01 |
655 651 40
|
Protecting hose DN 17 |
-2 |
InternBDB: VCSG-17 B | InternKon: 921 575 40 / 15
|
|
|
|
02 |
655 652 40
|
Protecting hose DN 23 |
-2 |
InternBDB: VCSG-23 B | InternKon: 921 575 40 / 16
|
|
|
|
03 |
655 696 40
|
Protecting hose DN 29 |
-2 |
InternBDB: VCSG-29 B | InternKon: 921 575 40 / 17
|
|
|
|
04 |
655 650 40
|
Protecting hose NW 12 |
-2 |
InternBDB: VCST-12 B | InternKon: 921 575 40 / 14
|
|
|
|
05 |
655 630 40
|
T-Distributor DN 29/23 |
2 |
InternBDB: BFTL-29 23 23 GGG | InternKon: 921 575 40 / 6
|
|
|
|
06 |
655 627 40
|
Distributor DN 23/17 |
1 |
InternBDB: BVYR 23 17 17 GGG | InternKon: 921 575 40 / 5
|
|
|
|
07 |
932 679 40
|
Cable union |
3 |
InternBDB: EK 153 PM 13x2,7 | InternKon: 921 575 40 / 24
|
|
|
|
08 |
655 635 40
|
Pipe adapter DN 29/17 |
1 |
InternBDB: BAVR 29 G 17 G | InternKon: 921 575 40 / 8
|
|
|
|
09 |
655 633 40
|
Pipe adapter MW 17/12 |
1 |
InternBDB: BAVR 17 G 12 T | InternKon: 921 575 40 / 7
|
|
|
|
10 |
515 213 40
|
Cable 1.0 |
-2 |
InternKon: 921 575 40 / 18
|
|
|
|
11 |
940 169 40
|
Cable 4x1 |
-2 |
InternKon: 921 575 40 / 19
|
|
|
|
12 |
907 693 40
|
Fitting DN 17 |
3 |
InternBDB: BVIR-M207 | InternKon: 921 575 40 / 10
|
|
|
|
13 |
932 676 40
|
Cable union |
3 |
InternBDB: Pflitsch 22053 YN | InternKon: 921 575 40 / 12
|
|
|
|
14 |
891 031 40
|
Plug with pins assy. |
15 |
InternKon: 921 575 40 / 1
|
|
|
|
15 |
891 039 40
|
Plug with bushings assy. |
16 |
|
|
|
|
16 |
891 084 40
|
Plug assy. |
3 |
InternKon: 921 575 40 / 2
|
|
|
|
17 |
654 904 40
|
Pressure switch |
1 |
InternBDB: 0166 404 03 1015 0,5 steigend | InternKon: 894 547 40 / 1
|
|
|
|
18 |
592 669 40
|
Pressure switch |
1 |
InternBDB: 0166 416 03 1063 24 bar | InternKon: 894 540 40 / 1
|
|
|
|
19 |
003 670 99
|
Clip |
25 |
InternKon: 921 532 40 / 7
|
|
|
|
20 |
932 898 40
|
Press. measuring transducer |
2 |
InternBDB: Hydac HDA 4740-G-100-161 | InternKon: 921 532 40 / 10
|
|
|
|
21 |
910 055 40
|
Protection cap assy. |
2 |
InternKon: 921 575 40 / 4
|
|
|
|
22 |
923 677 40
|
Cable union |
3 |
InternBDB: Pflitsch DS 153 YN | InternKon: 921 575 40 / 23
|
|
|
|
23 |
907 692 40
|
Fitting M16/NW12 |
1 |
InternBDB: BVIR M162 | InternKon: 921 575 40 / 9
|
|
|
|
24 |
907 703 40
|
Cable union |
1 |
InternBDB: Pflitsch 21650 YNPM 4x3 | InternKon: 921 575 40 / 11
|
|
|
|
25 |
896 520 40
|
End pin |
11 |
InternBDB: Pflitsch BO 3,0x25 | InternKon: 921 575 40 / 13
|
|
|
|
26 |
056 070 40
|
Cable sleeve 1.0-1.5 |
50 |
InternKon: 921 575 40 / 20
|
|
|
|
27 |
256 514 40
|
Name plate |
20 |
InternKon: 921 575 40 / 21
|
|
|
