
308 284 99
|
Bolt |
2 |
InternBDB: M5x35/931 | InternKon: 894 522 40 / 19
|
|
|
|
85 |
916 654 40
|
Retainer |
2 |
InternKon: 938 438 40 / 8
|
|
|
|
86 |
592 188 40
|
Socket |
2 |
InternBDB: 16A220V | InternKon: 938 438 40 / 26
|
|
|
|
87 |
320 976 99
|
Bolt |
12 |
InternBDB: M4x20/84 | InternKon: 938 438 40 / 16
|
|
|
|
89 |
307 727 99
|
Bolt |
6 |
InternBDB: M6x12/933 | InternKon: 938 438 40 / 22
|
|
|
|
90 |
916 648 40
|
Angle |
1 |
InternKon: 938 438 40 / 24
|
|
|
|
92 |
655 621 40
|
Cable union DN 10 |
1 |
InternBDB: BVNV-P090T | InternKon: 898 629 40 / 3
|
|
|
|
93 |
934 493 40
|
Harness 3X4-4S15 |
1 |
InternKon: 944 719 40 / 64
|
|
|
|
94 |
934 494 40
|
Harness 3X4-4S15A |
1 |
InternKon: 944 719 40 / 62
|
|
|
|
95 |
934 968 40
|
Press button assy. |
1 |
InternKon: 938 435 40 / 20
|
|
|
|
96 |
907 847 40
|
Button |
1 |
InternBDB: Klц-Mц. M22-DR-X flach rastend | InternKon: 934 968 40 / 1
|
|
|
|
97 |
907 848 40
|
Contact element |
1 |
InternBDB: Klц-Mц. M22--CKC 10 | InternKon: 934 968 40 / 2
|
|
|
|
98 |
940 038 40
|
Button plate |
1 |
InternBDB: Klц-Mц. M22-XD-Light | InternKon: 934 968 40 / 4
|
|
|
|
99 |
655 082 40
|
Cable 2,5 ge/gr |
-2 |
InternKon: 934 495 40 / 5
|
|
|
|
100 |
934 495 40
|
Harness socket 3X4-4X2 |
-2 |
InternKon: 944 719 40 / 52
|
|
|
|
101 |
933 356 40
|
Harness lighting equipment - 3X4- 7H4 |
1 |
InternKon: 944 719 40 / 53
|
|
|
|
102 |
921 563 40
|
Harness lighting equipment - 3X4- 7H3 |
1 |
InternKon: 944 719 40 / 54
|
|
|
|
103 |
933 355 40
|
Harness lighting equipment - 3X4- 7H6 |
1 |
InternKon: 944 719 40 / 55
|
|
|
|
104 |
933 354 40
|
Harness lighting equipment - 3X4- 7H7 |
1 |
InternKon: 944 719 40 / 56
|
|
|
|
105 |
921 564 40
|
Harness lighting equipment - 3X4- 4H41 |
1 |
InternKon: 944 719 40 / 57
|
|
|
|
106 |
933 352 40
|
Harness lighting equipment - 3X4- 4H41a |
1 |
InternKon: 944 719 40 / 58
|
|
|
|
107 |
933 353 40
|
Harness lighting equipment - 3X4- 4H41b |
1 |
InternKon: 944 719 40 / 59
|
|
|
|
108 |
934 490 40
|
Harness lighting equipment - 3X4- 4H43 |
1 |
InternKon: 944 719 40 / 60
|
|
|
|
109 |
934 491 40
|
Harness lighting equipment - 3X4- 4H43a |
1 |
InternKon: 944 719 40 / 61
|
|
|
|
110 |
934 492 40
|
Harness lighting equipment - 3X4- 4H43b |
1 |
InternKon: 944 719 40 / 63
|
|
|
|
111 |
921 549 40
|
Harness 3X4-1X10 |
1 |
InternKon: 944 719 40 / 35
|
|
|
|
112 |
921 548 40
|
Harness 3X4 |
1 |
InternKon: 944 719 40 / 36
|
|
|
|
113 |
921 550 40
|
Harness 4X3 |
1 |
InternKon: 944 719 40 / 34
|
|
|
|
114 |
921 562 40
|
Harness 4X1 |
1 |
InternKon: 944 719 40 / 44
|
|
|
|
115 |
907 194 40
|
Wall socket |
1 |
InternBDB: ETL CEE 5x32 A 206 0099
|
|
|
|
116 |
907 195 40
|
Socket coupler |
1 |
InternBDB: CEE 5x32 A ETL 206 0099 | InternKon: 944 706 40 / 16
|
|
