01 |
|
Switch cabinet see page |
1 |
InternBDB: 943 287 40 | InternKon: 943 292 40 / 2
|
991-0790 |
|
|
02 |
308 285 99
|
Bolt |
4 |
InternBDB: M36x230/931 10.9 | InternKon: 933 901 40 / 23
|
|
|
|
02 |
504 383 98
|
Bolt (Cold weather design) |
4 |
InternBDB: M36x230/931 10.9 kaltzдh | InternKon: 933 901 40 / 23
|
|
|
|
03 |
308 354 99
|
Bolt |
4 |
InternBDB: M36x160 /931 10.9 | InternKon: 933 901 40 / 20
|
|
|
|
03 |
501 128 98
|
Bolt (Cold weather design) |
4 |
InternBDB: M36x160 /931 10.9 kaltzдh | InternKon: 933 901 40 / 20
|
|
|
|
04 |
255 056 40
|
Washer |
4 |
InternBDB: 37/6916 | InternKon: 933 901 40 / 22
|
|
|
|
05 |
515 014 98
|
Resilient sleeve |
4 |
InternBDB: 37/65x20 | InternKon: 933 901 40 / 21
|
|
|
|
10 |
390 199 40
|
Hinge assy. |
6 |
InternBDB: DKG | InternKon: 914 000 40 / 3
|
|
|
|
11 |
621 108 40
|
Pin |
6 |
InternKon: 390 199 40 / 1
|
|
|
|
12 |
390 600 40
|
Bushing |
12 |
InternKon: 390 199 40 / 2
|
|
|
|
13 |
390 601 40
|
Bushing |
6 |
InternKon: 390 199 40 / 3
|
|
|
|
14 |
340 612 99
|
Washer |
6 |
InternKon: 390 199 40 / 4
|
|
|
|
15 |
342 061 99
|
Cotter pin |
6 |
InternBDB: 4x32 | InternKon: 390 199 40 / 5
|
|
|
|
16 |
350 562 99
|
Grease nipple |
6 |
InternBDB: AM 10x1 | InternKon: 390 199 40 / 6
|
|
|
|
17 |
307 810 99
|
Bolt |
6 |
InternBDB: M12 x 60 8.8 DIN 933
|
|
|
|
18 |
346 498 99
|
Washer |
6 |
InternBDB: DIN 128 A12
|
|
|
|
19 |
332 353 99
|
Nut |
6 |
InternBDB: M12 10 DIN 934
|
|
|
|
20 |
903 691 40
|
Flap |
3 |
InternKon: 914 000 40 / 2
|
|
|
|
21 |
915 161 40
|
Cover |
1 |
InternKon: 914 000 40 / 22
|
|
|
|
22 |
308 610 99
|
Bolt |
3 |
InternBDB: M 12x80 / 931 | InternKon: 914 000 40 / 24
|
|
|
|
23 |
334 600 99
|
Nut |
3 |
InternBDB: M 12 / 985 | InternKon: 914 000 40 / 25
|
|
|
|
24 |
906 744 40
|
Grating |
2 |
InternBDB: 40x300x1830 | InternKon: 914 000 40 / 8
|
|
|
|
25 |
317 319 40
|
Threaded block |
6 |
InternKon: 914 000 40 / 9
|
|
|
|
26 |
317 318 40
|
Wing nut, plastic |
6 |
InternBDB: A21x26 / 7603 | InternKon: 914 000 40 / 10
|
|
|
|
27 |
502 354 98
|
Bolt |
6 |
InternBDB: M8x40 /963 | InternKon: 914 000 40 / 11
|
|
|
|
28 |
514 072 98
|
Bolt |
12 |
InternBDB: M8x12 /933 10.9 | InternKon: 921 541 40 / 6
|
|
|
|
29 |
350 763 99
|
Washer |
12 |
InternBDB: R 9,0 /440 | InternKon: 921 541 40 / 7
|
|
|
|
30 |
896 742 40
|
Cable channel 110 |
-2 |
InternBDB: Sievert RSV 110.300 230 4968 | InternKon: 921 541 40 / 3
|
|
