01 |
923 993 40
|
Pipe |
2 |
InternBDB: Ш 25x3x1375 | InternKon: 923 936 40 / 43
|
|
|
|
02 |
371 264 99
|
Union Nut |
12 |
InternBDB: N-S 25 / ISO 8434 | InternKon: 923 936 40 / 46
|
|
|
|
03 |
906 868 40
|
Olive |
12 |
InternBDB: ES-4 S25 WN 655 939 40 | InternKon: 923 936 40 / 45
|
|
|
|
04 |
374 414 99
|
Socket |
4 |
InternBDB: SDS 25 X M33x2 / ISO8434 | InternKon: 923 936 40 / 50
|
|
|
|
05 |
516 853 40
|
Pipe |
1 |
InternBDB: Ш 25x3x300 | InternKon: 923 936 40 / 42
|
|
|
|
06 |
906 938 40
|
Valve |
1 |
InternBDB: RHD 25-PS / OMD 0,2B | InternKon: 923 936 40 / 47
|
|
|
|
07 |
516 740 98
|
Socket |
4 |
InternBDB: SWBT-S 25 / ISO 8434-4 | InternKon: 923 936 40 / 51
|
|
|
|
08 |
500 086 40
|
Pipe |
1 |
InternBDB: 25x3x70 | InternKon: 923 936 40 / 59
|
|
|
|
09 |
516 837 98
|
Socket |
1 |
InternBDB: E-S 25 / ISO 8434 | InternKon: 923 936 40 / 24
|
|
|
|
10 |
517 764 98
|
Hose assy. DN 25x750 |
1 |
InternBDB: 350 DOS 25 DOS 25 45 | InternKon: 923 936 40 / 57
|
|
|
|
11 |
928 873 40
|
Pipe |
1 |
InternBDB: Ш 25x2,5x068,5 | InternKon: 935 281 40 / 159
|
|
|
|
12 |
374 443 99
|
Socket |
4 |
InternBDB: S-S 25 / ISO 8434 | InternKon: 935 281 40 / 172
|
|
|
|
15 |
006 632 98
|
Half flange |
8 |
InternBDB: 25/210 | InternKon: 935 281 40 / 68
|
|
|
|
16 |
324 524 40
|
Flange seal |
2 |
InternKon: 935 281 40 / 62
|
|
|
|
17 |
319 148 99
|
Bolt |
8 |
InternBDB: M10x30 / DIN 912 | InternKon: 935 281 40 / 130
|
|
|
|
18 |
907 735 40
|
Flange connection |
1 |
InternBDB: GFS 34/30 S | InternKon: 935 281 40 / 129
|
|
|
|
20 |
517 786 98
|
Hose assy. DN 32x1150 |
1 |
InternBDB: SHL350 DOS 30 DOS 30 90° | InternKon: 935 281 40 / 20
|
|
|
|
21 |
517 729 98
|
Hose assy. DN 25x3600 |
1 |
InternBDB: SHL350 DOS 25 DOS 25 | InternKon: 935 281 40 / 21
|
|
|
|
30 |
928 870 40
|
Console |
1 |
InternKon: 935 281 40 / 154
|
|
|
|
31 |
928 875 40
|
Console |
1 |
InternKon: 935 281 40 / 155
|
|
|
|
32 |
510 745 98
|
Resilient sleeve |
8 |
InternBDB: 13/25x40 / WN 341 948 40 | InternKon: 935 281 40 / 193
|
|
|
|
33 |
307 810 99
|
Bolt |
8 |
InternBDB: M12x60 / DIN 933 | InternKon: 935 281 40 / 199
|
|
|
|
34 |
533 998 99
|
Pair of clamps |
2 |
InternBDB: S-1-R-15 PP / DIN 3015 | InternKon: 935 281 40 / 198
|
|
|
|
35 |
308 576 99
|
Bolt |
4 |
InternBDB: M10x45 / 8.8 DIN 931 | InternKon: 935 281 40 / 197
|
|
|
|
36 |
533 996 99
|
Weld on plate |
2 |
InternBDB: S-DP-A-1 / DIN 3015 | InternKon: 935 281 40 / 217
|
|
|
|
40 |
930 064 40
|
Pipe |
1 |
InternBDB: Ш 15x1,5x1121 | InternKon: 935 281 40 / 156
|
|
|
|
41 |
930 066 40
|
Pipe |
1 |
InternBDB: Ш 28x2,5x1171 | InternKon: 935 281 40 / 158
|
|
|
|
42 |
930 065 40
|
Pipe |
1 |
InternBDB: Ш 28x2,5x1141 | InternKon: 935 281 40 / 157
|
|
|
|
43 |
928 874 40
|
Pipe |
1 |
InternBDB: Ш 25x2,5x1195 | InternKon: 935 281 40 / 160
|
|
|
|
50 |
534 000 99
|
Pair of clamps |
4 |
InternBDB: S-2-R-25 / DIN 3015 | InternKon: 935 281 40 / 200
|
|
|
|
51 |
502 954 98
|
Pair of clamps |
12 |
InternBDB: S-2-R-28 / DIN 3015 | InternKon: 935 281 40 / 201
|
|
|
|
52 |
534 001 99
|
Cover Plate |
18 |
InternBDB: S-DP-A-2 / DIN 3015 | InternKon: 935 281 40 / 202
|
|
|
|
53 |
308 579 99
|
Bolt |
22 |
InternBDB: M10x60 / DIN931 | InternKon: 935 281 40 / 203
|
|
|
|
54 |
343 005 99
|
Washer |
28 |
InternBDB: 10,5 / DIN 93 | InternKon: 935 281 40 / 204
|
|
|
|
55 |
534 002 99
|
Weld on plate |
4 |
InternBDB: S-AP-A-2 / DIN 3015 | InternKon: 935 281 40 / 207
|
|
|
|
56 |
504 226 98
|
Pair of clamps |
1 |
InternBDB: S-2-R-30 / DIN 3015 | InternKon: 935 281 40 / 208
|
|
|
|
60 |
928 859 40
|
Pipe |
1 |
InternBDB: Ш 30x4x1289,5 | InternKon: 935 281 40 / 151
|
|
|
|
61 |
371 265 99
|
Union Nut |
2 |
InternBDB: N-S 30 / ISO 8434 | InternKon: 935 281 40 / 164
|
|
|
|
62 |
906 352 40
|
Olive |
2 |
InternBDB: ES-4 S30 WN 655 939 40 | InternKon: 935 281 40 / 165
|
|
|
|
63 |
374 445 99
|
Socket |
2 |
InternBDB: S-S 30 / ISO 8434 | InternKon: 935 281 40 / 166
|
|
|
|
64 |
517 740 98
|
Hose assy. DN 32x850 |
1 |
InternBDB: SHL350 DOS 30 DOS 30 90° | InternKon: 935 281 40 / 148
|
|
