01 |
634 009 40
|
Head light |
8 |
InternBDB: ABL/AB-05-03 mit H1-Lampe /E-ST | InternKon: 903 344 40 / 26
|
|
|
|
02 |
635 645 40
|
Emergency switch-off |
5 |
InternBDB: Klц.u.Mцl. FAK-R/V/KC/I-090794 | InternKon: 903 344 40 / 31
|
|
|
|
03 |
507 383 98
|
Halogen lamp to fig-no. 01 |
8 |
InternBDB: ABL 11-50320/H1 24V 70W
|
|
|
|
04 |
634 135 40
|
Fluorescent Lamp |
3 |
InternBDB: KIRA / KECL-DW 6318/24-0 | InternKon: 903 344 40 / 27
|
|
|
|
05 |
766 904 73
|
Fluorescent Lamp
to fig-nos. 05,06 |
3 |
InternBDB: Philips / PL-L18W/84/4P
|
|
|
|
06 |
600 813 99
|
Reducing 16-13.5 |
5 |
|
|
|
|
07 |
655 621 40
|
Cable union DN 10 |
-2 |
InternBDB: PMA BVNV P 090 T | InternKon: 903 383 40 / 37
|
|
|
|
08 |
655 649 40
|
Cable protection hose DN 10
Bulk ware, state length
required |
-2 |
InternBDB: PMA VCST-10B | InternKon: 903 383 40 / 46
|
|
|
|
09 |
515 213 40
|
Cable
Bulk ware, state length
required |
-2 |
InternKon: 903 383 40 / 36
|
|
|
|
10 |
006 302 98
|
Clamp |
100 |
InternBDB: RSGU 1100/ 15/15
|
|
|
|
11 |
255 034 40
|
Housing, empty |
5 |
InternBDB: Bopla A 105 | InternKon: 903 383 40 / 3
|
|
|
|
12 |
255 680 40
|
Pull switch |
4 |
InternBDB: ES 61 WZ 10 E /1.5 | InternKon: 903 344 40 / 179
|
|
|
|
13 |
360 887 40
|
Connector |
10 |
InternBDB: 2,8x0,8 1148/01
|
|
|
|
14 |
307 425 99
|
Bolt |
40 |
InternBDB: M8x20 /933
|
|
|
|
15 |
343 004 99
|
Washer |
40 |
InternBDB: 8,4 /93
|
|
|
|
16 |
471 915 99
|
Cable 4x1.5
Bulk ware, state length
required |
-2 |
InternBDB: 4x1,5 /97718
|
|
|
|
17 |
440 373 40
|
Cam switch |
3 |
InternBDB: Sievert 153 202 20A 3-polig | InternKon: 903 344 40 / 24
|
|
|
|
18 |
323 946 40
|
Thread pin |
100 |
InternBDB: M6x20 /32501
|
|
|
|
19 |
507 025 98
|
Nut |
100 |
InternBDB: M 6 /985
|
|
|
|
20 |
323 960 40
|
Tab 6.3 x 0.8 |
30 |
|
|
|
|
21 |
323 961 40
|
Sleeve 6.3 x 0.8 |
30 |
|
|
|
|
22 |
621 748 40
|
Cable channel 80/150
Bulk ware, state length
required |
-2 |
InternBDB: KBL 80150 Tehalit | InternKon: 903 383 40 / 57
|
|
|
|
23 |
621 749 40
|
Cable channel 80/200
Bulk ware, state length
required |
-2 |
InternBDB: KBL 80200 Tehalit | InternKon: 903 383 40 / 58
|
|
|
|
24 |
621 750 40
|
Cover to fig-no. 22
Bulk ware, state length
required |
-2 |
InternBDB: KBA 80150 Tehalit | InternKon: 903 383 40 / 59
|
|
|
|
25 |
621 751 40
|
Cover to fig-no. 23
Bulk ware, state length
required |
-2 |
InternBDB: KBA 80200 Tehalit | InternKon: 903 383 40 / 60
|
|
|
|
26 |
621 752 40
|
Cable channel
Bulk ware, state length
required |
-2 |
InternBDB: LFG 40060/0 Tehalit | InternKon: 903 383 40 / 61
|
|
|
|
27 |
621 753 40
|
Cable channel
Bulk ware, state length
required |
-2 |
InternBDB: LFG 50100/0 Tehalit | InternKon: 903 383 40 / 62
|
|
|
|
28 |
621 754 40
|
Spring |
50 |
InternBDB: L 7000 Tehalit | InternKon: 903 383 40 / 63
|
|
|
|
29 |
621 755 40
|
Spring |
80 |
InternBDB: L 7030 Tehalit | InternKon: 903 383 40 / 64
|
|
|
|
30 |
600 812 99
|
Reducing 13.5-11 |
-2 |
|
|
|
|
31 |
600 790 99
|
Reducing 11-9 |
-2 |
|
|
|
|
32 |
057 295 40
|
Socket |
8 |
InternBDB: 0332 030 002
|
|
|
|
33 |
898 629 40
|
Rotaflare light assy. |
1 |
InternKon: 903 383 40 / 182
|
|
|
|
34 |
898 612 40
|
Retainer |
1 |
InternKon: 898 629 40 / 1
|
|
|
|
35 |
896 497 40
|
Rotaflare light yellow |
1 |
InternBDB: Hella 24V 2RL 006 846-01 | InternKon: 898 629 40 / 2
|
|
|
|
36 |
180 322 40
|
Plug |
1 |
InternBDB: Bosch 0986 352 000 | InternKon: 898 629 40 / 5
|
|
|
|
37 |
323 960 40
|
Tab 6.3 x 0.8 |
2 |
InternKon: 898 629 40 / 6
|
|
|
|
38 |
515 214 40
|
Cable 2.5 qmm
Bulk ware, state length
required |
-2 |
InternBDB: Pur-Seil-Flex 2.5 hellblau KIW | InternKon: 898 629 40 / 7
|
|
|
|
39 |
634 446 40
|
Camswitch |
1 |
InternBDB: Klцckner-Mцller T0-1-15-321/I - 1-polig | InternKon: 903 344 40 / 114
|
|
|
|
40 |
896 746 40
|
Horn |
1 |
InternBDB: Ecco 787 | InternKon: 903 344 40 / 180
|
|
