STEERING AND ROD | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	933 000 40	Steering and rod, assy	1	InternKon: 903 028 40 / 3
02	902 939 40	Rod ,assy	1	InternKon: 933 000 40 / 1
03	902 974 40	Rod	1	InternKon: 902 939 40 / 1
04	914 132 40	Flanged bush	2	InternKon: 902 939 40 / 2
05	914 133 40	Flanged bush	2	InternKon: 902 939 40 / 3
10	933 050 40	Steering, l.h. fig-nos. 11,12,13	1	InternKon: 933 000 40 / 3
11	933 043 40	Steering	1	InternBDB: SK \| InternKon: 933 050 40 / 1
12	914 130 40	Flanged bush	1	InternKon: 933 050 40 / 3
13	914 131 40	Flanged bush	1	InternKon: 933 050 40 / 2
15	933 051 40	Steering, r.h. fig-nos.16,17,18	1	InternKon: 933 000 40 / 2
16	933 052 40	Steering	1	InternBDB: SK \| InternKon: 933 051 40 / 1
17	914 130 40	Flanged bush	1	InternKon: 933 051 40 / 3
18	914 131 40	Flanged bush	1	InternKon: 933 051 40 / 2
20	904 410 40	Pin with Plate	1	InternKon: 933 000 40 / 4
23	904 411 40	Pin with Plate	1	InternKon: 933 000 40 / 5
24	926 855 40	Cap	1	InternBDB: 350x350 \| InternKon: 933 000 40 / 7
25	926 850 40	Cap	1	InternBDB: 280x280 \| InternKon: 933 000 40 / 6
26	925 981 40	Safety sleeve	2	InternKon: 933 000 40 / 8
28	904 424 40	Catch	2	InternBDB: 30x300 \| InternKon: 933 000 40 / 10
29	902 953 40	Catch	2	InternBDB: 30x240 \| InternKon: 933 000 40 / 11
30	319 442 99	Bolt	2	InternBDB: M 16x40 / 8.8 / 912 \| InternKon: 933 000 40 / 12
31	925 982 40	Stop	8	InternKon: 933 000 40 / 13
32	332 361 99	Nut	2	InternBDB: M 30 / 934 \| InternKon: 933 000 40 / 14
33	332 338 99	Nut	2	InternBDB: M 20 / 934 \| InternKon: 933 000 40 / 15
34	342 085 99	Cotter pin	2	InternBDB: 5x50 \| InternKon: 933 000 40 / 16
