01 |
517 735 98
|
Hose assy. DN 25x1800 |
1 |
InternBDB: SHL120 25X 1800 FL 3/4 90 DOL 28 WN 34195140 | InternKon: 935 281 40 / 42
|
|
|
|
02 |
516 750 98
|
Socket |
2 |
InternBDB: S-L 28 ST A3C ISO 08434 | InternKon: 935 281 40 / 163
|
|
|
|
03 |
906 350 40
|
Olive |
2 |
InternBDB: SCHNEIDRG ES-4 L28 9SMNPB28K WN 65593940 | InternKon: 935 281 40 / 162
|
|
|
|
04 |
371 278 99
|
Union Nut |
2 |
InternBDB: N-L 28 ST ZN ISO 08434 | InternKon: 935 281 40 / 161
|
|
|
|
05 |
915 495 40
|
Pipe |
1 |
InternBDB: 28x2,5x1956,7 | InternKon: 935 281 40 / 150
|
|
|
|
06 |
517 787 98
|
Hose assy. DN 25x900 |
1 |
InternBDB: SHL120 25X 900 DOL 28 DOL28 90 WN 34195140 | InternKon: 935 281 40 / 147
|
|
|
|
07 |
928 856 40
|
Intermediate flange |
1 |
InternBDB: 66x66 | InternKon: 935 281 40 / 134
|
|
|
|
08 |
006 631 98
|
Half flange |
2 |
InternBDB: FLANSCHH 20/210 ST52-3N WN 01173599 | InternKon: 935 281 40 / 67
|
|
|
|
09 |
324 535 40
|
Flange seal |
2 |
InternBDB: FLANSCHDICHT 3/4 NBR90 WN 34198640 | InternKon: 935 281 40 / 63
|
|
|
|
10 |
319 242 99
|
Bolt |
4 |
InternBDB: ZYLSHR M 8X 25 10.9 DIN 00912 | InternKon: 935 281 40 / 133
|
|
|
|
11 |
319 256 99
|
Bolt |
4 |
InternBDB: ZYLSHR M10X 25 10.9 DIN 00912 | InternKon: 935 281 40 / 144
|
|
|
|
20 |
502 954 98
|
Pair of clamps |
12 |
InternBDB: KLEMMHPAAR S-2-R-28 PP DIN 03015 | InternKon: 935 281 40 / 201
|
|
|
|
21 |
534 001 99
|
Cover plate |
18 |
InternBDB: D-PLATTE S-DP-A-2 W1 DIN 03015 | InternKon: 935 281 40 / 202
|
|
|
|
22 |
307 793 99
|
Bolt |
2 |
InternBDB: M10x120 / 8.8 DIN 933 | InternKon: 935 281 40 / 209
|
|
|
|
23 |
343 005 99
|
Washer |
28 |
InternBDB: SHB 10,5 UST13 03 DIN 00093 | InternKon: 935 281 40 / 204
|
|
|
|
24 |
534 002 99
|
Weld on plate |
4 |
InternBDB: A-PLATTE S-AP-A-2 W1 DIN 03015 | InternKon: 935 281 40 / 207
|
|
|
|
25 |
307 791 99
|
Bolt |
6 |
InternBDB: 6KTSHR M10X 90 8.8 DIN 00933 | InternKon: 935 281 40 / 210
|
|
|
|
26 |
340 465 99
|
Washer |
8 |
InternBDB: SHB B 10,5 140HV DIN 00125 | InternKon: 935 281 40 / 215
|
|
|
|
27 |
930 905 40
|
Console |
1 |
InternKon: 935 281 40 / 206
|
|
|
|
28 |
504 226 98
|
Pair of clamps |
1 |
InternBDB: KLEMMHPAAR S-2-R-30 PP DIN 03015 | InternKon: 935 281 40 / 208
|
|
|
|
29 |
930 901 40
|
Console |
1 |
InternKon: 935 281 40 / 205
|
|
|
|
30 |
308 269 99
|
Bolt |
2 |
InternBDB: 6KTSHR M10X 150 8.8 DIN 00931 | InternKon: 935 281 40 / 211
|
|
|
|
31 |
507 037 98
|
Nut |
8 |
InternBDB: 6KTMU M10 8 DIN 00985 | InternKon: 935 281 40 / 219
|
|
|
|
35 |
907 149 40
|
Union |
1 |
InternBDB: 28 LR / OMD | InternKon: 935 280 40 / 35
|
|
|
|
36 |
372 885 99
|
Socket |
1 |
InternBDB: R1 1/4" x 1 | InternKon: 935 280 40 / 36
|
|
