01 |
517 727 98
|
Hose assy. DN 40 x 1370 |
1 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 45 | InternKon: 935 281 40 / 15
|
|
|
|
02 |
517 695 98
|
Hose assy. DN 40 x 1650 |
1 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 45 | InternKon: 935 281 40 / 16
|
|
|
|
03 |
517 688 98
|
Hose assy. DN 40 x 1960 |
1 |
InternBDB: 350 FS 1 1/2 FS 2 90 | InternKon: 935 281 40 / 12
|
|
|
|
04 |
517 616 98
|
Hose assy. DN 40 x 1500 |
1 |
InternBDB: 350 FS 1 1/2 FS 2 45 | InternKon: 935 281 40 / 14
|
|
|
|
05 |
793 499 73
|
Pipe assy. |
1 |
InternBDB: Rohr Pumpe 1-STBL I | InternKon: 935 281 40 / 22
|
|
|
|
06 |
793 492 73
|
Pipe assy. |
1 |
InternBDB: Rohr Pumpe 3-STBL III | InternKon: 935 281 40 / 24
|
|
|
|
07 |
793 496 73
|
Pipe assy. |
1 |
InternBDB: Rohr Pumpe 3-Klotz | InternKon: 935 281 40 / 140
|
|
|
|
08 |
517 636 98
|
Hose assy. DN 40 x 1900 |
1 |
InternBDB: 350 FS 2 FS 1 1/2 45 | InternKon: 935 281 40 / 13
|
|
|
|
09 |
793 461 73
|
Pipe assy. |
1 |
InternBDB: Rohr Pumpe 2-STBL II | InternKon: 935 281 40 / 23
|
|
|
|
10 |
619 823 40
|
Hose assy. DN 40 x 1200 |
1 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 45 | InternKon: 935 281 40 / 17
|
|
|
|
11 |
356 209 40
|
Flange seal |
33 |
InternBDB: 1 1/2" NBR 90 | InternKon: 935 281 40 / 61
|
|
|
|
12 |
319 288 99
|
Bolt |
92 |
InternBDB: M16x50 / DIN 912 | InternKon: 935 281 40 / 95
|
|
|
|
13 |
925 134 40
|
Intermediate plate |
2 |
InternBDB: 1 1/2" 120x165 | InternKon: 935 281 40 / 3
|
|
|
|
14 |
308 654 99
|
Bolt |
4 |
InternBDB: M16x210 / DIN 931 | InternKon: 935 281 40 / 102
|
|
|
|
15 |
928 846 40
|
Intermediate plate |
1 |
InternBDB: 1 1/2" 120x120 | InternKon: 935 281 40 / 141
|
|
|
|
16 |
302 553 99
|
Bolt |
2 |
InternBDB: M16x190 / DIN 931 | InternKon: 935 281 40 / 142
|
|
|
|
17 |
334 601 99
|
Nut |
6 |
InternBDB: M16 / DIN 985 | InternKon: 935 281 40 / 143
|
|
|
|
18 |
925 135 40
|
Diffuser |
1 |
InternBDB: 1 1/2" 185x225 | InternKon: 935 281 40 / 11
|
|
|
|
19 |
504 682 98
|
Bolt |
4 |
InternBDB: M12x200 / DIN 931 | InternKon: 935 281 40 / 103
|
|
|
|
25 |
500 127 98
|
Flange |
8 |
InternBDB: FE-5000-24/6 | InternKon: 935 281 40 / 137
|
|
|
|
26 |
500 203 98
|
Collar ring |
3 |
InternBDB: KO-5060-24 | InternKon: 935 281 40 / 139
|
|
|
|
27 |
319 292 99
|
Bolt |
36 |
InternBDB: M16x90 / DIN 912 | InternKon: 935 281 40 / 94
|
|
|
|
28 |
332 355 99
|
Nut |
36 |
InternBDB: M16 / DIN 934 | InternKon: 935 281 40 / 99
|
|
|
|
30 |
501 898 98
|
Collar ring |
5 |
InternBDB: K-5060-24 | InternKon: 935 281 40 / 138
|
|
|
|
31 |
319 289 99
|
Bolt |
20 |
InternBDB: M16x60 / DIN 912 | InternKon: 935 281 40 / 114
|
|
|
|
33 |
385 243 40
|
Flange seal |
6 |
InternBDB: 2" NBR 90 | InternKon: 935 281 40 / 60
|
|
|
|
34 |
319 305 99
|
Bolt |
24 |
InternBDB: M20x60 / DIN 912 | InternKon: 935 281 40 / 93
|
|
|
|
40 |
308 617 99
|
Bolt |
4 |
InternBDB: M12x150 / DIN 931 | InternKon: 935 281 40 / 126
|
|
|
|
41 |
534 008 99
|
Cover plate |
5 |
InternBDB: S-DP-A-4 / DIN 3015 | InternKon: 935 281 40 / 125
|
|
|
|
42 |
502 977 98
|
Pair of clamps |
10 |
InternBDB: S-4-G-50 / DIN 3015 | InternKon: 935 281 40 / 124
|
|
|
|
43 |
334 600 99
|
Nut |
10 |
InternBDB: M12 / DIN 985 | InternKon: 935 281 40 / 116
|
|
