01 |
936 969 40
|
Ascent segement |
1 |
InternBDB: PC 5500-6 | InternKon: 938 036 40 / 1
|
|
|
|
02 |
937 658 40
|
Ascent segement |
1 |
InternBDB: PC 3000-6 | InternKon: 938 036 40 / 2
|
|
|
|
03 |
936 975 40
|
Ascent segement |
1 |
InternBDB: PC 5500-6 | InternKon: 938 036 40 / 3
|
|
|
|
04 |
938 039 40
|
Ascent segement |
1 |
InternBDB: PC 4000-6 | InternKon: 938 036 40 / 4
|
|
|
|
05 |
938 041 40
|
Retainer |
1 |
InternBDB: PC 4000-6 | InternKon: 938 036 40 / 5
|
|
|
|
06 |
938 037 40
|
Retainer |
6 |
InternBDB: PC 4000-6 | InternKon: 938 036 40 / 6
|
|
|
|
07 |
938 038 40
|
Retainer |
1 |
InternBDB: PC 4000-6 | InternKon: 938 036 40 / 7
|
|
|
|
08 |
938 044 40
|
Plate |
1 |
InternBDB: 153X210 | InternKon: 938 036 40 / 8
|
|
|
|
09 |
936 985 40
|
Plate |
6 |
InternBDB: 90X110 | InternKon: 938 036 40 / 9
|
|
|
|
10 |
307 775 99
|
Bolt |
24 |
InternBDB: M10x20 / 8.8 / DIN 933 | InternKon: 938 036 40 / 10
|
|
|
|
11 |
343 065 99
|
Washer |
24 |
InternBDB: 10,5 / DIN 463 | InternKon: 938 036 40 / 11
|
|
|
|
12 |
534 009 99
|
Weld on plate |
8 |
InternBDB: S-AP-A-4 / W1 / DIN 03015 | InternKon: 938 036 40 / 12
|
|
|
|
13 |
504 445 98
|
Clamp set |
8 |
InternBDB: S-4-R-65 / Al / DIN 3015 | InternKon: 938 036 40 / 13
|
|
|
|
14 |
308 612 99
|
Bolt |
16 |
InternBDB: M12x100 / 8.8 / DIN 931 | InternKon: 938 036 40 / 14
|
|
|
|
15 |
517 118 98
|
Locking washer |
16 |
InternBDB: ZN / WN 65593840 | InternKon: 938 036 40 / 15
|
|
|
|
16 |
504 709 98
|
Clamp set |
9 |
InternBDB: S-3-R-38 / AL / DIN 3015 | InternKon: 938 036 40 / 16
|
|
|
|
17 |
534 004 99
|
Cover plate |
9 |
InternBDB: S-DP-A-3 / W1 / DIN 3015 | InternKon: 938 036 40 / 17
|
|
|
|
18 |
308 581 99
|
Bolt |
18 |
InternBDB: M10x70 / 8.8 / DIN 931 | InternKon: 938 036 40 / 18
|
|
|
|
19 |
509 309 98
|
Locking plate |
9 |
InternBDB: SI 5 / UST1203 / WN 01183999 | InternKon: 938 036 40 / 19
|
|
|
|
20 |
534 005 99
|
Weld on plate |
1 |
InternBDB: S-AP-A-3 / W1 / DIN 3015 | InternKon: 938 036 40 / 20
|
|
|
|
21 |
896 541 40
|
Vane threaded plug |
8 |
InternBDB: GL30 / GPN 320 | InternKon: 938 036 40 / 21
|
|