|
28 |
056 292 40
|
Cable strap |
20 |
InternBDB: TY 23 M | InternKon: 921 575 40 / 22
|
|
|
|
29 |
921 575 40
|
Harness - control carrier |
1 |
InternKon: 934 480 40 / 4
|
|
|
|
30 |
510 210 98
|
Thread pin |
20 |
InternBDB: PM 6x20 /32500 | InternKon: 903 399 40 / 2
|
|
|
|
31 |
507 025 98
|
Nut |
20 |
InternBDB: M 6 /985 | InternKon: 903 399 40 / 3
|
|
|
|
32 |
350 762 99
|
Washer |
12 |
InternBDB: R 6,6 /440 | InternKon: 903 399 40 / 4
|
|
|
|
33 |
006 301 98
|
Clamp 12/15 |
1 |
InternBDB: RSGU 1100 12/15 | InternKon: 910 019 40 / 1
|
|
|
|
34 |
006 304 98
|
Clamp 20/25 |
3 |
InternBDB: RSGU 1100 20/25 | InternKon: 910 020 40 / 1
|
|
|
|
35 |
510 363 98
|
Clamp 29/15 |
4 |
InternBDB: RSGU 1100 29/15 | InternKon: 910 028 40 / 1
|
|
|
|
36 |
006 306 98
|
Clamp 30/25 |
3 |
InternBDB: RSGU 1100 30/25 | InternKon: 910 021 40 / 1
|
|
|
|
37 |
509 875 98
|
Thread pin |
3 |
InternBDB: PM 8x25 /32500 | InternKon: 910 021 40 / 2
|
|
|
|
38 |
334 599 99
|
Nut |
3 |
InternBDB: M 8 /985 | InternKon: 910 021 40 / 3
|
|
|
|
39 |
006 339 98
|
Clamp 18/15 |
3 |
InternBDB: RSGU 1100 18/15 | InternKon: 921 532 40 / 5
|
|
|
|
40 |
921 574 40
|
Harness - control plate |
1 |
InternKon: 934 480 40 / 6
|
|
|
|
41 |
515 460 40
|
Seal |
1 |
InternKon: 894 547 40 / 2
|
|
|
|
42 |
907 692 40
|
Fitting M16/NW12 |
1 |
InternBDB: PMA BVIR M162 | InternKon: 921 574 40 / 9
|
|
|
|
43 |
907 703 40
|
Cable union |
2 |
InternBDB: Pflitsch 21650 YNPM 4x3 | InternKon: 921 574 40 / 10
|
|
|
|
44 |
655 650 40
|
Protecting hose DN 12 |
-2 |
InternBDB: VCST-12 B | InternKon: 921 574 40 / 4
|
|
|
|
45 |
906 483 40
|
Valve plug |
1 |
InternBDB: Murr 24999 B + 30m Kabel | InternKon: 921 574 40 / 1
|
|
|
|
46 |
923 560 40
|
Harness - pressure transducer |
1 |
InternKon: 934 480 40 / 5
|
|
|
|
47 |
891 032 40
|
Plug with pins assy. |
2 |
InternKon: 923 560 40 / 1
|
|
|
|
48 |
907 948 40
|
Fitting M25/NW23 |
1 |
InternBDB: BVIR-M253 | InternKon: 923 560 40 / 2
|
|
|
|
49 |
517 328 98
|
Reducing M25x1.5 - M20x1.5 |
1 |
InternBDB: DINEN 50262 | InternKon: 923 560 40 / 3
|
|
|
|
50 |
517 327 98
|
Reducing M20x1.5 - M16x1.5 |
1 |
InternBDB: DINEN 50262 | InternKon: 923 560 40 / 4
|
|
|
|
51 |
907 708 40
|
Cable union PG 13,5 |
1 |
InternBDB: Pflitsch 052 YNPM 6x2,5 | InternKon: 923 560 40 / 5
|
|
|
|
52 |
455 756 99
|
Insulating tube B 6x0,6 |
-2 |
InternBDB: B6x0,6 /40621 | InternKon: 923 560 40 / 7
|
|
|
|
53 |
891 040 40
|
Plug with bushes assy. |
2 |
|
|
|
|
54 |
515 460 40
|
Seal |
1 |
InternBDB: 14,00x18,70x1 89454640 Pos.2 | InternKon: 894 540 40 / 2
|
|
